Hitachi Spare Parts for Engine Brush Cutter CG27EAP2
€1.04
Tax included
Hitachi Spare Parts for Engine Brush Cutter CG27EAP2
Hitachi genuine spare parts or replacement parts for to repair Engine Bushcutter CG27EAP2.Fix Your Hitachi Engine Brushcutter CG27EAP2. All Spares are Available at best and Cheapest and Discounted Prices. Our spare parts are original and come with a full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Engine Brush Cutter CG27EAP2
Fix Your Hitachi Engine Brushcutter CG27EAP2. All Spares are Available at best and Cheapest and Discounted Prices. Our spare parts are original and come with a full Guarantee.
In the following table, look for the model of the Bush Cutter and ripettivo spare part.
| Bushcutter CG27EAP2 | ||
| # | Part Num. | Description |
| 2 | 6600322 | MUFFLER COVER |
| 3 | 6698384 | HEX. SOCKET HD. BOLT M6X65 |
| 5 | 6600004 | MUFFLER (B) |
| 6 | 6600324 | HEAT PROTECTION PANEL |
| 7 | 6696958 | HEX. SOCKET BOLT M5X20 |
| 14 | 6698365 | COVER PACKING |
| 15 | 6698484 | SCAVENGING COVER (A) |
| 16 | 6698385 | HEX. SOCKET HD. BOLT M4X12 |
| 19 | 6698700 | GLASS WASHER |
| 20 | 6698485 | SCAVENGING COVER (B) |
| 21 | 6698480 | CYLINDER |
| 22 | 6698473 | INTAKE PACKING |
| 23 | 6698387 | CARBURETOR INSULATOR |
| 24 | 6698844 | SEAL LOCK HEX. SOCKET BOLT (W/WASHERS)M5 |
| 25 | 6698405 | CARBURETOR PACKING |
| 26 | 6691337 | SWIVEL CAP |
| 27 | 6698489 | CARBURETOR ASS'Y WYC-29 |
| 29 | 6696830 | SWIVEL |
| 30 | 6684696 | STOP RING |
| 31 | 6684692 | PUMP GASKET |
| 32 | 6684693 | PUMP DIAPHRAGM |
| 33 | 6691242 | PUMP PLATE |
| 35 | 6691312 | SET SCREW |
| 37 | 6684695 | O-RING |
| 39 | 6691234 | CIRCUIT PLATE |
| 40 | 6696828 | PUMP BODY COMP. |
| 41 | 6685220 | DIAPHRAGM PACKING-METERING |
| 42 | 6684690 | METERING DIAPHRAGM |
| 46 | 6696832 | AIR CLEANER HOUSING |
| 47 | 6685139 | PRIMING PUMP COMP. |
| 48A | 6600704 | CLEANER SPONGE |
| 49 | 6696831 | AIR CLEANER COVER |
| 50 | 6696549 | AIR CLEANER ASS'Y |
| 53 | 6698366 | CYLINDER PACKING |
| 54 | 6686121 | PISTON RING |
| 55 | 6698483 | PISTON |
| 56 | 6684590 | CIR CLIP |
| 57 | 6684591 | PISTON PIN |
| 59 | 6698370 | CRANK CASE (B) ASS'Y |
| 60 | 6698371 | CRANK CASE PACKING |
| 64 | 6698488 | CRANK SHAFT COMP. |
| 65 | 6698369 | CRANK CASE (A) ASS'Y |
| 67 | 6684681 | STARTER PULLEY ASS'Y |
| 68 | 6684683 | STOP RING E-5 |
| 69 | 6684684 | STARTER PAWL SPRING |
| 70 | 6684685 | STARTER PAWL |
| 71 | 6699995 | RECOIL STARTER BODY ASS'Y |
| 72 | 6684679 | SET SCREW |
| 73 | 6699996 | CAM PLATE |
| 74 | 6684677 | DAMPER SPRING |
| 75 | 6699997 | STARTER ROPE REEL |
| 76 | 6684675 | RECOIL SPRING |
| 77 | 6684673 | RECOIL STARTER BODY COMP. |
| 79 | 6684680 | STARTER HANDLE |
| 91 | 305812 | TAPPING SCREW (W/FLANGE) D4X16 (BLACK) |
| 92 | 6696487 | HANDLE (B) |
