Hitachi Chainsaw CS33EDP Parts
€1.09
Tax included
Hitachi Spare Parts for Engine Chainsaw CS33EDP
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Pruning Chainsaw CS33EDTP.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Engine Chainsaw CS33EDP
Hitachi-HIKOKI Tanaka authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Pruning Chainsaw CS33EDP.
In the following table, look for the model of the Chainsaw and ripettivo spare part.
| Chainsaw CS33EDP | ||
| ENGINE - CARBURETOR - OIL PUMP - CLUTCH - COIL | ||
| Pag.1 | ||
| # | Part Num | Description |
| 1 | 305812 | SCREW WITH BLACK D4X16 FLANGE |
| 2 | 6696821 | MUFFLER PROTECTION |
| 3 | 6698864 | CAUTION LABEL (HOT) NEW |
| 4 | 6699969 | UPPER AIR FILTER |
| 5 | 6699968 | LOWER AIR FILTER |
| 6 | 949824 | BOLT M5X45 T.E.I. (10PCS.) |
| 7 | 6685408 | WASHER |
| 8 | 6699966 | CLEANER SUPPORT |
| 9 | 6699976 | CARBURETOR INCLUDES 10-25 |
| 10 | 6685210 | SCREW |
| 11 | 6685297 | SPRING |
| 12 | 6685298 | IDLE ADJUSTMENT SCREW |
| 13 | 6685218 | SCREW |
| 14 | 6685219 | PIN ROCKER ARM |
| 15 | 6685220 | DISC GASKET |
| 16 | 6684690 | PUMPING MEMBRANE |
| 17 | 6685222 | COVER |
| 18 | 6685223 | SCREW |
| 19 | 6600091 | PUMP COVER |
| 20 | 6685212 | PUMPING MEMBRANE |
| 21 | 6685213 | FILTER SCREEN |
| 22 | 6684700 | NEEDLE |
| 23 | 6685215 | VALVE SPRING (OLD 477-25343-20) |
| 24 | 6685216 | ROCKER ARM |
| 25 | 6685217 | HEX. HOLE BOLT M4 NEW |
| 26 | 6698792 | COLLECTOR |
| 27 | 6699951 | COLLECTOR GASKET |
| 28 | 6699952 | SEAL LOCK HEX. SOCKET BOLT (W/WASHERS)M5 |
| 29 | 6699044 | CLUTCH COMPLETE |
| 30 | 6600316 | CLUTCH BELL 3/8 |
| 31 | 6685144 | ROLLER BEARING |
| 32 | 6685361 | WASHER |
| 33 | 6685414 | BUSHING |
| 34 | 6685360 | PUMP COVER |
| 35 | 6699610 | SELF-THREADING SCREW D4X20 BLACK |
| 36 | 302086 | PLUG |
| 37 | 6685356 | SPONGE |
| 38 | 6696793 | OIL PUMP ADJUSTER (ED) |
| 39 | 6699960 | ADJUSTER SPRING |
| 40 | 6699961 | M4 WASHER |
| 41 | 323210 | ADJUSTER CAP |
| 42 | 6699959 | NEEDLE ROLLER |
| 43 | 6600046 | OIL PUMP SHAFT |
| 44 | 6699957 | PUMP GEAR SPRING (ED) |
| 45 | 6699958 | PUMP BODY |
| 46 | 6699119 | OIL PUMP COMPLETE INCLUDES 37, 39-46 |
| 47 | 6600085 | OIL FILTER (SPONGE) |
| 48 | 6685371 | OIL PIPE |
| 49 | 6696811 | PIPE CONNECTOR |
| 50 | 6685358 | ENGINE CASE INCLUDES 64, 65, 172 |
| 51 | 6600084 | SCREW (W/WASHERS) M4 (BLACK) |
| 52 | 6600048 | MUFFLER PLATE |
| 53 | 6698861 | MUFFLER GASKET |
| 54 | 6698862 | MUFFLER PLATE |
| 55 | 6696816 | MUFFLER PLATE |
| 56 | 6696818 | MUFFLER PLATE |
