Hitachi Spare Parts for Demolition Hammer DH52MEY

€19.79
Tax included

Hitachi Spare Parts for Demolition Hammer DH52MEY

Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Demolition Hammer DH52MEY.
ITEM CODE: 308471
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Hitachi Spare Parts for Demolition Hammer DH52MEY

Hitachi-HIKOKI Tanaka

 authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Demolition Hammer DH52MEY.

In the following table, look for the model of the Demolition Hammer and the respective parts of the code.
Hitachi DH52MEY

Demolition Hammer DH52MEY
# Part Num. Description
1 337562 FRONT CAP
2 318590 STOPPER RING
3 338155 RETAINER WASHER
4 339053 RETAINER DAMPER (A)
5 338154 GRIP
6 338153 BIT LOCK HOLDER
7 339051 THRUST PLATE
8 339052 RETAINER SPRING
9 337557 SPRING HOLDER (A)
10 872470 O-RING (S-26)
11 338198 CYLINDER CASE COVER
13 318582 RETAINING RING D40
14 338200 RETAINING RING D68
15 339063 BALL BEARING 6008DDU
16 338201 BEARING WASHER
17 318588 OIL SEAL (NBR710)
18 338199 CYLINDER CASE
20 338222 O-RING (C)
21 338204 RETAINER DAMPER HOLDER
22 338203 RETAINER DAMPER (B)
23 339064 DAMPER SLEEVE
24 338202 RETAINER DAMPER WASHER
25A 370654 BIT LOCK
26 338205 RETAINER SLEEVE
27 338210 NEEDLE PIN D8
28 986104 O-RING
29 338206 SECOND HAMMER
30 338207 DAMPER WASHER
31 328887 DAMPER
32 338208 DAMPER HOLDER
33 338209 CYLINDER
34 338214 STRIKER
35 328880 O-RING
36 338211 SPRING HOLDER (B)
37 338216 LOCK SPRING WASHER
38 338217 LOCK SPRING
39 338215 LOCK SLEEVE
40 338212 CLUTCH SPRING
41 338213 CLUTCH
42 338218 SLEEVE
43 338235 SLIDER
44 338219 METAL (A)
45 338220 METAL WASHER
46 338221 BEVEL GEAR
47 328880 O-RING
49 328877 PISTON
50 328878 CONNECTING ROD
51 944954 BEARING WASHER
52 6201VV BALL BEARING 6201VV
54 340899 STATOR SENSOR PCB SET 220V-240V
55 338168 HOUSING
56 333225 DUST SEAL
57 339065 PACKING (B)
58 338170 TAIL COVER
60 6202DD BALL BEARING 6202DD
61 980700 DUST WASHER (B)
62 360992 ROTOR
63 338189 CONTROLLER ASS'Y 220V-240V
64 339056 RUBBER SHEET (C)
65 339055 RUBBER SHEET (A)
66 339057 RUBBER SHEET (D)
67 338184 PANEL ASS'Y
69 991711 DISTANCE PIECE (B)
70 338173 HANDLE (A)
71 338181 FILTER PCB ASS'Y 220V-240V
72 310123 TRANSATORY UNIT
73 310124 HANDLE DAMPER
74 338162 HANDLE DAMPER HOLDER
75 338176 BELLOWS
76 337588 TRIGGER
77 337587 SWITCH
78 338174 HANDLE (B)
80 339058 FILTER PACKING
82 940778 CORD ARMOR D10.7
83 960266 CORD CLIP
86 338175 HANDLE SHAFT
87 338197 BACK COVER
90 338171 ON LOCK BUTTON
91 338172 ON LOCK SPRING
92 338185 ON LOCK PCB (A) ASS'Y
93 339059 PACKING (A)
94 330209 SIDE HANDLE
95 337577 WING BOLT
96 949859 ROLL PIN D2X8
97 338239 MOUNT
98 949556 NUT M6
99 333227 HANDLE BOLT
100 338238 BAND
101 939542 RETAINING RING FOR D12 SHAFT
102 338224 CRANK SHAFT
103 328869 FEATHER KEY 3X3X25
104 948227 RETAINING RING FOR D47 HOLE
105 6204DD BALL BEARING 6204DD
106 338227 O-RING (F)
107 949859 ROLL PIN D2X8
108 339112 WEIGHT DAMPER
109 339067 WEIGHT ASS'Y
110 338191 WASHER
111 338179 ON LOCK PCB (B)
112 338192 WEIGHT PIN
114 338187 LEAF SPRING (B)
115 328906 SPRING HOLDER
116 338190 BASE
117 338194 WEIGHT BUMPER
119 339050 FELT PACKING (D)
120 338237 CRANK COVER
122 338159 CHANGE LEVER
123 337567 LEVER SPRING
124 959149 STEEL BALL D4.76
125 878885 O-RING (S-18)
126 338236 LEVER SHAFT HOLDER
127 939547 RETAINING RING FOR D20 SHAFT
128 338160 O-RING (A)
129 338234 CHANGE PLATE
131 339062 FELT PACKING (C)
132 339061 CAP SCREW
133 995396 VALVE
134 328867 OIL SEAL
135 338223 CRANK CASE
136 338242 SLIP CLUTCH ASS'Y
137 338229 BEVEL PINION
138 944109 FEATHER KEY 3X3X8
139 338230 COLLAR
140 6202DD BALL BEARING 6202DD
141 313058 WASHER
142 338231 WASHER (A)
143 318554 GEAR HOLDER
144 313057 NEEDLE PIN D6X6
145 329095 SPRING (C)
146 338232 SECOND GEAR
147 338233 SPACER
148 629VVM BALL BEARING 629VV
149 338225 FIRST GEAR
150 338226 SECOND PINION
151 629VVM BALL BEARING 629VV
152 944525 BEARING WASHER (C)
153 338240 SEAL PACKING
155 338241 GEAR COVER
501 981840 GREASE (A) FOR HAMMER.HAMMER DRILL (30G)
502 339066 CASE
601 308471 GREASE FOR HAMMER.HAMMER DRILL (70G)
602 980927 GREASE FOR HAMMER.HAMMER DRILL (500G)
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Hitachi DH52MEY
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 7/10 BUSINESS DAYS APPROX
MORE INFO:
info@bricoutensili.com
New

Download

Diagram Hitachi DH52MEY

Diagram Hitachi DH52MEY

Download (583.34KB)
