Hitachi Spare Parts for Hammer Drill DH38YB
€1.33
Tax included
Hitachi Spare Parts for Hammer Drill DH38YB
Hitachi-HIKOKI Original spare parts, at the lowest price on the web to make maintenance operations to replace broken parts or to repair Hammer Drill DH38YB, quick shipping and after-sales service.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Hammer Drill DH38YB
Hitachi-HIKOKI Original spare parts, at the lowest price on the web to make maintenance operations to replace broken parts or to repair Hammer Drill DH38YB, quick shipping and after-sales service.
In the following table, look for the model of the Hammer and the respective parts of the code.
| Hitachi Hammer Drill DH38MB | ||
| # | Part Num. | Description |
| 1 | 986824 | STOP WASHER |
| 2 | 981937 | STOPPER SPRING |
| 3 | 983241 | KNOB (A) |
| 4 | 943364 | NEEDLE ROLLER D4X20 |
| 5 | 983240 | STOP LEVER |
| 6 | 971750 | FEATHER KEY 3X3X20 |
| 7 | 991696 | SEAL LOCK BOLT M7X25 |
| 8 | 992801 | FRONT COVER |
| 9 | 985780 | O-RING (E) |
| 10 | 981857 | O-RING (C) |
| 11A | 990144 | SECOND HAMMER - DISCONTINUED |
| 12 | 981862 | DAMPER WASHER |
| 13 | 992799 | DAMPER |
| 14 | 992798 | WASHER |
| 15 | 992797 | CYLINDER |
| 16 | 992796 | THIRD PINION |
| 17 | 981850 | SLEEVE |
| 18B | 981852 | NEEDLE BEARING (A) HK2012 |
| 19 | 981851 | OIL SEAL (B) |
| 20 | 992795 | SECOND GEAR |
| 21 | 992806 | METAL |
| 22 | 959150 | STEEL BALL D6.35 (10 PCS.) |
| 23 | 992792 | HOLDER |
| 24 | 992793 | PLATE |
| 25 | 992794 | SPRING |
| 26 | 992791 | WASHER |
| 27 | 629VVM | BALL BEARING 628VVMC2EPS2L |
| 28 | 944525 | BEARING WASHER (C) |
| 29 | 992805 | RETAINING RING FOR D@ SHAFT |
| 30 | 957561 | HITACHI LABEL |
| 31 | 980735 | WIND GUIDE TILL 5.1987 |
| 31A | 991713 | WIND GUIDE (B) TILL 6.1987 |
| 32 | 990430 | SEAL LOCK FLAT HD. SCREW M4X10. TILL 5.1987 |
| 33 | 987203 | SEAL LOCK SCREW (W/SP. WASHER) M4X12 |
| 35 | 993903 | CRANK COVER ASS'Y |
| 36 | 980749 | SEAL PACKING |
| 37 | 980744 | O-RING (S 55) |
| 38 | 939542 | RETAINING RING FOR D12 SHAFT (10 PCS.) |
| 39 | 991954 | CRANK SHAFT |
| 40 | 981847 | BEARING COVER |
| 41 | 984509 | SEAL LOCK HEX. SOCKET HD. BOLT M5X14 |
| 43A | 6203DD | BALL BEARING 6203DD UCMAV2S |
| 44 | 971745 | OIL SEAL (A) |
| 45A | 991768 | CRANK CASE INCLUD.18B,19,31A |
| 46 | 980706 | COLLAR |
| 47 | 981845 | FIRST GEAR |
| 48 | 981846 | SECOND PINION |
