at attractive and competitive prices on the web, we are a licensed service center with a repair service able to quickly solve the maintenance or repair any issues for Planer P20SA2.
In the following table, look for the model of the Planer and theirs spare part.![]()
| PLANER P20SA2 | ||
| # | Part Num. | Description |
| 1 | 958709 | SPRING |
| 2 | 958708 | RUBBER PACKING |
| 3 | 958831Z | FRONT BASE |
| 4A | 316417 | SCALE |
| 5 | 942328 | KNOB |
| 7 | 990658 | HOUSING ASS'Y |
| 8 | 999041 | CARBON BRUSH (1 PAIR) |
| 9 | 955203 | BRUSH HOLDER |
| 10 | 958838Z | COVER |
| 11 | 949453 | SPRING WASHER M4 (10 PCS.) |
| 12 | 949217 | MACHINE SCREW M4X12 (10 PCS.) |
| 13 | 958839Z | MAGNET |
| 14A | 335760 | BLADE COVER |
| 15 | 958835Z | TAIL COVER |
| 16 | 307811 | TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 17 | 958836Z | CHIP GUIDE |
| 18 | 6201VV | BALL BEARING 6201VVCMPS2L |
| 19 | 316418 | CUTTER BLOCK ASS'Y (W/B.B) |
| 20 | 629VVM | BALL BEARING 629VVC2PS2L |
| 21 | 958915 | WASHER (A) |
| 22 | 958824Z | SHAFT (B) |
| *23 | 314746 | PLANER BLADES 82MM (1 PAIR) |
| 24 | 314754 | SET PLATE (A) |
| 25 | 949423 | WASHER M4 (10 PCS.) |
| 26 | 949213 | MACHINE SCREW M4X5 (10 PCS.) |
| 27 | 958850Z | BLADE HOLDER (1 PAIR) |
| 28 | 990669 | BOLT (W/WASHER) M6X18 |
| 29 | 314740 | SET PLATE (B) (1 PAIR) |
| 30 | 6200VV | BALL BEARING 6200VVCMPS2L |
| *31 | 990652E | ARMATURE 220V-230V |
| 32 | 963712 | HEX. HD. TAPPING SCREW D4X65 |
| *33 | 990651E | STATOR ASS'Y 220V-230V |
| *34 | 941615 | BRUSH TERMINAL |
| 35 | 608VVM | BALL BEARING 608VVC2PS2L |
| 36 | 963227 | BEARING LOCK |
| 38 | 958844Z | PLATE |
| 39A | 984750 | TAPPING SCREW (W/FLANGE) D4X16 |
| 40 | 958833Z | REAR BASE |
| 41 | 954004 | TAPPING SCREW D4X16 |
| 42 | 307028 | TAPPING SCREW (W/FLANGE) D4X25 (BLACK) |
| 43 | 958830Z | BELT COVER |
| 44A | 317747 | BELT |
| 45 | 990661 | PULLEY (B) |
| 46 | 990660 | PULLEY (A) |
| 47 | 990659 | END BRACKET |
| 48 | 958854Z | HANDLE COVER |
| 49 | 305499 | MACHINE SCREW (W/WASHER) M3.5X6 |
| *50 | 957747 | SWITCH (A) (1P SCREW TYPE) W/LOCK |
| *50 | 963756Z | SWITCH (2P PILLAR TYPE) W/SAFETY LOCK |
| 51 | 994273 | NOISE SUPPRESSOR |
| 52 | 981373 | TUBE (D) |
| 54 | 981373 | TUBE (D) |
| 55 | 959144 | TERMINAL 50051 (10 PCS.) |
| 56 | 959140 | CONNECTOR 50091 (10 PCS.) |
| 57 | 984750 | TAPPING SCREW (W/FLANGE) D4X16 |
| 58 | 937631 | CORD CLIP |
| 59 | 303662 | CORD ARMOR D8.8 |
