Hitachi Spare Parts for Router M12VE
€11.16
Tax included
Hitachi Spare Parts for Router M12VE
We are Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Router M12VE.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Router M12VE
We are Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Router M12VE.
In the following table, look for the model of the Routers and theirs spare part.
| Routers M12VE | ||
| # | Part Num. | Description |
| 1 | 331809 | TOP COVER |
| *2 | 930039 | NOISE SUPPRESSOR |
| 3 | 930804 | TERMINAL M4.0 (10 PCS.) |
| 4 | 959141 | CONNECTOR 50092 (10 PCS.) |
| 5 | 331823 | MARKER |
| 6 | 325196 | STOPPER POLE (A) |
| 7 | 301653 | TAPPING SCREW (W/FLANGE) D4X20 (BLACK) |
| *8 | 500234Z | CORD |
| 9 | 331811 | CONTROLLER 220/240V |
| 10 | 325475 | MAGNET |
| 11 | 954004 | TAPPING SCREW D4X16 |
| 12 | 331822 | MP HOLDER |
| 13 | 325169 | BEARING BUSHING |
| 14 | 325184 | RUBBER RING |
| *15 | 331989 | INTERNAL WIRE (BLUE) |
| 16 | 938307 | PILLAR TERMINAL |
| 17 | 980063 | TERMINAL |
| 18 | 937631 | CORD CLIP |
| 19 | 984750 | TAPPING SCREW (W/FLANGE) D4X16 |
| *20 | 953327 | CORD ARMOR D8.8 |
| *20 | 938051 | CORD ARMOR D10.1 |
| 22 | 6200VV | BALL BEARING 6200VVCMPS2L |
| 23 | 938477 | HEX. SOCKET SET SCREW M5X8 |
| 24 | 331813 | SWITCH HOLDER |
| 25 | 307887 | MACHINE SCREW (W/WASHER) M3.5X6 |
| *26 | 331812 | SWITCH (1P SCREW TYPE) |
| *27 | 331820 | SCALE |
| 28 | 945161 | BRUSH CAP |
| 29 | 999038 | CARBON BRUSH (1 PAIR) |
| 30 | 938241 | BRUSH HOLDER |
| 32 | 331825 | LABEL |
| 33 | 937623 | BRUSH TERMINAL |
| *34 | 340659J | STATOR ASS'Y 220V-230V |
| 35 | 961400 | HEX. HD. TAPPING SCREW D5X70 |
| 36 | 331814 | HOUSING ASS'Y |
| 37 | 325960 | LEVER |
| 38 | 331980 | FAN GUIDE |
| 40 | 325180 | SPRING GUIDE |
| 41 | 303316 | SPRING |
| 42 | 307443 | MACHINE SCREW (W/WASHERS) M6X30 (BLACK) |
| 43 | 331819 | HANDLE (A).(B) SET |
| 44 | 301806 | WING BOLT M6X15 |
| 45 | 331817 | END BRACKET |
| 46 | 323426 | FELT |
| 47 | 317200 | MACHINE SCREW (W/WASHERS) M4X8 (BLACK) |
| 48 | 962569 | WASHER (B) |
| 49 | 971858 | SPRING (A) |
| 50 | 302196 | MACHINE SCREW M5X20 (BLACK) |
| 51 | 331824 | SCREW M8 |
| 52 | 302197 | MACHINE SCREW M5X35 (BLACK) |
| 53 | 302012 | NUT M5 (BLACK) |
| 54 | 331826 | STOPPER BLOCK |
| 55 | 303317 | SPRING |
| 56 | 971848 | LOCK PIECE |
| 57 | 325187 | LOCK SCREW M10 |
| 58 | 323923 | LEVER (A) |
| 59 | 997314 | MACHINE SCREW (W/WASHERS) M6X10 |
| 60 | 307100 | TAPPING SCREW D5X50 |
| 61 | 6004VV | BALL BEARING 6004VVCMPS2L |
| 62 | 325186 | THRUST NUT |
| 63 | 325185 | BEARING COVER |
| 64 | 935196 | MACHINE SCREW (W/WASHERS) M4X12 (BLACK) |
| 65 | 325183 | LOCK SPRING (A) |
| 66 | 325182 | PUSHING BUTTON |
| *67 | 325199 | COLLET CHUCK 12MM |
| 68 | 331818 | BASE |
| 69 | 301810 | SUB BASE |
| 70 | 992013 | SEAL LOCK FLAT HD. SCREW M5X14 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s HITACHI websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to HITACHI brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
