Hitachi Spare Parts for Engine Chainsaw CS33EDT
€62.43
Tax included
Hitachi Spare Parts for Engine Chainsaw CS33EDT
Hitachi-HIKOKI Tanaka original spare parts, at discounted prices, we are a licensed service center with after-sales service able to quickly solve the maintenance and repair any issues for Pruning Chainsaw CS33EDT.Chainsaw for Pruning, light and powerful 3.4kg. It has a 32.2 cc engine with Walbro carburetor
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Engine Chainsaw CS33EDT
Hitachi-HIKOKI Tanaka original spare parts, at discounted prices, we are a licensed service center with after-sales service able to quickly solve the maintenance and repair any issues for Pruning Chainsaw CS33EDT.
In the following table, look for the model of the chainsaw and ripettivo spare part.
| ENGINE CHAINSAW CS33EDT | ||
| # | Part Num. | Description |
| 1 | 6685225 | AIR CLEANER BASE |
| 2 | 949824 | HEX. SOCKET HD. BOLT M5X45 (10 PCS.) |
| 3 | 6696826 | CLEANER SPONGE (B) |
| 4 | 6685230 | CLEANER ELEMENT A COMP. |
| 5 | 6685231 | CLEANER ELEMENT B COMP. |
| 6 | 6696825 | CLEANER SPONGE (A) |
| 7 | 6696785 | CLEANER COVER |
| 8 | 6696786 | CLEANER KNOB |
| 9 | 305812 | TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 10 | 6696821 | MUFFLER COVER |
| 11A | 6600316 | CLUTCH ASSY |
| 12 | 6698856 | CLUTCH HOUSING |
| 13 | 6685361 | NEEDLE BEARING (D) |
| 14 | 6685414 | CLUTCH WASHER |
| 15 | 6685360 | CRANK SHAFT COLLAR |
| 16 | 6696789 | OIL PUMP COVER |
| 17 | 6685356 | NEEDLE ROLLER 2.5X19.8 |
| 18 | 6685354 | PUMP GEAR |
| 19 | 6685355 | PUMP GEAR SPRING |
| 20A | 6699119 | PUMP CASE |
| 21A | 6699120 | PUMP ASS'Y |
| 22 | 6685136 | SEAL LOCK BOLT M5X15 |
| 23 | 6698849 | INTAKE PACKING |
| 24 | 6696794 | INTAKE MANIFOLD |
| 25A | 6698792 | HEX. SOCKET BOLT M4 |
| 26 | 6685203 | PULSE GUIDE |
| 27 | 6696812 | ENGINE CASE COVER |
| 28 | 6696792 | CLEANER BODY |
| 30 | 6696795 | CARBURETOR ASS'Y |
| 31 | 6698857 | INLET SPACER |
| 32 | 6685210 | SCREW |
| 33 | 6685211 | PUMP BODY |
| 34 | 6685212 | PUMP GASKET |
| 35 | 6685213 | PUMP DIAPHRAGM |
| 36 | 6684700 | INLET SCREEN |
| 37 | 6685215 | NEEDLE VALVE |
| 38 | 6685216 | VALVE SPRING |
| 39 | 6685217 | CONTROL LEVER |
| 40 | 6685297 | IDLE ADJUST SPRING |
| 41 | 6685298 | IDLE ADJUST SCREW |
| 42 | 6685218 | HINGE PIN SET SCREW |
| 43 | 6685219 | HINGE PIN |
| 44 | 6685220 | DIAPHRAGM PACKING-METERING |
| 45 | 6684690 | METERING DIAPHRAGM |
| 46 | 6685222 | DIAPHRAGM COVER-METERING |
| 47 | 6685223 | SET SCREW |
