Hitachi Spare Parts for Rotary Hammer Drill DH28PMY
€2.24
Tax included
Hitachi Spare Parts for Rotary Hammer Drill DH28PMY
Hitachi-HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Rotary Hammer Drill DH28PMY.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Rotary Hammer Drill DH28PMY
Hitachi-HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Rotary Hammer Drill DH28PMY.
In the following table , look for the model of the Rotary Hammer Drill and the respective parts of the code.
| Rotary Hammer Drill DH28PMY | ||
| # | Part Num. | Description |
| 1 | 326271 | CHUCK HOLDER ASS'Y |
| 5 | 965469 | RETAINING RING FOR D25 SHAFT |
| 6 | 326520 | WASHER (B) |
| 7 | 326519 | SPRING |
| 8 | 326387 | LOCK GRIP |
| 9 | 326801 | LOCK RING |
| 10 | 336850 | CHUCK HOLDER |
| 11A | 335274 | GEAR COVER |
| 12 | 959156 | STEEL BALL D7.0 |
| 14 | 335259 | OIL SEAL |
| 15 | 335260 | BALL BEARING 6805DD |
| 16 | 326516 | BIT HOLDER ASS'Y |
| 17 | 336849 | BIT HOLDER |
| 18 | 306345 | FRONT CAP |
| 19 | 306340 | STOPPER RING |
| 20 | 324527 | GRIP |
| 21 | 324528 | BALL HOLDER |
| 22 | 324526 | HOLDER PLATE |
| 23 | 322812 | HOLDER SPRING |
| 24 | 322789 | PUSHING BUTTON |
| 25 | 317223 | PUSHING SPRING |
| 26 | 334011 | CHANGE LEVER |
| 27 | 878885 | O-RING (S-18) |
| 29 | 335800 | SPRING (E) |
| 30 | 608VVM | BALL BEARING 608VVC2PS2L |
| 31 | 336845 | CYLINDER |
| 32 | 335264 | PIN D2.5 |
| 33 | 335263 | CYLINDER CLUTCH |
| 34 | 335265 | SECOND GEAR |
| 35 | 335266 | SPRING (A) |
| 36 | 301679 | WASHER (A) |
| 37 | 948310 | RETAINING RING FOR D30 SHAFT |
| 38 | 335262 | OIL SEAL (A) |
| 39 | 336847 | HAMMER HOLDER (C) |
| 40 | 335795 | SLEEVE (FW) |
| 41 | 336846 | SECOND HAMMER |
| 42 | 335267 | HAMMER HOLDER (A) |
| 43 | 322805 | DAMPER (A) |
| 44 | 322808 | O-RING (C) |
| 45 | 324524 | DAMPER HOLDER |
| 46 | 322807 | STOPPER RING |
| 47 | 335246 | STRIKER |
| 48 | 335247 | O-RING D17 |
| 49 | 335255 | PISTON |
| 50 | 335793 | PISTON PIN |
| 51 | 335250 | BEARING WASHER |
| 52 | 335794 | PISTON WASHER |
| 53 | 335275 | PINION SLEEVE |
| 54 | 335276 | LOCK PLATE |
| 55 | 335278 | SECOND PINION |
| 56 | 323182 | CLUTCH SPRING |
| 57 | 335254 | CLUTCH |
| 58 | 331315 | WASHER |
| 59 | 335277 | SECOND SHAFT |
| 60 | 335249 | RECIPROCATING BEARING |
| 62 | 335270 | BEARING HOLDER |
| 63 | 335271 | BEARING COVER |
| 64 | 335253 | FIRST GEAR |
| 65 | 335245 | O-RING D72.2 |
| 66 | 335798 | INNER COVER |
| 67 | 334008 | AIR CAP |
| 68 | 324543 | FELT PACKING (A) |
| 69 | 335284 | SPRING DAMPER |
| 70 | 335283 | SPRING HOLDER |
| 72 | 335285 | WEIGHT DAMPER (A) |
| 73 | 335280 | WEIGHT (A) |
| 74 | 335282 | LEAF SPRING |
| 75 | 335281 | WEIGHT (B) |
| 76 | 325241 | SEAL LOCK HEX. SOCKET HD. BOLT M3X8 |
| 77 | 322816 | FELT PACKING |
| 78 | 322818 | PACKING WASHER |
| 79 | 876796 | O-RING (P-22) |
| 80 | 608DDM | BALL BEARING 608DD |
| 81 | 982631 | WASHER (A) |
| 82 | 335279 | COVER PLATE |
| 83 | 360961E | ARMATURE 220V-230V |
| 84 | 335286 | WEIGHT DAMPER (B) |
| 85 | 335244 | FAN GUIDE |
| 87 | 340850E | STATOR 220V-230V |
| 88 | 322853 | PUSHING BUTTON |
| 89 | 335796 | SWITCH |
| 90 | 335242 | HANDLE COVER |
| 92 | 335241 | HOUSING |
| 94 | 955203 | BRUSH HOLDER |
| 95 | 999041 | CARBON BRUSH (1 PAIR) |
| 96 | 999072 | CARBON BRUSH (AUTO STOP TYPE) (1 PAIR) |
| 97 | 953327 | CORD ARMOR D8.8 |
| 98 | 937631 | CORD CLIP |
| 100 | 930039 | NOISE SUPPRESSOR |
| 101 | 335857 | CHOKE COIL (A) BROWN |
| 102 | 324551 | CHOKE COIL (A) BLUE |
| 502 | 335273 | SIDE HANDLE |
| 503 | 303709 | DEPTH GAUGE |
| 605 | 948310 | RETAINING RING FOR D30 SHAFT |
| 607 | 959150 | STEEL BALL D6.35 (10 PCS.) |
| 654 | 981122 | SPECIAL SCREW M6X22 |
| 678 | 335781 | GREASE FOR ROTARY HAMMER (500G) |
| 679 | 335782 | GREASE FOR ROTARY HAMMER (60G) |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