| 92 | 6696942 | HANDLE (B) |
| 93 | 6696490 | LOCK LEVER |
| 94 | 6696488 | LEVER |
| 95 | 6696489 | SPRING (A) |
| 96A | 6601275 | STOP SWITCH |
| 97 | 6696491 | STOP SWITCH CORD |
| 98 | 6696967 | PROTECTION TUBE |
| 99 | 6696560 | THROTTLE WIRE COMP. |
| 99 | 6696593 | THROTTLE WIRE COMP. |
| 100 | 6696486 | HANDLE (A) |
| 100 | 6696941 | HANDLE (A) |
| 102 | 6695492 | HEX. HOLE BOLT 5X22/S |
| 103 | 6696963 | ANTI VIBE RUBBER (A) |
| 104 | 6698643 | PIPE HOLDER (A) |
| 105 | 6698644 | PIPE HOLDER (B) |
| 106 | 6696964 | ANTI VIBE RUBBER (B) |
| 107 | 939542 | RETAINING RING FOR D12 SHAFT |
| 108 | 6697922 | FAN CASE |
| 109 | 6699400 | CLUTCH SHAFT |
| 110 | 6696469 | STEP BOLT |
| 111 | 6684648 | BENT WASHER 8 |
| 112 | 6696546 | CLUTCH PLATE (A) |
| 113 | 6696948 | CLUTCH |
| 114 | 6696547 | CLUTCH WASHER (B) |
| 115 | 6685337 | FLYWHEEL NUT |
| 118 | 6698492 | IGNITION COIL ASS'Y |
| 122 | 6696545 | EARTH CORD |
| 123 | 6698396 | MAGNETO ROTOR COMP. |
| 125 | 6698931 | FUEL GROMMET |
| 125A | 6600358 | FUEL GROMMET |
| *126 | 6698716 | FUEL PIPE |
| 128 | 6697846 | RETURN GROMMET |
| 129 | 6698402 | FUEL TANK CAP ASS'Y |
| *131 | 6600317 | TANK (B) |
| *131 | 6699719 | TANK |
| 131A | 6600354 | TANK (C) |
| 132 | 6600351 | PUMP FILTER |
| 135 | 6696557 | FLANGE BOLT |
| 136 | 6698991 | BOLT (W/FLANGE) L27.8 |
| 155 | 6691098 | HANDLE GRIP |
| 156 | 949556 | NUT M6 (10 PCS.) |
| 157 | 6689681 | BRAKE SHAFT WASHER |
| 158 | 6695255 | TAPPING SCREW 5X20 |
| 160 | 6696975 | LOOP HANDLE |
| 163 | 6696972 | HANDLE HOLDER (A) |
| 164 | 6684838 | BOLT 6X43/P (BLACK) |
| 165 | 6696974 | BOLT (BLACK) M6 |
| 166 | 6696973 | BARRIER |
| 167 | 6684709 | HEX. HOLE BOLT M5X25/S |
| 172 | 6684714 | HEX. HOLE BUTTON BOLT M6X25 |
| 172 | 6684714 | HEX. HOLE BUTTON BOLT M6X25 |
| 173 | 6699402 | GEAR CASE ASS'Y 3BB (A) |
| 175 | 6696977 | CUTTER HOLDER (A) |
| 176 | 6698659 | CUTTER HOLDER (B) |
| 177 | 6699188 | NUT COVER |
| 178 | 335759 | U-NUT (LEFT HAND) M10 |
| 181 | 6696494 | COVER BRACKET |
| 184 | 6685064 | HEX. SOCKET HD. BOLT (W/BUTTON) M6X20 |
| 189 | 6696558 | MAIN PIPE COMP. |
| 190 | 6698514 | DRIVE SHAFT |
| 193 | 6698794 | COVER |
| 196 | 6698796 | REEL |
| 197 | 6698797 | RETURN SPRING |
| 198 | 6698798 | BUTTON |
| 199 | 6698799 | CORD GUIDE |
| 199 | 6698942 | CORD GUIDE |
| 200 | 6698800 | CASE |
| 202 | 6696980 | GUARD |
| 203 | 6696951 | GUARD HOLDER |
| 204 | 6696950 | COVER GUARD |
| 205 | 6684751 | TAPPING SCREW 4X14 |
| 206 | 6684750 | KNIFE |
| 209 | 6685068 | MACHINE SCREW (W/SP. WASHER) M4X12 |
| 510 | 6696977 | CUTTER HOLDER (A) |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Hitachi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to hitachi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
