Hitachi Spare Parts for Engine Hedge Trimmer CH22EC2
€17.74
Tax included
Hitachi Spare Parts for Engine Hedge Trimmer CH22EC2
We are Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem for Engine Hedge Trimmer CH22EC2.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Hitachi Spare Parts for Engine Hedge Trimmer CH22EC2
We are Hitachi-HIKOKI Tanaka authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem for Engine Hedge Trimmer CH22EC2.
In the following table, look for the model of Trimmer and the respective parts of the code.
| Hedge Trimmer CH22EC2 | ||
| # | Part Num. | Description |
| 1 | 6698730 | COVER FIXING BOLT COMP. |
| 2 | 6698609 | CLEANER COVER |
| 3 | 6690365 | CLEANER SPONGE |
| 4 | 6698608 | CHOKE VALVE |
| 6 | 6698606 | CLEANER BODY |
| 7 | 6698607 | CHOKE HANDLE |
| 13 | 6699097 | PRIMER BASE |
| 14 | 6699096 | PUMP GASKET |
| 15 | 6699095 | PUMP DIAPHRAGM |
| 17 | 6699103 | GUIDE PIN ROLLER |
| 24 | 6699091 | METERING DIAPHRAGM |
| 34 | 6699092 | METERING GASKET |
| 37 | 6698387 | CARBURETOR INSULATOR |
| 38A | 6600456 | INTAKE PAKING (A) |
| 39 | 6698700 | GLASS WASHER |
| 40 | 6698816 | CARBURETOR PACKING |
| 41 | 6698844 | SEAL LOCK HEX. SOCKET BOLT (W/WASHERS)M5 |
| 45 | 6698871 | CYLINDER COVER |
| 47 | 6698548 | PLUG CAP |
| 49A | 6600890 | IGNITION COIL |
| 51 | 6698597 | CYLINDER |
| 52 | 6696534 | COVER PACKING |
| 53 | 6696535 | INTAKE COVER (A) |
| 54 | 6696835 | SEAL LOCK SCREW M4X10 |
| 59 | 6696536 | INTAKE COVER (B) |
| 60 | 6696944 | PISTON PIN |
| 61 | 6696531 | PISTON |
| 63 | 6696530 | CYLINDER PACKING |
| 64 | 6696532 | PISTON RING |
| 65 | 6684590 | CIR CLIP |
| 66 | 6696879 | FLYWHEEL NUT M7 |
| 67 | 6696880 | BOLT WASHER D7 |
| 69 | 6685335 | STARTER PAWL SPRING |
| 70 | 6698601 | MAGNETO ROTOR |
| 71 | 6685336 | RETAINING RING D4 |
| 72 | 6698872 | CRANK CASE (B) ASS'Y |
| 77 | 6699043 | CRANK SHAFT |
| 79 | 6696539 | CRANK CASE PACKING |
| 81 | 6699173 | CLUTCH ASS'Y (B) |
| 82 | 6699040 | CLUTCH DRUM |
| 83 | 6698740 | BALL BEARING 6002ZC3 |
| 85 | 6688643 | GREASE NIPPLE COMP. |
| 93 | 6695495 | HEX. HOLE BOLT 6X18/S |
| 97 | 6693227 | STARTER HANDLE |
| 98 | 6693168 | ROPE |
| 100A | 6684675 | RECOIL SPRING |
| 101A | 6600995 | STARTER PULLEY |
| 102 | 6685183 | DAMPER SPRING |
| 103A | 6600996 | CAM PLATE |
| 104 | 6684679 | SET SCREW |
| 106 | 6698624 | AIR DEFLECTOR |
| 107 | 6698402 | FUEL TANK CAP ASS'Y |
| 109 | 6698931 | FUEL GROMMET |
| 112A | 6697846 | RETURN GROMMET |
| 114 | 6698874 | PUMP FILTER |
