Femi Spare Parts for Miter Saw 911 EVO-8436047
€3.26
Tax included
Femi Spare Parts for Miter Saw 911 EVO-8436047
Femi Original spare parts at attractive and competitive prices on the web, we are a service center with a repair service able to quickly solve the maintenance or repair any issues for Miter Saw 911 EVO - 8436047.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Femi Spare Parts for Miter Saw 911 EVO-8436047
Femi Original spare parts at attractive and competitive prices on the web, we are a service center with a repair service able to quickly solve the maintenance or repair any issues for Miter Saw 911 EVO - 8436047.
In the following table, look for the model of Miter Saw and the respective parts of the code.
| Wood Miter Saw 911 EVO-8436047 | ||
| # | Part Num. | Description |
| 1 | 0320826 | SOCKET HEAD SCREW |
| 2 | 0120308 | WASHER |
| 3 | 0120714 | PLAIN WASHER |
| 4 | 5190299 | WHEEL FLANGE |
| 5 | 5061037 | BLADE BUSHING |
| 7 | 5182862 | ARM PROTECTION |
| 10 | 5100146 | NUT |
| 11 | 5170001 | PROTECTION LOCKING PIN |
| 12 | 7130706 | BLADE GUARD WITH LEVERS |
| 13 | 5000742 | BLADE SHAFT |
| 14 | 0151136 | SNAP RING |
| 15 | 0155004 | ELASTIC RING |
| 17 | 5182588 | BOX COVER |
| 19 | 5182872 | CABLE PROTECTION |
| 20 | 5080129 | SPRING |
| 22 | 5100147 | NUT |
| 23 | 5120655 | SPACER |
| 24 | 0536203 | BALL BEARING |
| 25 | 0215111 | BELT |
| 26 | 5133008 | RIVING KNIFE PLATE |
| 28 | 0120206 | WASHER |
| 29 | 5100088 | ADJUST SCREW |
| 32 | 5183067 | RIVING KNIFE |
| 33 | 5050144 | LEFT HANDLE |
| 35 | 0151116 | SNAP RING |
| 36 | 7013152 | ROTOR |
| 37 | 5138007 | LEFT HANDLE SUPPORT |
| 39 | 5138006 | RIGHT HANDLE SUPPORT |
| 41 | 0802611 | SWITCH |
| 42 | 5050143 | RIGHT HALF GRIP |
| 43 | 5143013 | HEAD RELEASE BUTTON |
| 44 | 7130606 | HEAD RELEASE LINKAGE ASS'Y |
| 45 | 5080130 | SPRING |
| 46 | 5214400 | WHEEL |
| 47 | 0140070 | KNOB |
| 48 | 5137945 | MOTOR SUPPORT |
| 49 | 7801105 | MOTOR BODY |
| 50 | 5050145 | RIGHT HANDLE |
| 52 | 0536202 | BALL BEARING |
| 53 | 5137946 | BELT SUPPORT |
| 54 | 5100143 | SPACER |
| 57 | 5182853 | CONDENSATOR COVER |
| 58 | 0536201 | BALL BEARING |
| 59 | 5112027 | MOTOR FAN |
| 60 | 5182930 | ELECTRIC BOX |
| 61 | 5154501 | CABLE LOCKING DEVICE |
| 64 | 0802606 | SWITCH |
| 66 | 0840028 | CAPACITOR |
| 68 | 5141016 | ADJUST HANDWHEEL |
| 69 | 5182850 | MOTOR COVER |
| 71 | 5042827 | MITRE SAW ARM |
| 72 | 5181887 | ADDITIONAL PROTECTION |
| 73 | 4130474 | UPPER FENCE |
| 76 | 5181888 | UPPER PROTECTION |
| 78 | 0400645 | SCREW TTQST 6x45 |
| 83 | 7130559 | ROD STOP ASS'Y |
| 84 | 5130838 | UPPER TABLE FRONT GUIDE |
| 85 | 0170004 | BALL |
| 86 | 5130480 | FENCE GUIDE |
| 88 | 5138019 | FRICTION PLATE |
| 89 | 5871070 | CABLE |
| 90 | 0140103 | WING NUT |
| 91 | 7130710 | UPPER FENCE ASS'Y |
| 92 | 5130790 | ROD STOP |
| 93 | 5130767 | UPPER TABLE REAR GUIDE |
| 94 | 0107004 | WING NUT |
| 97 | 0120706 | PLAIN WASHER |
| 98 | 7130709 | UPPER WORKTABLE ASS'Y |
| 101 | 5181666 | LOWER PROTECTION |
| 102 | 5181003 | RUBBER PROTECTION |
| 104 | 5182575 | BOX COVER |
| 107 | 0080256 | SPRING WASHER |
| 108 | 5063069 | BUSHING |
| 109 | 5124051 | RING |
| 110 | 5080168 | SPRING |
| 111 | 5181822 | FIX PROTECTION |
| 113 | 0147006 | HAND LEVER |
| 114 | 5120646 | SPACER |
| 115 | 0450880 | TIE ROD |
| 117 | 5181819 | LOWER PROTECTION |
| 118 | 5133789 | MITRE SAW BASE |
| 120 | 0080257 | SPRING WASHER |
| 123 | 5137902 | ANGULAR BRACKET |
| 124 | 5152076 | BRAKE RING |
| 125 | 0140078 | WING NUT |
| 126 | 5081026 | SPRING |
| 129 | 5171077 | SWIVEL SUPPORT PIN |
| 130 | 5142096 | RELEASE LEVER |
| 131 | 5133003 | SLIDING BRACKET |
| 132 | 5137793 | REST FOOT |
| 134 | 5182900 | PLASTIC COVER |
| 135 | 5159514 | JOINT INDEX |
| 137 | 5121552 | SPACER |
| 138 | 5130901 | BASE EXTENSION |
| 139 | 5138002 | SWIVEL SUPPORT |
| 140 | 5182569 | SUPPORT COVER |
| 142 | 0063035 | BUSH |
| 145 | 0151116 | SNAP RING |
| 146 | 5181821 | FIX PROTECTION |
| 148 | 0152318 | SPRING PIN |
| 149 | 5170530 | JOINT PIN |
| 150 | 5137872 | JOINT |
| 152 | 5001560 | JOINT SHAFT |
| 153 | 0120708 | FLAT WASHER |
| 156 | 5159506 | JOINT INDEX |
| 157 | 7130624 | JOINT ASSY |
| 158 | 5143012 | LOCKING BUTTON |
| 160 | 5153504 | CABLE LOCKING DEVICE |
| 161 | 5182916 | ELECTRIC BOX |
| 162 | 5873585 | CABLE |
| 165 | 7130701 | VERTICAL CLAMP ASSY |
| 166 | 5152066 | BRAKE PIN |
| 167 | 5081041 | SPRING |
| * | 5130966 | BASE HOLDER |
