Hikoki Cordless Chainsaw CS3630DA
€5.76
Tax included
HIKOKI CORDLESS ELECTRIC CHAINSAW CS3630DA PARTS
We are Hitachi-HIKOKI-TANAKA authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem for Cordless Electric Chainsaw CS3630DA.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
HIKOKI CORDLESS ELECTRIC CHAINSAW CS3630DA PARTS
We are Hitachi-HIKOKI-TANAKA authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem for Cordless Electric Chainsaw CS3630DA.
In the following table, look for the model of the Chainsaw and ripettivo spare part.
| HIKOKI CHAINSAW CS3630DA Pag.1 | ||
| # | Part. Num. | Description |
| 1 | 335134 | BRAKE LINK COVER |
| 2 | 6696782 | BRAKE SUPPORT PLATE |
| 3 | 6696783 | BRAKE LEVER SPRING |
| 4 | 335135 | BRAKE LINK HOLDER |
| 5 | 6699013 | BRAKE BAND |
| 6 | 6685391 | NEEDLE ROLLER D3 |
| 7 | 6685388 | BRAKE LINK |
| 8 | 6685389 | BRAKE SPRING |
| 9 | 335192 | LOCK NUT (LEFT HAND) M8 |
| 10 | 957042 | SUPER LOCK WASHER M8 |
| 11 | 335139 | SIDE PLATE |
| 12 | 6685403 | CLUTCH HOUSING |
| 13 | 335151 | KNOB |
| 14 | 335150 | TENSION DIAL |
| 15 | 315500 | MACHINE SCREW (W/WASHER) M4X8 (BLACK) |
| 16 | 335152 | TENSION GEAR |
| 17 | 336349 | HEX. SOCKET HD. BOLT (W/FLANGE) M5X20 |
| 18 | 336347 | CHAIN SIDE COVER |
| 19 | 335156 | BEVEL GEAR (A) |
| 20 | 696352 | TAPPING SCREW D3X6 |
| 21 | 370905 | TAPPING SCREW D3X12 |
| 22 | 335688 | DUST SHEET |
| 23 | 939543 | RETAINING RING FOR D14 SHAFT |
| 24 | 996407 | O-RING (1AP-12) |
| 25 | 335153 | CHAIN PULLER |
| 26 | 335154 | GUIDE PLATE |
| 27 | 781122 | SAW CHAIN (3/8X12") 91PX-45XJ |
| 28 | 781232 | CHAIN BAR 12 INCH 3/8 SPROCKET PRC |
| 29 | 335142 | SPIKE |
| 30 | 339250 | TAPPING SCREW (W/FLANGE) D4X20 |
| 32 | 335155 | CHAIN CATCHER |
| 33 | 336350 | SPECIAL NUT M5 |
| 34 | MV LABEL (B) | |
| 35 | 313687 | TAPPING SCREW (W/FLANGE) D3X16 (BLACK) |
| 36 | 371750 | BATTERY BSL 36A18 (EUROPE,AUS,NZL) INCLUD.505 |
| 37A | 373112 | HOUSING.HANDLE COVER SET |
| 38 | 370328 | BATTERY RUBBER (B) |
| 39 | 6698696 | HOOK |
| 40 | 335690 | LINK SLEEVE |
| 41 | 301653 | TAPPING SCREW (W/FLANGE) D4X20 (BLACK) |
| 42 | 304043 | MACHINE SCREW (W/WASHERS) M4X10 (BLACK) |
| 43 | 336342 | MACHINE SCREW (W/WASHERS) M5X10 (BLACK) |
| 44 | 335137 | SPINDLE |
| 45 | 6001VV | BALL BEARING 6001VV |
| 46 | 939542 | RETAINING RING FOR D12 SHAFT |
| 47 | 335138 | GEAR |
| 48 | 6696886 | WORM |
| 49 | 606ZZM | BALL BEARING 606VV |
| 50 | 335140 | FAN GUIDE |
| 51 | 323156 | MAGNET |
| 52 | 335148 | URETHANE TUBE 130L |
| 53 | 335147 | NOZZLE |
| 54 | 6696887 | OIL PUMP |
| 55 | 335136 | INNER COVER |
| 56 | 360948 | ARMATURE AND PINION SET |
| 57 | 335124 | SWITCH |
| 58 | 335687 | INTERNAL WIRE (RED) L240 |
| 59 | 335694 | INTERNAL WIRE (RED) L490 |
| 60 | 959141 | CONNECTOR 50092 (10 PCS.) |
| 61 | 372228 | BATTERY TERMINAL |
| 62 | 335132 | BRAKE LEVER |
| 63 | 314429 | SPRING |
| 64 | 331682 | LOCK BUTTON |
| 65 | 301653 | TAPPING SCREW (W/FLANGE) D4X20 (BLACK) |
| 66 | 319956 | WASHER (B) |
| 67 | 335133 | SWITCH LEVER |
| 68 | 373111 | CONTROLLER TERMINAL SET INCLUD.60,61 |
| 69 | 335146 | OIL PIPE |
| 70 | 981824 | HEX. HD. TAPPING SCREW D4X45 |
| 71 | 319956 | WASHER (B) |
| 72 | 335125 | TRIGGER |
| 73 | 335695 | INTERNAL WIRE (BROWN) L165 |
| 74 | 335696 | INTERNAL WIRE (BLACK) L120 |
| 75 | 335689 | DIODE |
| 76 | 335145 | URETHANE TUBE 95L |
| 77 | 335143 | OIL TANK |
| 78 | MV LABEL (A) | |
| 79 | NAME PLATE | |
| 80 | 335692 | CAUTION LABEL (EX) |
| 81 | PANEL SHEET | |
| 82 | 335867 | SPONGE (A) |
| *83 | 335698 | BRUSH HOLDER |
| 84 | 999068 | CARBON BRUSH (1 PAIR ) |
| 85 | 319847 | BRUSH CAP |
| 86 | 335141 | TAIL COVER |
| 87 | 335691 | TANK CAP PACKING |
| 88 | 335144 | TANK CAP |
| *89 | 335699 | BRUSH HOLDER |
| 90 | 335130 | FRONT HANDLE |
| 91 | 335131 | BRAKE HANDLE |
| 92 | 316321 | TAPPING SCREW (W/FLANGE) D5X45 |
| *93 | 334379 | FERRITE CORE |
| STANDARD ACCESSORIES Pag.2 | ||
| 501A | 6685439 | CHAIN COVER 14" |
| 502 | OIL FEEDER (50CC) | |
| 503 | CHARGER (MODEL UC 18YSL3) | |
| 504 | 944458 | HEX. BAR WRENCH 4MM |
| 505 | 329897 | BATTERY COVER |
| OPTIONAL ACCESSORIES Pag.3 | ||
| 601 | 957681 | LUBRICANT OILER (120CC) |
