Flex Spare Parts for Safety Vacuum Cleaner VCE 35 L AC

Flex original spare parts at the best price on the web for the maintenance or replacement of damaged or worn spare parts of the Safety Vacuum Cleaner with automatic filter cleaning VCE 35 L AC - from 2014-11-01.
ITEM CODE: 195715
Quantity
Only on demand

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Flex Spare Parts for Safety Vacuum Cleaner VCE 35 L AC

Flex original spare parts at the best price on the web for the maintenance or replacement of damaged or worn spare parts of the Safety Vacuum Cleaner with automatic filter cleaning VCE 35 L AC - from 2014-11-01.

In the following table, look for the model of the Safety Vacuum Cleaner and the respective parts of the code.
Flex VCE 35 L AC
Safety Vacuum Cleaner with automatic filter cleaning VCE 35 L AC - from 2014-11-01
A Pag.1
# Part Num. Description
1 415227 COMPLETE COVER VCE45
2 337641 HANDLE
3 337706 SCREW, 5X30 S 47
4 341797 ON / OFF BUTTON
5 340499 SPRING S47
6 341800 BUTTON S47M
7 329797 SCREW, KT-, KT 4 X 16 GALVANIZED
8 297615 MICRO SWITCH X S36
9 297607 SOCKET S 36
10 340456 ROTATING KNOB S47 GRAY
11 340367 INSTRUMENT PANEL F. ERS. S47
12 297593 GREEN LED S36
13 340596 SWITCH WITH LED S47
14 340618 SWITCH S47
15 337668 LATERAL HOOK X S47
16 297534 COMPLETE POWER CABLE S 36
17 297542 ACCESSORIES SUPPORT S36
18 325910 SCREW 3X12 S36M
19 340359 SPEED POTENTIOMETER
20 297623 PLATE S36
B Pag.2
1 415235 CASING VCE45
2 415219 GASKET SET VCE45
3 421650 MOTORE 230V VCE35-45
6 415324 WHIRE VCE4
7 297860 GASKET X S36
8 340308 INTERMEDIATE COVER S47
9 340421 ELECTRIC PROBE, S 47 / M, VCE 35/45-L / M
10 415243 ELECTRONIC BOARD - from 2014-11-01
11 340677 TERMINAL S47
12 297550 SCREW 4X16 VCE
13 340642 CABLE PROBE
15 337706 SCREW, 5X30 S 47
16 337692 FLAT FOLDER FILTER
17 340537 QUICK CLOSURE S47
18 341908 SCREW, 4 X 22 S47M
26 374490 FERRITE RING VCE 35/45 L AC
C Pag.3
1 415251 PORTA MAGNETE, DOMEL, VCE45
2 340669 MAGNET X S47
3 340545 0-RING S47
4 340294 SET X PORTA MAGNETE S47
5 340502 GUARNIZIONE DELL'ARIA DI MANDATA S47
6 340375 SUPPORTO MOLLA S47
7 415278 COPERCHIO FILTRO VCE45
8 415286 SUPPORTO FILTRO VCE45
9 340650 VITE 5X80 S47
10 375020 CAVO, MAGNETE VCE35 / 45L-AC
11 325937 VITE M4X8 S36M
13 195715 VITE LK 604 4X12
15 374490 FERRITRING VCE 35/45 L AC
D Pag.4
2 298131 TANK 10 X S36
3 298158 HOOK S36 / S47
4 340413 SUPPORT X S47
5 298174 WASHER X S47
6 394041 WHEEL COVER (VC / VCE - 35/45)
7 298190 REAR WHEEL X S47
8 298204 WHEELS X S36
9 298212 CONNECTION X S36
10 298298 BOLT S 36
11 340448 WASHER X S47
12 375039 LABEL VCE35 / 45
E Pag.5
1 408697 CONNECTION SLEEVE
2 298239 RUBBER CORD S 36
3 379654 SNAP RING SH-C 32 GRAY
4 378526 CONNECTOR FOR AS HOSE, VC / E 35/45
5 406708 SUCTION HOSE
17 296961 PAPER FILTER BAG S36 / VC35 5PCS
18 340766 DISPOSAL BAG, PACK OF 10
19 320188 ADAPTER
21 413437 NOZZLE
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Flex websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Flex brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
