Hitachi Spare Parts for Angle Grinder G12SQ

€4.18
Tax included

Hitachi Spare Parts for Angle Grinder G12SQ

Hitachi-HIKOKI Tanaka authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Angle Grinder G 12SQ.
ITEM CODE: 301943
Quantity
on 7/10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Hitachi Spare Parts for Angle Grinder G12SQ

Hitachi-HIKOKI Tanaka authorized service center

and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Angle Grinder G 12SQ.

In the following table , look for the model of the grinder and the ripettivo spare part.
Hitachi G12SQ

Angle Grinder 115 mm G12SQ
# Part Num. Description
1 307028 TAPPING SCREW (W/FLANGE) D4X25 (BLACK)
2 301944 PUSHING BUTTON
3 332529 GEAR COVER ASS'Y
4 309191 SPECIAL NUT M6
5 628VVC BALL BEARING 628VVC2PS2-L
6 327887 BEARING HOLDER
*7 360891F ARMATURE 230V
8 332527 FAN GUIDE
9 982021 HEX. HD. TAPPING SCREW D4X70
*10 340771J STATOR 230V-240V
11 321722 DUST SEAL
12 626VVM BALL BEARING 626VVC2PS2L
13 309929 RUBBER BUSHING
14 301943 LOCK PIN
15 987201 SEAL LOCK SCREW (W/SP. WASHER) M4X10
16 316490 BEARING COVER
17 6201VV BALL BEARING 6201VVCMPS2L
18 301946 FELT PACKING
19 316489 PACKING GLAND
20 987203 SEAL LOCK SCREW (W/SP. WASHER) M4X12
21 302047 WOODRUFF KEY
*22 332536 SPINDLE
*22 332537 SPINDLE
23 308386 MACHINE SCREW (W/SP. WASHER) M5X16(BLACK
24 301949 SET PLATE
25 315492 WHEEL GUARD ASS'Y
*26 937817Z WHEEL WASHER
26A 334456 WHEEL WASHER (C)
27 316821 D. C. WHEELS 115MM A36Q (25 PCS.)
*28 994324 WHEEL NUT M14
*28 937923P WHEEL NUT 5/8"-11UNC
28A 337329 WHEEL NUT M14
29 327888 GEAR SET
30 332525 HOUSING ASS'Y
32 959140 CONNECTOR 50091 (10 PCS.)
33 980063 TERMINAL
34 938307 PILLAR TERMINAL
*35 332524 TAIL COVER (B)
*35 332523 TAIL COVER (B)
36 305490 TAPPING SCREW (W/FLANGE) D4X30 (BLACK)
37 301653 TAPPING SCREW (W/FLANGE) D4X20 (BLACK)
38 305499 MACHINE SCREW (W/WASHER) M3.5X6
39 314603 SWITCH (1P SOLDER TYPE)
40 317491 NOISE SUPPRESSOR
*41 959140 CONNECTOR 50091 (10 PCS.)
42 332545 INTERNAL WIRE
43 980063 TERMINAL
44 937631 CORD CLIP
45 984750 TAPPING SCREW (W/FLANGE) D4X16
47 999005 CARBON BRUSH (1 PAIR)
48 328210 TAPPING SCREW D3X8
49A 333844 BRUSH HOLDER
50 332531 SPRING
51 333136 PIN (A) D2.5
52 332581 OFF LOCK PLATE
53 314429 SPRING
54 332580 SWITCH PLUNGER
55 332530 OFF LOCK LEVER
56 332582 SWITCH LEVER
*57 332522 TAIL COVER (A)
*57 332521 TAIL COVER (A)
58 332534 SPRING (A)
59 332535 PIN D2.5
60 332533 ON LOCK BUTTON
*61 953327 CORD ARMOR D8.8
*61 938051 CORD ARMOR D10.1
