FIAC Parts for Engine Air Compressor FIAC S360-22
€5.70
Tax included
FIAC Parts for Petrol Engine Air Compressor FIAC S360-22
Genuine Parts FIAC for Engine Air Compressor FIAC S360-22 1121440659 09/03/2012 - Honda for use where there is no available electric power supply. Designed with wide-track gauge to facilitate their transport, they have large all-terrain tyres to make it easier to move them on impracticable ground.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FIAC Parts for Petrol Engine Air Compressor FIAC S360-22
Genuine Parts FIAC for Engine Air Compressor FIAC S360-22 1121440659 09/03/2012 - Honda for use where there is no available electric power supply. Designed with wide-track gauge to facilitate their transport, they have large all-terrain tyres to make it easier to move them on impracticable ground. Equipped with pressure regulator/filter and, in the Agri models, also with a lubricator, they are remarkably powerful, sturdy, versatile, handy and easy to use.
In the following table, look for the type of the air compressor and the respective parts of the code .
| Engine Air Compressor FIAC S360-22 1121440659 09/03/2012 Honda Pag.1 |
||
| # | Part Num | Description |
| 1 | 1125010164 | BASE PLATE |
| 2 | 1125150689 | TANK |
| 3 | 1126000027 | UNION TEE |
| 5 | X | SCREW |
| 6 | X | SCREW |
| 7 | X | SCREW |
| 8 | X | SCREW |
| 9 | X | SCREW |
| 10 | X | SCREW |
| 11 | X | SCREW |
| 12 | X | NUT |
| 13 | X | NUT |
| 14 | X | NUT |
| 15 | X | NUT |
| 16 | X | WASHER |
| 17 | X | WASHER |
| 18 | X | WASHER |
| 19 | X | WASHER |
| 20 | X | WASHER |
| 21 | X | GUDGEON PIN |
| 22 | 1127050132 | TAB |
| 23 | 7062680000 | BUSHING |
| 24 | 7080110000 | FITTING |
| 25 | 7080160000 | FITTING |
| 26 | 7080770000 | ELBOW |
| 27 | 7080970000 | FITTING |
| 28 | 7081090000 | FITTING |
| 29 | 7110430000 | PRESSURE GAUGE |
| 30 | 7130160000 | DISCHARGE TAP |
| 31 | 1127150257 | SPACER |
| 32 | 7192010000 | RELIEF VALVE |
| 33 | 7195170000 | AUTOMATIC UNLOADING VALVE |
| 34 | 7230020000 | RILSAN TUBE |
| 35 | 1127230669 | INFEED HOSE |
| 36 | 4170030000 | BELT GUARD KIT |
| 37 | X | WHEEL |
| 38 | 7360040000 | RUBBER FOOT |
| 39 | 7364180000 | VIBRATION-DAMPING |
| 40 | 7370740000 | BELT |
| 41 | 7387650000 | I.C. ENGINE HONDA HP.5-GP160H-QX3 |
| 42 | 7409090000 | PULLEY |
| 43 | 7457960000 | BELT GUARD SUPPORT |
| 44 | 1127450820 | BELT GUARD SUPPORT |
| 45 | 1129101142 | PUMP UNIT |
| 60 | 4057200000 | KIT |
| 61 | 7080970000 | FITTING |
| 62 | 7082530000 | UNION TEE |
| 63 | 7100480000 | PRESSURE REDUCER |
| 64 | 7100930000 | LUBRICATOR |
| 65 | 7110240000 | PRESSURE GAUGE |
| 66 | 7130570000 | TAP |
| 100 | 1120001836 | SCREWS KIT |
| 101 | 1120001968 | KIT |
| Pump Unit AB360 Pag.2 |
||
| # | Part Num. | Description |
| 1 | 9700001075 | CRANKCASE |
| 2 | 9700001076 | CASING COVER |
| 3 | 9700000531 | SCREW |
| 4 | 9700001077 | O RING |
| 5 | 9100270140 | CRANKSHAFT |
| 6 | 7060180000 | BEARING |
| 7 | 7060200000 | BEARING |
| 8 | 9100270150 | OIL SEAL |
| 9 | 9100270160 | COVER |
| 10 | 9100270170 | COVER |
| 11 | 9100280010 | O RING |
| 12 | 7011420000 | SCREW |
| 13 | 9100280020 | FEATHER |
| 14 | 9100270010 | Connecting rod |
| 15 | 9100270020 | GUDGEON PIN |
| 16 | 9100270030 | PISTON |
| 17 | 4080120000 | PISTON RING KIT |
| 18 | 9100270070 | RING |
| 19 | 9100270080 | CYLINDER |
| 20 | 7012220000 | SCREW |
| 21 | 9700000408 | OIL SIGHT GLASS |
| 22 | 9100270180 | O RING |
| 23 | 9100270190 | GASKET |
| 24 | 9100270090 | Valve plate |
| 25 | 7198220000 | VALVE |
| 25A | 7010790000 | SCREW |
| 26 | 7198210000 | VALVE |
| 27 | 9100270210 | GASKET |
| 28 | 9100270100 | HEAD |
| 31 | 9700001902 | INTAKE FILTER KIT |
| 31A | 7210010000 | FILTER CARTRIDGE |
| 33 | 7010080000 | SCREW |
| 33A | 7030030000 | WASHER |
| 34 | 9100270220 | AIR CONVEYOR |
| 35 | 7012090000 | SCREW |
| 36 | 7011460000 | SCREW |
| 37 | 9700000300 | KIT OIL VENT CAP |
| 38 | 7030270000 | WASHER |
| 39 | 9100270230 | FLYWHEEL |
| 41 | 9700010087 | WASHER |
| 42 | 9700002651 | COOLER |
| 43 | 9100270280 | O RING |
| 100 | 9700003272 | VALVE PLATE KIT |
| 102 | 9700002034 | PISTON KIT |
| 102A | 9700010170 | CONROD PISTON KIT |
| 103 | 9700002932 | GASKET KIT |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fiac websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Fiac brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