| 49 | 939299 | NEEDLE BEARING (M661) |
| 50 | 991953 | GEAR COVER |
| 51 | 992803 | SEAL LOCK HEX. SOCKET HD. BOLT M6X20 |
| 52 | 981858 | VALVE BAND. |
| 53 | 981957 | SPRING (A) |
| 54 | 981855 | STRIKER |
| 55 | 986104 | O-RING |
| 56 | 981956 | CLUTCH |
| 57 | 981885 | PISTON |
| 58 | 980708 | PISTON PIN |
| 59 | 980707 | CONNECTING ROD ASS'Y |
| 60 | 987707 | SEAL LOCK HEX. SOCKET HD. BOLT M6X25 TILL 11.1984 |
| 60 | 987707 | SEAL LOCK HEX. SOCKET HD. BOLT M6X25 SINCE 12,1984 FOR HANDLE (A) |
| 62A | 993902 | CYLINDER CASE |
| 63 | 956996 | O-RING (1AS — 60) |
| 64A | 993069 | NEEDLE BEARING (M455520) |
| 65 | 981955 | THRUST WASHER |
| 66 | 981954 | THIRD GEAR |
| 67 | 981870 | SIDE HANDLE |
| 68 | 672612 | SPRING |
| 69 | 981960 | HANDLE HOLDER |
| 70 | 971785 | HANDLE BOLT |
| 71 | 971786 | STOPPER ROD |
| 72 | 981964 | LEVER SHAFT |
| 73 | 981967 | O-RING (A) |
| 74 | 981965 | SHAFT COVER |
| 75 | 959155 | STEEL BALL D3.97 (10 PCS.) |
| 76 | 981966 | SPRING (8) |
| 77 | 981963 | LEVER |
| 78A | 901711 | DISTANCE PIECE (B) |
| 80 | 620 2VV | BALL BEARING 6202VVCMPS2S |
| 81 | 980700 | DUST WASHER (B) |
| 82 | 980740 | FAN |
| 83 | 981971U | ARMATURE ASS'Y 110V — 115V INCLUD.80,81,82,90,91 |
| 83 | 981971D | ARMATURE ASS'Y 120V ~ 127V INCLUD.82 |
| 83 | 981971L | ARMATURE ASS'Y 220V — 230V INCLUD.82 |
| 83 | 981971H | ARMATURE ASS'Y 240V INCLUD.82 |
| 83 | 981971J | ARMATURE ASS'Y 110V INCLUD.82 FOR GBR |
| 84 | 960251 | HEX. HD. TAPPING SCREW D5X65 |
| 87 | 983162 | SEAL LOCK HEX. SOCKET HD. BOLT M4X12 |
| 88 | 986277 | INTERNAL WIRE FOR _NZL,GBR.SAF,ITA,FRG,FRA,ESP,HOL,DEN, FINSWE,AUT |
| 89 | 981970C | STATOR ASS'Y 110V — 115V INCLUD.99 |
| 89 | 981970D | STATOR ASS'Y 120V — 127V INCLUD.99 |
| 89 | 981970E | STATOR ASS'Y 220V — 230V INCLUD.99 |
| 89 | 981970F | STATOR ASS'Y 240V INCLUD.99 |
| 89 | 981970H | STATOR ASS'Y 240V INCLUD.99,110 FOR AUS |
| 89 | 981970J | STATOR ASS'Y 110V INCLUD.99 FOR GBR |
| 89 | 981970K | STATOR ASS'Y 220V — 230V INCLUD.99 FOR_NZL,SAF,ITA,FRG,FRA,DEN, FIN,SWE,NOR,ESP,POR,SUI,HOL,AUT |
| 90 | 980698 | DUST WASHER (A) |
| 91 | 608VVM | BALL BEARING 608VVMC2EPS2L |
| 92 | 958715 | TAPPING SCREW D4X10 |
| 93 | 981959 | CAP COVER |
| 94 | 961781 | BRUSH CAP. |
| 95 | 999073 | CARBON BRUSH (AUTO STOP TYPE) (1 PAIR) |
| 96 | 981586 | BRUSH HOLDER |
| 99 | 930703 | BRUSH TERMINAL |
