Hitachi Spare Parts for Engine Brush Cutter CG25EUP2
Hitachi-HIKOKI-Tanaka authorized service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Engine Bush Cutter CG25EUP2.
In the following table, look for the model of the Brush Cutter and ripettivo spare part.
| Brush Cutter CG25EUP2 | ||
| # | Part Num. | Description |
| 2 | 6696440 | CYLINDER HEAD COVER |
| 4 | 6696438 | PIVOT ROCKER ARM |
| 5 | 6696437 | PUSH ROD |
| 6 | 6696432 | TAPPET |
| 7 | 6696442 | BREATHER PIPE |
| 8 | 6696439 | ROCKER ARM |
| 11 | 6600329 | MUFFLER HEAT COVER |
| 14 | 6696462 | MUFFLER |
| 15 | 6696460 | MUFFLER GASKET (A) |
| 16 | 6696461 | WIND GUIDE PLATE (B) |
| 17 | 6696421 | RETAINER VALVE |
| 18 | 6696420 | VALVE SPRING |
| 19 | 6696418 | STEM SEAL BASE |
| 20 | 6696419 | STEM SEAL |
| 24 | 6696450 | INSULATOR GASKET |
| 25 | 6696451 | WIND GUIDE PLATE (A) |
| 27 | 6696452 | INSULATOR |
| 29 | 6696954 | CARBURETOR GASKET |
| 31 | 6696956 | INSULATOR GASKET (B) |
| 32 | 6696957 | CARBURETOR |
| 45 | 6691337 | SWIVEL CAP |
| 46 | 6696413 | CYLINDER (A) |
| 47 | 6696958 | HEX. SOCKET BOLT M5X20 |
| 49 | 6696436 | CYLINDER GASKET |
| 50 | 6696417 | INTAKE VALVE |
| 51 | 6696416 | EXHAUST VALVE |
| 52 | 6696444 | PUMP GASKET |
| 53 | 6696443 | BASE PUMP |
| 54 | 6696445 | INNER ROTOR |
| 55 | 6696446 | OUTER ROTOR |
| 57 | 6684682 | HEX. HOLE BOLT 4X15/PS |
| 58 | 6696429 | 1ST RING |
| 59 | 6696430 | 2ND RING |
| 60 | 6696431 | OIL RING |
| 61 | 6696427 | PISTON |
| 62 | 6684590 | CIR CLIP |
| 63 | 6696425 | CRANK CASE GASKET |
| 66 | 6696426 | CRANK SHAFT GEAR SET |
| 67 | 6684591 | PISTON PIN |
| 68 | 6696434 | SHIM |
| 71 | 6696959 | O-RING (I.D 13.8) |
| 72 | 6685391 | NEEDLE ROLLER D3 |
| 74 | 6696960 | CRANK CASE ASS'Y (B) |
| 75 | 6685310 | OIL FILTER BODY |
| 76 | 6690919 | OIL FILTER |
| 77 | 6685407 | BOLT WASHER D5 |
| 78 | 6685311 | CLIP |
| 81 | 6696470 | RECOIL STARTER BODY ASS'Y |
| 86 | 6693168 | ROPE |
| 93 | 6696471 | STARTER PULLEY ASS'Y |
| 94 | 6696455 | CLEANER BODY |
| 96 | 6684659 | COLLAR 8 |
| 97 | 6684658 | WAVE WASHER 8 |
| 98 | 6685407 | BOLT WASHER D5 |
| 101 | 6685139 | PRIMING PUMP COMP. |
| 102 | 6696459 | CLEANER ELEMENT |
| 103 | 6696458 | CLEANER COVER |
| 104 | 6684655 | COVER FIXING BOLT |
| 123 | 6696963 | ANTI VIBE RUBBER (A) |
| 124 | 6698643 | PIPE HOLDER (A) |
| 125 | 6698644 | PIPE HOLDER (B) |
| 126 | 6696964 | ANTI VIBE RUBBER (B) |
| 131 | 6696469 | STEP BOLT |
| 132 | 6684648 | BENT WASHER 8 |
| 134 | 6696948 | CLUTCH |
| 135 | 6684642 | CLUTCH WASHER B |
| 136 | 6685337 | FLYWHEEL NUT |
| 137 | 6685410 | BOLT WASHER D8 |
| 138 | 6696464 | MAGNET ROTOR |
| 140 | 6696463 | IGNITION COIL SET |
| 148 | 6600330 | FAN CASE (A) W/ALUMINUM TAPE |
| 149 | 6698793 | CLUTCH SHAFT |
| 151 | 6696487 | HANDLE (B) |
| 152 | 6696490 | LOCK LEVER |
| 153 | 6696488 | LEVER |
| 154 | 6696489 | SPRING (A) |
| 155 | 6696486 | HANDLE (A) |
| 157 | 6696491 | STOP SWITCH CORD |
| 158 | 6696967 | PROTECTION TUBE |
| 159 | 6696492 | THROTTLE WIRE (EU) |
| 160 | 6696474 | TANK |
| 165 | 6684709 | HEX. HOLE BOLT M5X25/S |
| 166 | 6685311 | CLIP |
| 167 | 6698717 | FUEL PIPE |
| 169 | 6697846 | RETURN GROMMET |
| 170 | 6698931 | FUEL GROMMET |
| 171 | 6696479 | TANK CAP ASS'Y (A) |
| 196 | 6696593 | THROTTLE WIRE COMP. |
| 201 | 6684714 | HEX. HOLE BUTTON SCREW M6X25S |
| 202 | 6684709 | HEX. HOLE BOLT M5X25/S |
| 207 | 6696973 | BARRIER |
| 208 | 6696974 | BOLT (BLACK) M6 |
| 211 | 6699402 | GEAR CASE ASS'Y 3BB (A) |
| 213 | 6696977 | CUTTER HOLDER (A) |
| 214 | 6698659 | CUTTER HOLDER (B) |
| 215 | 6699188 | NUT COVER |
| 219 | 6696494 | COVER BRACKET |
| 220 | 6684714 | HEX. HOLE BUTTON SCREW M6X25S |
| 225 | 6696558 | MAIN PIPE COMP. |
| 226 | 6698514 | DRIVE SHAFT |
| 227 | 6696493 | HANGER |
| 229 | 6698794 | COVER |
| 232 | 6698796 | REEL |
| 233 | 6698797 | RETURN SPRING |
| 234 | 6698798 | BUTTON |
| 235 | 6698799 | CORD GUIDE |
| 236 | 6698800 | CASE |
| 238 | 6696950 | COVER GUARD |
| 239 | 6684751 | TAPPING SCREW 4X14 |
| 240 | 6684750 | KNIFE |
| 242 | 6696980 | GUARD |