| 57 | 6696817 | MUFFLER NET |
| 58 | 6696815 | MUFFLER |
| 59 | 6600049 | MUFFLER GUARD |
| 60B | 6600445 | HEX. SOCKET HD. BOLT M6X55 NEW |
| 61 | 6696819 | WASHER M6 |
| 62 | 949432 | TANK MARK LABEL (50:1) NEW |
| 63 | 6698921 | PROTECTION SHEET |
| 64 | 6600047 | MIX TANK BREATHER |
| 65 | 6685351 | MIX CAP (ORANGE) *6698358 INCLUDES 67 |
| 66 | 6698854 | CAP SEAL |
| 67 | 6685179 | OIL CAP (BLACK) INCLUDES 67 |
| 68 | 6698358 | BOLT M4X10 |
| 69 | 949812 | CYLINDER CAP (B) |
| 70 | 6696766 | MIX TUBE |
| 71 | 6698907 | *SEE 6685198 |
| 72 | 6685311 | CYLINDER |
| 74 | 6600083 | CORD INSULATION TUBE L100 |
| 75 | 6600051 | CORD INSULATION TUBE L60 |
| 76 | 6699175 | SPARK PLUG CAP |
| 77 | 6696771 | CORD |
| 78 | 6600052 | HEX SCREW M4 |
| 79 | 6696326 | METAL FITTING OF PLUG CAP (A) NEW |
| 80 | 6696772 | PLASTIC WASHER |
| 81 | 6698700 | IGNITION COIL |
| 82 | 6699977 | CORD (A) |
| 83 | 6699948 | CYLINDER CAP (A) |
| 84 | 6696765 | LOCK PIN |
| 85 | 6685326 | PISTON |
| 86 | 6698806 | PISTON RING |
| 87 | 6685331 | PISTON PIN |
| 88 | 6696764 | CRANKSHAFT-BEARINGS-OIL SEAL INCLUDES 90-93 |
| 89 | 6698853 | PUMP GEAR |
| 90 | 6685330 | OIL SEAL |
| 91 | 6685329 | BEARING |
| 92 | 6685328 | CRANKSHAFT W/ BEARING |
| 93 | 6696762 | WOODRUFF KEY |
| 94 | 6684899 | HEX. SOCKET HD BOLT M5X18 (W/SP.WAS |
| 95 | 6698386 | CRANK CASE NEW MAR |
| 96 | 6696767 | FLYWHEEL W/ PAWLS INCLUDES 98-101 |
| 97 | 6600090 | E-RING D4E |
| 98 | 6685336 | MAGNETO ROTOR COMP. |
| 99 | 6600053 | STARTER HOOK SPRING |
| 100 | 6685335 | STARTER PAWL |
| 101 | 6685334 | STARTER RATCHET |
| 102 | 6696880 | WASHER |
| 103 | 6696879 | FLYWHEEL NUT |
| 104A | 6600346 | GUIDE PLATE |
| 105 | 958715 | SELF-THREADING SCREW D.4X10 |
| STARTER-GRIPS-CHAIN BRAKE-HANDGUARD-BAR and CHAIN | ||
| Pag.2 | ||
|
3
|
6698864
|
CAUTION LABEL (HOT) NEW |
|
36
|
302086
|
SELF-THREADING SCREW D4X20 BLACK |
|
62
|
949432
|
M6 WASHER |
|
121
|
6600088
|
CHAIN HOUSING |
|
122
|
6696782
|
BRAKE LEVER SUPPORT |
|
123
|
6696783
|
BRAKE LEVER SPRING |
|
124
|
6699972
|
HAND GUARD |
|
126
|
6696779
|
BRAKE HOUSING |
|
127
|
6600071
|
NAME PLATE (EURO.A) CS33EDP |
|
128
|
6600057
|
BLADE FIXING NUT |
|
129
|
6600058
|
NUT HOLDER |
|
130
|
6698986 | CHAIN TENSIONER |
|
131
|
6696784 | GUIDE PLATE |
|
132
|
781124
|
CHAIN PACK 3/8 LP 1.3 52M |
|
132
|
781126
|
CHAIN PACK 3/8 LP 1.3 57M |
|
133
|
Bar + Chain Set cm 30 12'' - 3/8'' LP - 45 M. 1,3 mm/0.50'' | |
|
133
|
Bar + Chain Set cm 40 16'' - 3/8'' LP - 57 M. 1,3 mm/0.50'' | |
