Hitachi Spare Parts for Engine Hedge Trimmer CH62EA (ST)
€9.61
Tax included
Hitachi Spare Parts for Engine Hedge Trimmer CH62EA (ST)
We are Dealers of Hitachi-HIKOKI original spare parts at low at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Engine Hedge Trimmer CH62EA (ST).
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Engine Hedge Trimmer CH62EA (ST)
We are Dealers of Hitachi-HIKOKI original spare parts at low at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Engine Hedge Trimmer CH62EA (ST).
In the following table, look for the model of Trimmer and the respective parts of the code.
| HEDGETRIMMER HITACHI CH62EA (ST) pag.1 | ||
| # | Part Num. | Description |
| 1 | 6687476 | SPARK PLUG CAP |
| 3 | 6685480 | CYLINDER WITH GASKET |
| 4 | 6684586 | SCREW M5X18 / S |
| 7 | 6685744 | CYLINDER GASKET |
| 8 | 6686118 | PISTON RING |
| 9 | 6685892 | PISTON WITH RINGS (2) AND CIRCLIPS (2) |
| 10 | 6696944 | PISTON PIN |
| 11 | 6684590 | CIRCLIP |
| 12 | 6686208 | CRANKSHAFT |
| 27 | 6695927 | IGNITION COIL ASSY |
| 28 | 6684599 | SCREW EX 68-4599 |
| 29 | 6688461 | IGNITION CABLE |
| 36 | 6684597 | TUBE |
| 37 | 6687866 | CABLE |
| 38 | 6695939 | IGNITION COIL |
| HEDGETRIMMER HITACHI CH62EA (ST) pag.2 | ||
| 21 | 6686574 | CRANKSHAFT CASE |
| 22 | 6686720 | CRANKSHAFT CASE GASKET |
| 23 | 6684607 | OUTER TB 12227 |
| 24 | 6684608 | BEARING 6001 C3 NSK |
| 25 | 6689177 | THICKNESS 0.10 |
| 25 | 6689178 | THICKNESS 0.15 |
| 25 | 6684604 | THICKNESS 0.20 |
| 25 | 6684605 | THICKNESS 0.30 |
| 26 | 6691822 | RUBBER |
| 30 | 6684786 | SCREW M5X30S |
| 31 | 6687396 | THEY FLY |
| 34 | 6684612 | NUT M8 |
| 35 | 6686771 | STUD |
| HEDGETRIMMER HITACHI CH62EA (ST) pag.3 | ||
| 25 | 6689891 | GASKET |
| 26 | 6689966 | INTAKE MANIFOLD WITH GASKET |
| 27 | 6695515 | SCREW 5X25WS |
| 30 | 6684615 | CARBURETOR GASKET |
| 35 | 6690091 | FILTER BODY |
| 36 | 6690801 | COLLAR |
| 37 | 6691267 | DISTANCE |
| 38 | 6684859 | BUSHING |
| 40 | 6684662 | WASHER |
| 41 | 6694918 | EXAGONAL SCREW 990-11050-652 |
| 42 | 6684661 | WASHER M5 |
| 43 | 6690350 | CLEANER ELEMENT |
| 44 | 6690142 | AIR CLEANER CAP |
| 45 | 6690495 | CARBURETOR WYL212 |
| 46 | 6684629 | HEXAGON BRACKET 668-4629 |
| 47 | 6689839 | GASKET |
| 48 | 6690184 | GASKET |
| 50 | 6685247 | HOSE WITH GROMMET |
| 51 | 6684619 | CLIP |
| 52 | 6698874 | PUMP FILTER |
| 53 | 6691647 | TANK |
| 54 | 6691716 | TANK CAP - ORANGE |
| 55 | 6692244 | COLLAR 5.8 |
| 56 | 6692059 | TANK CAP CHAIN |
| 58 | 6695505 | SCREW 5X18PS |
| 59 | 6684871 | CABLE REGULATOR |
| 60 | 6684872 | NUT M6 |
| 61 | 6691337 | CAP |
| 78 | 6692357 | PIPE |
| 79 | 6697846 | GROMMET |
| HEDGETRIMMER HITACHI CH62EA (ST) pag.4 | ||
| 3 | 6692795 | MUFFLER PROTECTOR |
| 4 | 6692744 | MUFFLER GASKET |
| 5 | 6687252 | HEAT SHIELD |
| 6 | 6692481 | MUFFLER SET |
| 7 | 6684661 | WASHER M5 |
| 8 | 6685114 | SCREW M5X50 |
| 17 | 6688050 | GROMMET |
