FIAC Spare Parts for Pump Unit GM 143
€5.90
Tax included
FIAC Spare Parts for Pump Unit GM 143
Genuine Parts FIAC for piston Air Compressors and spare parts for to repair or replacement of components for direct driven lubricared pump unit GM 143 data validity - from 16/02/2011.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FIAC Spare Parts for Pump Unit GM 143
Genuine Parts FIAC for piston Air Compressors and spare parts for to repair or replacement of components for direct driven lubricared pump unit GM 143 data validity - from 16/02/2011.
In the following table, look for the model of the Pumping Unit and the respective parts of the code .
| GM 143 data validity - from 16/02/2011 | ||
| # | Part Num. | Description |
| 1 | 7011050000 | Screw M6x30 UNI-5739 |
| 2 | 9700000632 | junction |
| 3 | 7458340000 | filter plate |
| 4 | 7210010000 | filter element |
| 5 | 7210430000 | filter cover |
| 6 | 7012100000 | Ø3,9X16 lives |
| 7 | 7196020000 | Start valve M1/4"1.5 bar |
| 8 | 7570540000 | Head |
| 9 | 9101410080 | Cylinder head gasket |
| 10 | 9100010240 | Plate |
| 11 | 9100010080 | gasket |
| 12 | 9100010370 | Valve |
| 13 | 9101410090 | gasket |
| 14 | 9101410060 | Cylinder |
| 17 | 9100580020 | AC42 segment |
| 18 | 9100580050 | Piston |
| 19 | 9100580090 | pin |
| 20 | 7041010000 | Seeger Ø12 |
| 21 | 5050150008 | piston rod |
| 22 | 5070330000 | sump |
| 23 | 7060200000 | 6204 bearing |
| 24 | 7071100000 | MIM oil seal 20X47X7 |
| 25 | 4280902000 | Rotor kit |
| 26 | 4013630000 | stator |
| 27 | 7060010000 | Bearing 6203 ZZ 17:40:12 QE6 |
| 28 | 9101720040 | cap |
| 29 | 7018010000 | Screw M6x139 UNI-5737 |
| 30 | 7012070000 | Screw M4X8 UNI-8112 |
| 31 | 7031020000 | Washer Ø4 UNI-3703 |
| 32 | 7011460000 | Screw M6X16 TAP-TITE |
| 33 | 7013090000 | Screw Ø4.2X16 UNI-6949 |
| 34 | 7070370000 | O-ring 114 |
| 35 | 9100010170 | Dipstick |
| 36 | 7650140000 | crankcase cover |
| 37 | 9700000634 | Nut |
| 38 | 9700000633 | wishbone Ø10 |
| 39 | 9101410050 | Crank |
| 40 | 7078150000 | gasket |
| 41 | 7020070000 | Nut M8 UNI-5587 |
| 42 | 7015020000 | Stud M.8X35X14X16 |
| 43 | 7150820000 | plastic hull |
| 44 | 7150830000 | plastic hull |
| 45 | 9700010186 | Ø6 washer |
| 46 | 7201280000 | Fan raff. |
| 47 | 7310590000 | MF.25 V450 capacitor |
| 48 | 7020240000 | DIN 6923-M8 nut |
| 100 | 9101720070 | KIT-ROD HEAD OUT GM143 |
| 101 | 9105000000 | stator |
| 102 | 9105000030 | GROUP HEAD GM 143 (HEAD ECU) |
| 103 | 4080010000 | segments kit |
| 104 | 4190330000 | Conrod-Piston kit |
| 105 | 7459480000 | valve plate kit |
| 106 | 4081100000 | Repair Kit |
| 001A | 7011290000 | Screw M6X35 UNI-5739 |
| 004A | 9100010210 | filter element |
| 007A | 9100010190 | valve start |
| 008A | 9100010320 | Head |
| 009A | 7078580000 | gasket |
| 017A | 9100580030 | ROS42 segment |
| 017B | 9100580040 | ROF42 segment |
| 102A | 9700001335 | head kit |
| 106A | 4081110000 | Repair Kits |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