| 100 | VINYL TUBE (1.D.7XT0.5X120) | |
| 101 | 959140 | CONNECTOR 50091 (10 PCS.) |
| 102A | 963243 | SUPPORT |
| 103 | 994273 | NOISE SUPPRESSOR |
| 104 | 949423 | WASHER M4 (10 PCS.) FOR _GBR,ITA,FRG,FRA,ESP,HOL,DEN,FIN,SWE,AUT,SUI |
| 105 | 981974Z | INTERNAL WIRE FOR _GBR,ITA,FRG,FRA,ESP,HOL,DEN,FIN,SWE,AUT,SUI |
| 106 | 959141 | CONNECTOR 50082 (10 PCS.) |
| 107A | 990941 | SWITCH (B) (1P SCREW TYPE) W/O LOCK |
| 107A | 981533Z | SWITCH (2P PILLAR TYPE) W/O LOCK FOR AUS |
| 108 | 981869 | SUPPORT (A) TILL 10.1987 |
| 108 | 981986Z | SUPPORT (A) FOR AUS |
| 108A | 990082 | SUPPORT (E) SINCE 11,1987 |
| 109 | 992808 | HANDLE (A) |
| 109 | 981866 | HANDLE (A) FOR AUS |
| 110 | 981373 | TUBE (D) |
| 111 | 992790 | HOUSING ASS'Y INCLUD,96,118 |
| 112 | 992809 | HANDLE (B} |
| 113B | 981867 | DISTANCE PIECE (C) |
| 114 | 958308Z | PILLAR TERMINAL (A) FOR FIN |
| 115 | 992810 | TERMINAL FOR _ITA,FRG,FRA,HOL,DEN,FIN,SWE,AUT |
| 116 | 958049Z | CORD ARMOR D8.2 |
| 116 | 940778 | CORD ARMOR D10.7 |
| 117 | 500239Z | CORD (CORD ARMOR D10.7) |
| 117 | 500224Z | CORD (CORD ARMOR 010.7) FOR_SIN,KUW |
| 117 | 500227Z | CORD (CORD ARMOR D8.2) FOR NGU,NZL |
| 117 | 500232Z | CORD (CORD ARMOR D8.2) FOR SAF |
| 117 | 500235Z | CORD (CORD ARMOR D8.2)FOR INA.SUR.DEN,SWE,NO |
| 117 | 500249Z | CORD (CORD ARMOR D8.2) FOR CAN |
| 117 | 500390Z | CORD (CORD ARMOR D10.7) FOR ITA,FRG,FRA,HOL,DEN,FIN.SWE,AUT |
| 117 | 500391Z | CORD (CORD ARMOR D10.7) FOR SUI |
| 117 | 500394Z | CORD (CORD ARMOR D10.7) FOR SYR,ESP |
| 117 | 500406Z | CORD (CORD ARMOR D8.2) FOR GBR |
| 117 | 500410Z | CORD (CORD ARMOR D10.7) FOR AUS |
| 118 | 938477 | HEX. SOCKET SET SCREW MSX8 |
| 119 | 985480 | TAPPING SCREW (W/WASHER) D5X20 |
| 120 | 302323 | TAIL COVER (8) |
| 121 | 949510 | RIVET D2.5X4.8(10PCS) |
| 122 | NAME PLATE | |
| 123 | 956636 | TAPPING SCREW (W/WASHER) D4X25 |
| 124 | 992802 | TAPPING SCREW D6X25 |
| 125 | 992807 | CHOKE COIL FOR NZL |
| 126 | 938307Z | PILLAR TERMINAL FOR _GBR,ITA,FRG,FRA,ESP,HOL,DEN.FIN,SWE,AUT,SIN |
| 127 | 984750 | TAPPING SCREW (W/FLANGE) D4X16 |
| 128 | 960266 | CORD CLIP |
| 129 | 967261 | RETAINING RING FOR D17 SHAFT |
| 130A | 990146 | DISTANCE PIECE (A) |
| 131A | 993903 | CRANK COVER ASS'Y INCLUD.33,35,130A, |
| 132 | 991712 | HEX. SOCKET HD. BOLT (W/FLANGE) M6X25 |
| 133 | 982411 | HEX. SOCKET HD. BOLT (W/FLANGE) M6X50 |