| 20 | 6695502 | HEXAGONAL BOLT |
| 47 | 6688494 | CLUTCH |
| 61 | 6684636 | SCREW D4.5X16 |
| 62 | 6695441 | SCREW 4X12PS |
| 67 | 6687014 | FAN CASE COMP. - DISCONTINUED |
| 68 | 6693072 | PULLEY |
| 69 | 6684678 | CAM PLATE |
| 70 | 6684677 | STARTER SPRING S-START |
| 71 | 6684675 | STARTER SPRING |
| 72 | 6684679 | SET SCREW |
| 73 | 6693172 | ROPE 3X890 |
| 74 | 6693237 | STARTER KNOB |
| 75 | 6684681 | STARTER PULLEY ASS'Y |
| 76 | 6687209 | DEFLECTOR |
| 77 | 6684685 | STARTER PAWL |
| 78 | 6684684 | PAWL SPRING |
| 79 | 6684683 | RETAINING RING |
| HEDGETRIMMER HITACHI CH62EA (ST) pag.5 | ||
| 2 | 6691433 | CARBURETOR PLATE |
| 3 | 6684687 | CARBURETOR PRIMER PLATE |
| 4 | 6684688 | LITTLE COVER |
| 5 | 6684689 | PRIMER |
| 6 | 6690830 | DISC MEMBRANE |
| 7 | 6684691 | DISC GASKET |
| 8 | 6684878 | JET # 39 |
| 9 | 6684696 | RING |
| 10 | 6684697 | PIN |
| 12 | 6684695 | O-RING |
| 13 | 6691457 | PUMP GASKET |
| 14 | 6684693 | PUMP MEMBRANE |
| 15 | 6684698 | SCREW |
| 17 | 6684699 | SET SCREW (OLD 548-25151-20 / 6696324 |
| 201 | 6684700 | NET FILTER |
| HEDGETRIMMER HITACHI CH62EA (ST) pag.6 | ||
| 1 | 6686314 | LEFT HANDLE |
| 2 | 6686279 | RIGHT HANDLE |
| 3 | 6688230 | THROTTLE LEVER |
| 4 | 6688240 | SAFETY LEVER |
| 5 | 6688244 | THROTTLE LEVER SPRING |
| 6 | 6687758 | SWITCH |
| 7 | 6688246 | LEVER |
| 8 | 6688279 | SPRING |
| 9 | 6685070 | WASHER |
| 10 | 6685161 | SCREW D4X10 |
| 11 | 6684636 | SCREW D4.5X16 |
| 12 | 6693942 | THROTTLE CABLE |
| 13 | 6688366 | BUTTON |
| 14 | 6684913 | SCREW 3X10 |
| 16 | 6694588 | STOP SWITCH |
| 25 | 6696359 | STILL |
| 61 | 6688096 | FRONT HANDLE |
| 63 | 6689680 | WASHER |
| 64 | 6684834 | WASHER |
| 65 | 6695054 | BOLT 5X40 |
| 73 | 6687521 | TUBE PROTECTION |
| HEDGETRIMMER HITACHI CH62EA (ST) pag.7 | ||
| 1 | 6688827 | GEAR BOX - DISCONTINUED |
| 2 | 6695285 | SEEGER |
| 3 | 6002C3 | BALL BEARING 6002C3 |
| 4 | 6695538 | BALL BEARING |
| 5 | 6688570 | CLUTCH DRUM |
| 6 | 6688960 | SHAFT, GEAR |
| 7 | 6686614 | PLATE |
| 9 | 6688979 | GEAR |
| 10 | 6688909 | GEAR COVER GASKET |
| 11 | 6692102 | LOWER CASE |
| 12 | 6697703 | BLADE GUIDE |
| 13 | 6684639 | WASHER M6 |
| 14 | 6695175 | NUT M6 |
| 15 | 6697701 | LOWER BLADE |
| 16 | 6686658 | FELT |
| 17 | 6687187 | WASHER D7 |
| 18 | 6687158 | SCREW M6 |
| 19 | 6695170 | NUT M6 |
| 20 | 6695484 | SCREW 4X10S |
| 22 | 6688643 | GREASE |
| 23 | 6695495 | SCREW |
| 24 | 6687162 | BLADE SCREW |
| 25 | 6697702 | UPPER BLADE |
| 26 | 6690761 | REINFORCEMENT |
| 27 | 6684864 | WASHER |
| 28 | 305491 | NYLON NUT M5 (OLD 991-78050-010) |
| 29 | 6686468 | PLATE |
| 67 | 6688008 | CABLE CLAMP |
| 69 | 6687302 | BLADE PROTECTION |
| 72 | 6695475 | NUT M6 |
| HEDGETRIMMER HITACHI CH62EA (ST) pag.8 | ||
| 2 | 6695736 | FLYWHEEL PULLER |
| 3 | 6695737 | FLYWHEEL BOLT PULLER |
| 5 | 6695740 | PISTON PIN PULLER |
| 14 | 6695754 | CLUTCH PULLER |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