| 48 | 6696793 | IDOL SPONGE |
| 49 | 6685206 | CHOKE LEVER |
| 50 | 6698699 | PROTECTIVE COIL |
| 51 | 6698850 | FUEL PIPE 2.5X4X47 |
| 52 | 6685139 | PRIMING PUMP COMP. |
| 53 | 6685371 | AIR VENT SPONGE |
| 54 | 6685370 | AIR VENT VALVE (B) |
| 55 | 6696811 | OIL PIPE |
| 56 | 6685358 | PIPE JOINT |
| 57 | 6698456 | FLANGED TAPPING SCREW D5X15 |
| 58 | 6685363 | CHAIN CATCHER |
| 59A | 6696807 | ENGINE CASE ASS'Y |
| 60 | 935196 | MACHINE SCREW (W/WASHERS) M4X12 (BLACK) |
| 61 | 6696816 | EXHAUST PIPE |
| 62 | 6696818 | MUFFLER SPECIAL PACKING |
| 63 | 6696817 | GAUZE FIXING PLATE |
| 64 | 6696815 | MUFFLER GAUZE |
| 65 | 6696814 | MUFFLER |
| 66A | 6600414 | MUFFLER PACKING |
| 67 | 949812 | HEX. SOCKET HD. BOLT M4X10 (10 PCS.) |
| 68 | 6696766 | SCAVENGING COVER (B) |
| 70 | 6696819 | HEX. SOCKET HD. BOLT M6X55 |
| 71 | 949432 | BOLT WASHER M6 (10 PCS.) |
| 72 | 6698853 | CRANK WORM ASS'Y |
| 73 | 6685330 | WORM |
| 74 | 6685329 | OIL SEAL |
| 75 | 6685328 | BALL BEARING |
| 76 | 6696762 | CRANK SHAFT |
| 77 | 6696767 | CRANK CASE |
| 78 | 6698386 | HEX. SOCKET HD. BOLT (W/SP.WASHER) M5X18 |
| 79 | 6685326 | CIRCLIP |
| 80 | 6698806 | PISTON (M) |
| 81 | 6685331 | PISTON RING (XR1-1856) |
| 82 | 6696764 | PISTON PIN |
| 83 | 6685103 | BOLT WASHER M7 |
| 84 | 6685104 | FLYWHEEL NUT |
| 85 | 6685336 | RETAINING RING D4 |
| 86A | 6600053 | MAGNETO ROTOR COMP. |
| 87 | 6685335 | STARTER PAWL SPRING |
| 88 | 6685334 | STARTER PAWL |
| 89A | 6600090 | MAGNETO SUB ASS'Y |
| 90A | 6685351 | INNER CAP |
| 91 | 6685179 | TANK CAP PACKING |
| 92 | 6698854 | FUEL TANK CAP ASS'Y (VERMILION) |
| 93 | 6696761 | CYLINDER |
| 94 | 6685782 | SPARK PLUG BPMR7A |
| 95A | 6699999 | IGNITION COIL |
| 96 | 6698700 | GLASS WASHER |
| 98 | 6696765 | SCAVENGING COVER (A) |
| 99 | 6696772 | METAL FITTING OF PLUG CAP (A) |
| 100A | 6696787 | CORD (A) |
| 101 | 6696771 | SPARK PLUG CAP |
| 102A | 6696791 | CORD (B) |
| 103A | 6696326 | HEX. SOCKET HD. BOLT (W/FLANGE) M4X18 |
| 104 | 6685226 | WASHER M5 (BLACK) |
| 105 | 6698864 | CAUTION LABEL (HOT) |
| 106 | 6698787 | GROMMET |
| 107 | 6698860 | PROTECTION SHEET |
| 108 | 6698861 | PACKING PLATE |
| 109 | 6698862 | MUFFLER SPECIAL PACKING (S) |
| 110 | 6684899 | WOODRUFF KEY 3X13X4.5 |
| 111 | 6698863 | CORD INSULATION TUBE |
| 112 | 6698358 | FUEL TANK CAP ASS'Y (BLACK) |
| 121A | 6699403 | TAPPING SCREW (W/FLANGE) D5X40 |
| 122 | 6698858 | WASHER 1.0 |
| 123 | 6696800 | COLLAR 28.2 |
| 124 | 6696775 | DAMPER |
| 125 | 6696774 | REAR HANDLE (B) |
