Hitachi Spare Parts for Electric Saw CS 35Y
We are Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Electric Chainsaw CS 35Y.
In the following table, look for the model of the Electric Saw and their spare part.
| Electric Chain Saw CS 35Y | ||
| # | Part Num. | Description |
| 3 | 696352 | TAPPING SCREW D3 |
| 4 | 335471 | GUIDE PLATE |
| 5 | 335470 | SIDE COVER (R) |
| 6 | 335688 | DUST SHEET |
| 7 | 996407 | O-RING (1AP-12) |
| 8 | 939543 | RETAINING RING FOR D14 SHAFT |
| 9 | 335150 | TENSION DIAL |
| 10 | 335151 | KNOB |
| 12 | 335152 | TENSION GEAR |
| 15 | 335472 | INNER COVER |
| 16 | 335482 | SPIKE BAR |
| 18 | 997218 | O-RING (S-6) |
| 24 | 335484 | WASHER (E) |
| 25 | 335485 | SPRING WASHER |
| 26 | 335486 | COLLAR (B) |
| 29 | 335487 | WASHER (C) |
| 30 | 335488 | WASHER (D) |
| 32 | 335966 | CHAIN PULLER |
| 33 | 335479 | BRAKE HANDLE |
| 34 | 335483 | SPRING (C) |
| 35 | 335480 | SWITCH ROD |
| 36 | 335144 | TANK CAP |
| 37 | 335691 | TANK CAP PACKING |
| 38 | 335477 | SIDE COVER (L) |
| 39 | 335490 | GASKET |
| 40 | 335474 | OIL PUMP ASS'Y |
| 41 | 335476 | GEAR CASE |
| 42 | 335967 | ADJUSTING BOLT |
| 43 | 981317 | O-RING (S-4) |
| 44 | 335473 | SPINDLE GEAR ASS'Y |
| 45 | 606ZZM | BALL BEARING 606VV |
| 46 | 6202VV | BALL BEARING 6202VVCMPS2L |
| 47 | 360957E | ARMATURE AND PINION SET 220V-230V |
| 48 | 6301VV | BALL BEARING 6301VVCMPS2L |
| 50 | 6000VV | BALL BEARING 6000VVCMPS2L |
| 51 | 335481 | FAN GUIDE |
| 53 | 340864E | STATOR ASS'Y 220V-230V |
| 54 | 335478 | FRONT HANDLE |
| 56 | 307811 | TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 57 | 335475 | HANDLE SET |
| 58 | 335469 | HOUSING ASS'Y |
| 60 | 945161 | BRUSH CAP |
| 61 | 999065 | CARBON BRUSH (1 PAIR) |
| 62 | 938241 | BRUSH HOLDER |
| 66 | 335455 | CONTROLLER 200V-240V |
| 67 | 335463 | TRIGGER |
| 68 | 335464 | OFF LOCK BUTTON |
| 69 | 335465 | SPRING (A) |
| 70 | 335460 | MICRO SWITCH |
| 72 | 335453 | SWITCH |
| 73 | 953327 | CORD ARMOR D8.8 |
| 73 | 938051 | CORD ARMOR D10.1 |
| 74 | 937631 | CORD CLIP |
