Hitachi Spare Parts for Cordless Driver Drill DS18DSDL

€8.78
Tax included

Hitachi Spare Parts for Cordless Driver Drill DS18DSDL

Hitachi-HIKOKI Tanaka authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Cordless Drill DS18DSDL.
ITEM CODE: 306952
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Hitachi Spare Parts for Cordless Driver Drill DS18DSDL

Hitachi-HIKOKI Tanaka authorized service center

 and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Cordless Drill DS18DSDL.

In the following table, look for the model of the Cordless Drill and theirs spare part.
Hitachi DS18DSDL<

CORDLESS DRIVER DRILL DS18DSDL
# Part Num. Description
1 330588 SPECIAL SCREW (LEFT HAND) M6X27
2 752065 DRILL CHUCK 13VLRL-N (W/O CHUCK WRENCH)
3 334473 TAPPING SCREW (W/SP. WASHER)D3X20(BLACK)
4 334429 COVER (A)
5 334430 GEAR BOX ASS'Y
6 334431 DIAL HOLDER (A)
7 331881 NUT
8 334432 SPRING
9 334433 THRUST WASHER
10 334434 FRONT CASE
11 333516 CLICK SPRING
12 333539 PIN SET (6 PCS.)
13 331909 WASHER (A)
14 331903 LOCK RING (A)
15 331888 NEEDLE ROLLER SET (6PCS.)
16 331904 LOCK CAM
17 333517 CARRIER
18 333518 PLANET GEAR (C) SET (5 PCS.)
19 333519 RING GEAR
20 331892 WASHER (A)
21 331893 REAR CASE
22 331894 SHIFT ARM
23 330579 SCREW SET D2X3.5 (2 PCS.)
24 320087 SCREW SET M3X12 (4 PCS.)
25 331897 PINION (C)
26 333520 PLANET GEAR (B) SET (4 PCS.)
27 333521 SLIDE RING GEAR
28 335296 STOPPER (A)
29 333523 STOPPER SPRING
30 333524 PINION (B)
31 331926 NEEDLE BEARING SET (4 PCS.)
32 334441 PLANET GEAR (A) SET (4 PCS.)
33 334435 FIRST RING GEAR
34 322988 WASHER (B)
35 331902 MOTOR SPACER
36A 360975 ARMATURE AND PINION SET 18V
37 334442 MAGNET
38 334436 BRUSH BLOCK
39 999054 CARBON BRUSH 5X6X11.5 (1 PAIR)
40 319918 BRUSH CAP
41 334440 HOUSING (A).(B) SET
42 327001 TRUSS HD. SCREW M4 (BLACK)
43 332824 HOOK
44 327002 LOCK NUT M4 (BLACK)
45 328644 PACKING
46 334438 CONTROLLER TERMINAL SET
47 334443 FERRITE CORE
48 331907 PUSHING BUTTON
49 334267 SHIFT KNOB
50 333640 DC-SPEED CONTROL SWITCH
51 313687 TAPPING SCREW (W/FLANGE) D3X16 (BLACK)
53 306952 STRAP (BLACK)
54 330068 BATTERY BSL 1830 (EUROPE,AUS,NZL)
54 334421 BATTERY BSL 1840 (EUROPE,AUS,NZL)
501 323230 CASE
503 983006 + DRIVER BIT NO.2 65L
504 331906 SIDE HANDLE
505 329897 BATTERY COVER
506 336471 CASE ASS'Y (STACKABLE)
507 336472 LATCH
508 336473 HANDLE
509 336474 HINGE
510 336475 INNER TRAY