| 126A | 6685244 | TRIGGER LOCKOUT |
| 127 | 6696797 | THROTTLE WIRE |
| 128 | 6696940 | STOP SWITCH |
| 129 | 6698449 | NUT M6 |
| 130 | 6698691 | THROTTLE LEVER SPRING |
| 131 | 6685242 | THROTTLE LEVER |
| 132 | 6698409 | SPRING HOLDER |
| 133 | 6698859 | DAMPER SET BOLT |
| 134 | 6698428 | ANTIVIBRATION SPRING |
| 136 | 6698581 | FLANGE NUT M8 |
| 137A | 6696776 | SIDE CASE (VERMILION) |
| 138 | 6696782 | BRAKE SUPPORT PLATE |
| 139 | 6696783 | BRAKE LEVER SPRING |
| 140 | 6685388 | BRAKE LINK |
| 141 | 6685140 | BRAKE BAND - DISCONTINUED |
| 142 | 6685391 | NEEDLE ROLLER D3 |
| 143 | 6685389 | BRAKE SPRING |
| 144A | 6698986 | CHAIN PULLER |
| 145 | 6696784 | GUIDE PLATE (B) |
| 146 | 696352 | TAPPING SCREW D3 |
| 147 | 958715 | TAPPING SCREW D4X10 |
| 148A | 6697852 | SAW CHAIN(3/8X12")91PX-45XJ |
| 148A | 6697854 | SAW CHAIN (3/8X14") 91PX-52XJ |
| 149 | 6696990 | CHAIN BAR 12 INCH 3/8 SPROCKET PRC |
| 149 | 6696991 | CHAIN BAR 14 INCH 3/8 SPROCKET PRC |
| 150 | 6698715 | FUEL PIPE |
| 151 | 6696827 | SPIKE SET |
| 152 | 6698851 | FUEL PIPE (FKM) L240 |
| 154 | 6698852 | FUEL PIPE (FKM) L260 |
| 155 | 6696167 | FUEL GROMMET |
| 156 | 6696773 | REAR HANDLE (A) |
| 157A | 6600026 | D5 TAPPING SCREW W/F |
| 158A | 6696798 | FRONT HANDLE - DISCONTINUED |
| 159 | 6698866 | BRAKE HANDLE |
| 161 | 6696779 | BRAKE LINK COVER |
| 162 | 6685199 | PUMP FILTER BODY |
| 163 | 6685311 | CLIP |
| 164 | 6685310 | OIL FILTER BODY |
| 165 | 6696804 | OIL FILTER |
| 166 | 6685407 | BOLT WASHER D5 |
| 167 | 6696790 | AIR DEFLECTOR |
| 168B | 6699417 | RECOIL STARTER CPL 175-177-185-186 |
| 169 | 302086 | TAPPING SCREW (W/FLANGE) D4X20 (BLACK) |
| 171 | 6698457 | CORD INSULATION TUBE |
| 172 | 6698865 | SPRING COVER |
| 173 | 6685308 | FUEL GROMMET (A) |
| 174 | 6699404 | GROMMET (A) |
| 175 | 6699475 | SET SCREW |
| 176 | 6699483 | REEL |
| 177 | 6699480 | SPIRAL SPRING CASE |
| 178 | 6699476 | SET SCREW |
| 179 | 6699478 | CAM PLATE - DISCONTINUED |
| 180 | 6699479 | DAMPER SPRING |
| 181 | 6699484 | REEL |
| 182 | 6699469 | STARTER ROPE |
| 183 | 6699465 | ROPE STOPPER |
| 184 | 6699467 | STARTER KNOB |
| 185 | 6699473 | STARTER HANDLE ASS'Y |
| 186 | 6699490 | FAN CASE |
| 187 | 6699947 | TAPPING SCREW (W/FLANGE) D4 |
| 501 | HGA781122 | CHAIN x Bar cm 30-3/8" LP-45 Maglie |
| 502 | HGA781124 | CHAIN per Bar cm 35-3/8" LP-52 Maglie |
| 503 | HGA781232 | BAR + CHAIN set cm 30-3/8" LP-45 Maglie |
| 504 | HGA781234 | BAR + CHAIN set cm 35-3/8" LP-52 Maglie |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
