Hitachi Spare Parts for Hammer Drill DH 20PB
€1.33
Tax included
Hitachi Spare Parts for Hammer Drill DH 20PB
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Hammer Drill DH 20PB.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Hammer Drill DH 20PB
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Hammer Drill DH 20PB.
In the following table, look for the model of the Hammer and the respective parts of the code.
| HAMMER DRILL Model DH 20PB | ||
| 1 | 306345 | FRONT CAP INCLUD.44,45,52 |
| 2 | 306992 | GRIP INCLUD.48 |
| 3 | 306343 | BALL HOLDER FOR CORD |
| 4 | 306342 | HOLDER SPRING (CORD ARMOR D8.8) |
| 5 | 984118 | WASHER (B) (CORD ARMOR D8.8) FOR GBR (230V) |
| 6 | 939547 | RETAINING RING FOR D20 SHAFT (CORD ARMOR D8.8) FOR SUI |
| 7 | 314876 | GEAR COVER |
| 8 | 301654 | TAPPING SCREW (W/FLANGE) D5X35 |
| 9 | 314881 | O-RING |
| 10 | 981328 | SPRING (H) |
| 11 | 959155 | STEEL BALL D3.97 |
| 12 | 314878 | O-RING |
| 13 | 314877 | CHANGE LEVER |
| 14 | 307688 | OIL SEAL |
| 15 | 307690 | SLEEVE |
| 16 | 6904DD | BALL BEARING 6904DDPS2L |
| 17 | 986147 | RETAINING RING FOR D37 HOLE |
| 18 | 959156 | STEEL BALL D7.0 |
| 19 | 959154 | STEEL BALL D5.556 |
| 20 | 314882 | CYLINDER |
| 21 | 301677 | SECOND GEAR |
| 22 | 301678 | SPRING (A) |
| 23 | 301679 | WASHER (A) |
| 24 | 948310 | RETAINING RING FOR D30 SHAFT |
| 25 | 301671 | SECOND HAMMER |
| 26 | 301672 | O-RING (B) |
| 27 | 301680 | O-RING (I.D. 10.5) |
| 28 | 315148 | STRIKER |
| 29 | 301670 | O-RING (A) |
| 30 | 301668 | PISTON |
| 31 | 301666 | PISTON PIN |
| 32 | 303977 | WASHER (C) |
| 33 | 314880 | INNER COVER |
| 34 | 301664 | SPRING (B) |
| 35 | 315161 | GEAR SHAFT SET |
| 36 | 301659 | WASHER (B) |
| 37 | 301660 | CLUTCH SPRING |
| 38 | 301661 | CLUTCH |
| 39 | 992912 | O-RING (S-8) |
| 40 | 306990 | RECIPROCATING BEARING |
| 41 | 301663 | SPACER |
| 42 | 626VVM | BALL BEARING 626VVC2PS2L |
| 43 | 876796 | O-RING (P-22) |
| 44 | 608DDM | BALL BEARING 608DDC2PS2L |
| 45 | 982631 | WASHER (A) |
| 46 | 360446U | ARMATURE ASS’Y 110V-115V |
| 46 | 360446E | ARMATURE 220V-230V |
| 47 | 314879 | FAN GUIDE ASS’Y |
| 48 | 994343 | RUBBER BUSHING |
| 49 | 340398C | STATOR 110V-115V |
| 49 | 340398F | STATOR 230V-240V |
| 50 | 314914 | INTERNAL WIRE (A) (BLACK) |
| 51 | 314913 | INTERNAL WIRE (A) (GRAY) |
| 52 | 608VVM | BALL BEARING 608VVC2PS2L |
| 53 | 314889 | HOUSING |
| 54 | 314912 | NAME PLATE |
| 55 | 314915 | INTERNAL WIRE (A) (RED) |
| 56 | 301653 | INTERNAL WIRE (A) (WHITE) |
| 57 | 314891 | TAPPING SCREW (W/FLANGE) D4X20 (BLACK) |
| 58 | 314916 | HANDLE COVER |
| 59 | 314921 | SPEED CONTROL SWITCH (2P) 100V-115V |
| 59 | 994273 | SPEED CONTROL SWITCH (2P) 220V-240V |
| 60 | 302488 | NOISE SUPPRESSOR |
| 61 | 999041 | EARTH TERMINAL |
| 62 | 999072 | CARBON BRUSH (1 PAIR) |
| 62 | 955203 | CARBON BRUSH (AUTO STOP TYPE) (1 PAIR) |
| 63 | 981373 | BRUSH HOLDER |
| 64 | 315147 | HITACHI LABEL |
| 65 | 314922 | TUBE (D) |
| 66 | 314923 | DUST PACKING |
| 67 | 984750 | CHOKE COIL (A) BLUE |
| 68 | 937631 | CHOKE COIL (A) BROWN |
| 69 | 953327 | TAPPING SCREW (W/FLANGE) D4X16 |
| 70 | 500390Z | CORD CLIP |
| 71 | 500440Z | CORD ARMOR D8.8 |
| 72 | 500391Z | CORD |
| 72 | 307786 | CORD |
| 72 | 303659 | CORD |
| 501 | 303709 | CASE |
| 502 | SIDE HANDLE | |
| 503 | DEPTH GAUGE | |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