| 115 | 6698615 | CUSHION RUBBER |
| 116 | 6698613 | FUEL TANK |
| 123 | 6600879 | PUMP PACKING |
| 124 | 6600880 | PUMP DIAPHRAGM |
| 125 | 6684700 | INLET SCREEN |
| 129 | 6685219 | HINGE PIN |
| 130 | 6600881 | METERING DIAPHRAGM |
| 132 | 6684697 | SWIVEL |
| 134 | 6684696 | STOP RING |
| 136 | 6685215 | NEEDLE VALVE |
| 139 | 6685220 | DIAPHRAGM PACKING-METERING |
| 140 | 6600875 | CARBURETOR ASS'Y WYGA-1 |
| 142 | 6698776 | FRONT HANDLE |
| 144 | 6698777 | FRAME |
| 147 | 6698880 | HANDLE A |
| 149 | 6696348 | SPRING (A) |
| 152 | 6696344 | TRIGGER LOCKOUT |
| 153 | 6696345 | THROTTLE LEVER SPRING |
| 155 | 6699051 | HANDLE B |
| 157 | 6698627 | THROTTLE WIRE |
| 159 | 6699058 | STOP SWITCH WIRE |
| 160 | 6699059 | STOP SWITCH WIRE (B) |
| 162 | 6696359 | CLIP |
| 164 | 6684639 | BOLT WASHER 6 |
| 164 | 6684639 | BOLT WASHER 6 |
| 165 | 6699108 | U-NUT M5 |
| 165 | 6699108 | U-NUT M5 |
| 169A | 6699064 | SUPPORT PLATE |
| 171 | 6698779 | SPRING HOLDER |
| 173A | 6600480 | ANTIVIBRATION SPRING |
| 174A | 6600398 | BLADE ASS'Y (620MM) |
| 174A | 6600410 | BLADE ASS'Y (780MM) |
| 175 | 6699065 | HEX. SOCKET HD. BOLT (W/FLANGE) M5X8 |
| 176 | 6699062 | GUARD PLATE |
| 177 | 6699113 | HEX. SOCKET HD. BOLT (W/BUTTON) M6X25 |
| 178 | 6699114 | WASHER (A) |
| 179 | 6699111 | WASHER M7 |
| 179 | 6699111 | WASHER M7 |
| 180 | 6699109 | SHOULDER BUTTON BOLT M5X25 |
| 180 | 6699109 | SHOULDER BUTTON BOLT M5X25 |
| 181 | 6699179 | SHOULDER BUTTON BOLT M5X31 |
| 182 | 6698948 | BLADE CASE (FOR 620MM) |
| 183 | 6699074 | GEAR CASE (A) ASS'Y |
| 185 | 6699113 | HEX. SOCKET HD. BOLT (W/BUTTON) M6X25 |
| 186A | 6600418 | GUIDE PLATE (B) |
| 187 | 6698987 | CAM ROD |
| 188 | 6699066 | GEAR 2 |
| 189 | 6699068 | FELT PACKING (B) |
| 190 | 6699067 | FELT PACKING (C) |
| 191 | 6699042 | GEAR CASE PACKING |
| 192 | 6699071 | GEAR CASE (B) ASS'Y |
| 194 | 6600013 | LOWER PLATE |
| 195 | 6600012 | BLADE GUIDE (620MM) |
| 195 | 6600015 | BLADE GUIDE (780MM) |
| 196 | 6600014 | HEDGE TRIMMER BLADE (C) 620MM |
| 196 | 6600016 | HEDGE TRIMMER BLADE (D) 780MM |
| 197 | 6600360 | BLADE LINER |
| 197 | 6600361 | BLADE LINER |
| 198 | 6699112 | WASHER (B) |
| 198 | 6699112 | WASHER (B) |
| 199 | 6600362 | BALANCER |
| 202 | 6698405 | CARBURETOR PACKING |
| 204 | 6600997 | STARTER PULLEY ASS'Y |
| 205 | 6601364 | IGNITION COIL ASS'Y |
| 206 | 6600891 | CARBURETOR HEAT PANEL ASS'Y |
| 208 | 6600358 | FUEL GROMMET |
| 601 | 6600487 | BOTTOM COVER SET |
| 607 | 6600486 | HEAT PROTECTION PANEL (B) |
