Hitachi Spare Parts for Angle Grinder G12SA3
€4.18
Tax included
Hitachi Spare Parts for Angle Grinder G12SA3
Hitachi-HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Angle Grinder G 12SA3.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Angle Grinder G12SA3
Hitachi-HIKOKI Tanaka Authorized Technical Assistance, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Angle Grinder G 12SA3.
In the following table , look for the model of the grinder and the ripettivo spare part.
| Angle Grinder 115 mm G12SA3 | ||
| # | Part Num. | Description |
| 1 | 320523 | TAPPING SCREW D5X25 (BLACK) |
| 2 | 325053 | GUARD PLATE |
| 3 | 301944 | PUSHING BUTTON |
| 4 | 321737 | GEAR COVER ASS'Y |
| 5 | 949558 | NUT M8 (10 PCS.) |
| 7 | 308543 | SEAL RING (A) |
| 8 | 980866 | WASHER (C) |
| 9 | 629T12 | BALL BEARING 629T12DDC3PS2-L |
| 10 | 957754 | RUBBER RING |
| 11 | 321734 | BEARING COVER |
| 12 | 360734E | ARMATURE 230V-240V |
| 13 | 321732 | FAN GUIDE |
| 14 | 982021 | HEX. HD. TAPPING SCREW D4X70 |
| 15 | 340645E | STATOR 220V-230V |
| 16 | 315877 | DUST SEAL |
| 17 | 608VVM | BALL BEARING 608VVC2PS2L |
| 18 | 303255 | SEAL LOCK SCREW (W/SP. WASHER) M4X10 |
| 19 | 301943 | LOCK PIN |
| 21 | 991207 | SEAL LOCK SCREW (W/SP. WASHER) M4X8 |
| 22 | 936680 | BEARING COVER (B) |
| 23 | 6201DD | BALL BEARING 6201DDCMPS2L |
| 24 | 308546 | FELT PACKING |
| 25 | 308545 | PACKING GLAND |
| 26 | 307046 | SEAL LOCK SCREW (W/SP. WASHER) M5X16 |
| 27 | 944109 | FEATHER KEY 3X3X8 |
| 28 | 994301 | SPINDLE (A) |
| 28 | 994302 | SPINDLE (B) |
| 29 | 949241 | MACHINE SCREW M5X20 |
| 30 | 949454 | SPRING WASHER M5 |
| 31 | 319656 | WHEEL GUARD ASS'Y |
| 32 | 937817Z | WHEEL WASHER |
| 32B | 334456 | WHEEL WASHER (C) |
| 33 | 316821 | D. C. WHEELS 115MM A36Q |
| 34 | 994324 | WHEEL NUT M14 |
| 34 | 937923P | WHEEL NUT 5/8"-11UNC |
| 34A | 337329 | WHEEL NUT M14 |
| 35A | 329054 | BEVEL GEAR AND PINION SET |
| 36 | 314428 | SLIDE KNOB |
| 37 | 325050 | HOUSING |
| 38 | 321733 | RUBBER RING |
| 39A | 329057 | PUSHING BUTTON SWITCH |
| 40 | 930039 | NOISE SUPPRESSOR |
| 41 | 325051 | SLIDE BAR |
| 42 | 999088 | CARBON BRUSH (1 PAIR) |
| 43 | 317810 | BRUSH HOLDER |
| 44 | 308536 | SPRING |
| 45 | 325054 | SWITCH HOLDER |
| 46 | 980063 | TERMINAL |
| 47 | 984750 | TAPPING SCREW (W/FLANGE) D4X16 |
| 48 | 937631 | CORD CLIP |
| 49 | 953327 | CORD ARMOR D8.8 |
| 51 | 301815 | TAPPING SCREW (W/FLANGE) D4X45 (BLACK) |
| 53 | 325052 | TAIL COVER |
| 55 | 319320 | FASTON TERMINAL |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
