FIAC Spare Parts for Compressor SCS 500-600-951

€541.48
Tax included

FIAC Spare Parts for Compressor SCS 500-600-951-981

We are FIAC AIR COMPRESSORS Division original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to solve any maintenance issues for Air Compressor SCS 500 - 600 - 951 - 981 VALID FROM 01/03/2012
ITEM CODE: 5167290008
Quantity
Usually Ships in: 10/15 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

FIAC Spare Parts for Compressor SCS 500-600-951-981

We are FIAC AIR COMPRESSORS Division original spare parts and Accessories Worldwide Dealers at low at Amazing price guarantee, tech assistance with professional repair service able to advise you to purchase the most suitable spare part to solve any maintenance or repair issues for Air Compressor SCS 500 - 600 - 951 - 981 VALID FROM 01/03/2012

In the following table, look for the type of the Compressor and the respective parts of the code.
Air Compressor SCS 500 - 600 - 951 - 981

SCS 500-600-951-981 AB550-AB981 10-14 BAR Pag.1
VALID FROM 01/03/2012 - VALIDO DAL 01/03/2012 (REV-04)
RIF. CODE DESCRIPTION
1 5167290008 Panel
2 7014420000 Screw
3 5168940008 Panel
4 5168900008 Panel
5 5168910008 Panel
6 5168920008 Conveyor
7 5167300008 Panel
8 5167350008 Panel
9 5167360008 Base
10 3020521000 Pump unit
10A 3020980000 Pump unit
11 7011120000 Screw
12 5167370008 Base
13 7011360000 Screw
14 7364420000 Shock absorber
15 7020070000 Nut
16 7370360000 Belt
16A 7370490000 Belt
16B 7370210000 Belt
16C 7370280000 Belt
16D 7371110000 Belt
17 7408230000 Pulley
17A 7408410000 Pulley
17B 7408100000 Pulley
17C 7408830000 Pulley
17D 7406950000 Pulley
17E 7407990000 Pulley
17F 7408470000 Pulley
18 7385370000 Motor
18A 7385380000 Motor
18B 7385180000 Motor
18C 7380840000 Motor
19 7011170000 Screw
20 7030040000 Washer
21 7111030000 Pressure gauge
22 7080890000 Joint
23 7566190000 Hour meter
24 7081040000 Joint
25 7085700000 Joint
26 7326650000 Hour meter
27 7328690000 Pressure switch Motor cable
28 7328700000 Infeed cable
29 7251211000 Pressure switch (4-5,5HP)
29A 7251221000 Pressure switch (7,5-10HP)
29B 7251231000 Pressure switch
29C 7251241000 Pressure switch
30 7230010000 Rilsan hose
31 7084220000 Joint
32 7016070000 Plug
33 7090080000 Plug
34 7511531000 Support
35 7155631000 Instruments support
36 7500440000 Stretch eliminator
37 7500440010 Nut
38 7500070000 Fairlead
39 7236740000 Infeed hose
39A 7236730000 Infeed hose
40 7234530000 Infeed hose
41 7080780000 Joint
42 7080810000 Joint
43 7085080000 Joint
44 5156280008 Tank DISCONTINUED
45 7190150000 Non return
46 7192010000 Safety valve
46A 7192340000 Safety valve
47 7080160000 Joint
48 7012240000 Screw
49 7010500000 Screw
50 7500060000 Fairlead
51 7014450000 Screw
52 7091160000 Plug
53 7081260000 Joint
54 7011210000 Screw
55 7020080000 Nut
56 7030020000 Washer
57 7031030000 Washer
58 7360400000 Rubber
59 5167430008 Lower suport
60 7030060000 Washer
61 5160031148 Suport
61A 5160041158 Suport
62 7236720000 Infeed Rubber hose
62A 7236710000 Infeed Rubber hose
63 4086570000 Infeed Hose kit
64 4086580000 Infeed Hose kit
SCS 500-600-951-981 300 LT 10-14 BAR Pag.2
VALID FROM 01/03/2012 - VALIDO DAL 01/03/2012 (REV-04
100 7471780000 Tank
100A 7471790000 Tank
101 7192010000 Safety valve
101A 7195250000 Safety valve
102 7090030000 Plug
103 7130150000 Tap
104 7082820000 Joint
105 7230080000 Rilsan hose
106 7080970000 Joint
107 7082050000 Joint "T"
108 7130170000 Tap
109 6002550038 Joint "T"
110 7081250000 Joint
111 7090090000 Plug
112 7080160000 Joint
113 7239220000 Hose
114 7081260000 Joint
115 7566390000 Dryer
116 7239300000 Tank/dryer hose
117 7090080000 Plug
118 5164600008 DX Dryer suport
119 5164610008 SX Dryer suport
120 7085020000 Joint
121 7085120000 Joint
122 7090050000 Plug
SCS 500-600-951-981 500 LT 10-14 BAR Pag.3
VALID FROM 01/03/2012 - VALIDO DAL 01/03/2012 (REV-04
200 7472000000 Tank
200A 7472040000 Tank
201 7192090000 Safety valve
201 7195250000 Safety valve
202 7090030000 Plug
203 7130150000 Tap
204 7082820000 Joint
205 7230080000 Rilsan hose
206 7080970000 Joint
207 7082050000 Joint "T"
208 7130170000 Tap
209 6002550038 Joint "T"
210 7081250000 Joint
211 7090090000 Plug
212 7080160000 Joint
213 7239220000 Hose
214 7081260000 Joint
215 7566390000 Dryer
216 7239300000 Tank/dryer hose
217 7090080000 Plug
218 5164600008 DX Dryer suport
219 5164610008 SX Dryer suport
220 7085020000 Joint
221 7085120000 Joint
222 7090050000 Plug
D8SA 8-10-13 bar / 50/60Hz Pag.4
1 7566260010 230V Refrigerant compressor
1,1 7566280010 115V Refrigerant compressor
2 7566260020 230V Fan Motor
2,1 7566320020 115V Fan Motor
3 7566260030 Fan blade
4 7566260040 Grid
5 7565311005 Heat exchanger base
6 7566260060 Condenser
7 7566260070 230V Electronic Controller
7,1 7566280070 115V Electronic Controller
8 7566260080 Probe
9 7566610030 Tap with strainer
10 7566290100 230V Solenoid drain valve
10,1 7566630050 115V Solenoid drain valve
11 7566290120 230V Drain solenoid valve coil
11,1 7566300060 115V Drain solenoid valve coil
12 7566290130 Control panel cover
13 7566290140 Filter dryer
14 7566260140 Heat exchanger bracket
15 7566310080 Front panel
16 7566310090 Side panel
17 7566310100 Rear panel
18 7566310120 Cover
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
SCS 500-600-951-981 - 01/03/2012
12 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10/15 BUSINESS DAYS APPROX.
MORE INFO:
ON DEMAND ONLY
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
New

Download

Diagram Fiac SCS 500-600-951

Diagram Fiac SCS 500-600-951

Download (913.91KB)