|
134
|
958715
|
SELF-TAPPING SCREW D.4X10 |
|
135
|
696352 | D3 SCREW |
|
136
|
6600054
|
BRAKE SPRING |
|
137
|
6685388
|
BRAKE CONNECTION |
|
138
|
6685140
|
BRAKE SPRING |
|
139
|
6685391 | PIN |
|
140
|
305812
|
BLACK D4X16 FLANGE SCREW |
|
141
|
6699970
|
AIR FILTER COVER |
|
142
|
6699971
|
AIR FILTER KNOB |
|
143
|
6699965
|
REAR HANDLE GRIP |
|
144
|
6685350
|
SAFETY LEVER |
|
145A
|
6600341
|
THROTTLE LEVER SPRING |
|
146
|
6685282
|
PLUG |
|
147A
|
6601275
|
STOP SWITCH |
|
148
|
6600082
|
START LABEL (CS33ED) EX |
|
150
|
6696327
|
SHOCK ABSORBER |
|
151
|
696314
|
*SEE HGR696314 |
|
152
|
6685413
|
BOLT |
|
153
|
6685206
|
CHOKE LEVER |
|
154
|
6699964
|
THROTTLE ROD (ED) |
|
155
|
6698787
|
GROMMET NEW |
|
156
|
6698916
|
THROTTLE TRIGGER |
|
157
|
6699974
|
ENGINE CASE COVER |
|
158
|
6698787
|
GROMMET NEW |
|
159
|
6698409
|
DAMPER SPRING CONNECTOR |
|
160
|
6699962
|
DAMPER SET BOLT (A) |
|
161
|
6698428
|
DAMPER SPRING |
|
162
|
6696167
|
MIXTURE RUBBER |
|
163
|
6699975
|
FUEL PIPE |
|
164
|
6600055
|
FUEL PIPE L220 |
|
165
|
329934
|
M6 FLANGED NUT |
|
166
|
6699963
|
REAR HANDLE |
|
167
|
6600056
|
IDLE SPONGE |
|
168
|
6685267 | MIX TUBE |
|
169
|
6685139 | PRIMER |
|
170
|
6600047
|
PROTECTION SHEET |
|
171
|
6685308 | MIX TUBE RUBBER |
|
172
|
6685370 | RUBBER |
|
173
|
6698456
|
D5X15 SCREW |
|
174
|
6699973
|
SPIKE |
|
175
|
6698456
|
D5X15 SCREW |
|
176
|
6699950
|
CHAIN CATCHER |
|
177A
|
6600351
|
MIXTURE FISHING UNIT |
|
178
|
6685311
|
*SEE 6685198 |
|
179
|
6685310 | FISHING UNIT OIL |
|
180
|
6696804
|
*SEE HGR6690919 |
|
181
|
6685407
|
M5 WASHER |
|
182
|
6698715
|
RUBBER TUBE |
|
183
|
6600061
|
STARTER HANDLE INCLUDES 184-186 |
|
184
|
6699465
|
ROPE STOPPER |
|
185
|
6699467
|
STARTER KNOB |
|
186
|
6600060
|
STARTER ROPE (NS) |
|
187
|
6600066
|
STARTER COVER |
|
188
|
6600089
|
AIR DEFLECTOR ASS'Y INCLUDES 170 |
|
189
|
6600062
|
SCREW |
|
190
|
6600064
|
ENGAGEMENT PLATE |
|
191
|
6600065
|
STARTER PULLEY W/S-START SPRING |
|
192
|
6600063
|
STARTER SPRING |
|
193
|
305558
|
TAPPING SCREW D5X25 (W/FLANGE) BLAC |
|
194
|
6685408
|
WASHER |
|
195
|
6699967
|
FRONT HANDLE |
|
196
|
6698865
|
SPRING GUARD |
|
197
|
6698859
|
SHOCK ABSORBER SCREW |
|
198
|
6699953
|
COMPLETE STARTER INCLUDES 183, 187, 189-192 |
|
501
|
6685439
|
ROD SLEEVE 35CM |
|
502
|
6685440
|
ROD SLEEVE 40CM |
| Accessories Pag.3 | ||
| 2 | 6695736 | FLYWHEEL PULLER |
| 3 | 6695737 | FLYWHEEL PULLER BOLT |
| 5 | 6695740 | PIN PULLER |
| 13 | 6695753 | CLUTCH PULLER |
