Femi Spare Parts for Wood Mitre Saw 305 PRO-8436044
€3.26
Tax included
Femi Spare Parts for Wood Mitre Saw 305 PRO-8436044
FEMI Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Wood Mitre Saw 305 PRO - 8436044.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Femi Spare Parts for Wood Mitre Saw 305 PRO-8436044
FEMI Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Wood Mitre Saw 305 PRO - 8436044.
In the following table, look for the model of Miter Saw and the respective parts of the code.
| Wood Miter Saw 305 PRO-8436044 | ||
| # | Part Num. | Description |
| 1 | 7130709 | UPPER WORKTABLE GROUP |
| 3 | 7130657 | COMPLETE UPPER GUIDE |
| 4 | 0140103 | WING NUT |
| 5 | 5130503 | FENCE GUIDE |
| 7 | 5130480 | FENCE GUIDE |
| 9 | 5138019 | FRICTION PLATE |
| 10 | 5130767 | UPPER TABLE REAR GUIDE |
| 11 | 5183067 | RIVING KNIFE |
| 13 | 5100143 | SPACER |
| 14 | 5080130 | SPRING |
| 15 | 7130575 | LINKAGE ASS'Y |
| 16 | 5182852 | BOX COVER |
| 17 | 5154501 | CABLE LOCKING DEVICE |
| 20 | 0802606 | ON/OFF SWITCH |
| 0155001 | THICKNESS WASHER | |
| 21 | 0155004 | SPRING RING |
| 22 | 5182589 | BOX COVER |
| 25 | 5182572 | CABLE COVER |
| 27 | 5042825 | MITRE SAW ARM |
| 29 | 0410606 | HEADLESS SCREW |
| 30 | 0106115 | SELF-LOCKING RING NUT |
| 32 | 5182862 | ARM PROTECTION |
| 34 | 5181666 | LOWER PROTECTION |
| 37 | 5181888 | UPPER PROTECTION |
| 39 | 5181887 | ADDITIONAL PROTECTION |
| 40 | 0400645 | SCREW TQST 6x45 |
| 41 | 5061037 | BLADE BUSH |
| 42 | 5120655 | SPACER |
| 44 | 5170001 | PROTECTION LOCKING PIN |
| 45 | 7130706 | BLADE TRASP.PROTECTION WITH LEVERS |
| 46 | 5080129 | SPRING |
| 47 | 5100147 | NUT |
| 48 | 5133008 | RIVING KNIFE PLATE |
| 50 | 0120206 | WASHER |
| 51 | 0140070 | KNOB |
| 52 | 0526203 | BALL BEARING |
| 55 | 0840028 | CAPACITOR |
| 57 | 5182850 | MOTOR COVER |
| 59 | 5112027 | MOTOR FAN |
| 60 | 5081041 | SPRING |
| 61 | 5152066 | BRAKE PIN |
| 63 | 0536201 | BALL BEARING |
| 64 | 5190295 | WHEEL FLANGE |
| 65 | 7801109 | MOTOR BODY |
| 66 | 5182853 | CAPACITOR COVER |
| 68 | 0120308 | WASHER |
| 69 | 0320826 | SOCKET HEAD SCREW |
| 70 | 7013644 | ARMATURE |
| 71 | 5138007 | LEFT HANDLE SUPPORT |
| 73 | 5138006 | RIGHT HANDLE SUPPORT |
| 74 | 5050144 | LEFT HANDLE |
| 76 | 5143013 | HEAD RELEASE BUTTON |
| 77 | 5050143 | RIGHT HALF GRIP |
| 78 | 0120714 | FLAT WASHER |
| 79 | 5143012 | LOCKING BUTTON |
| 80 | 0802611 | SWITCH |
| 81 | 5001560 | JOINT SHAFT |
| 83 | 7130624 | JOINT ASSY |
| 84 | 5159506 | JOINT INDEX |
| 88 | 0080256 | SPRING WASHER |
| 89 | 5063069 | BUSHING |
| 90 | 5124051 | RING |
| 91 | 5080135 | SPRING |
| 92 | 5181822 | FIX PROTECTION |
| 94 | 0120708 | PLAIN WASHER |
| 95 | 5137872 | JOINT |
| 96 | 0450880 | TIE ROD |
| 98 | 5181819 | LOWER PROTECTION |
| 99 | 5133789 | MITRE SAW BASE |
| 101 | 0080257 | SPRING WASHER |
| 102 | 0120708 | PLAIN WASHER |
| 104 | 5137902 | ANGULAR BRACKET |
| 105 | 0140078 | WING NUT |
| 106 | 5081026 | SPRING |
| 109 | 5171077 | SWIVEL SUPPORT PIN |
| 110 | 5142096 | RELEASE LEVER |
| 111 | 5133003 | SLIDING BRACKET |
| 112 | 5137793 | REST FOOT |
| 114 | 5182900 | PLASTIC COVER |
| 115 | 5159514 | JOINT INDEX |
| 117 | 5121552 | SPACER |
| 118 | 5138002 | SWIVEL SUPPORT |
| 119 | 5182569 | SUPPORT COVER |
| 121 | 0063035 | BUSHING |
| 122 | 5170530 | JOINT PIN |
| 123 | 0152319 | SPRING PIN |
| 126 | 5181821 | FIX PROTECTION |
| 128 | 0151116 | SNAP RING |
| 129 | 7130701 | VERTICAL CLAMP ASS'Y |
| 130 | 0147006 | RATCHET HAND LEVER |
| 131 | 0101406 | SELF-LOCKING SPECIAL NUT M6 |
| 132 | 0120106 | SHOCK ABSORBER |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Femi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Femi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Femi 305 PRO 8436044
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK ITEM CODE OR S/N FEMI:
- FEMI ITEM CODE START WITH (8....) AND HAVE 7 DIGITS
