Femi Spare Parts for Wood Mitre Saw 745 - 8400722
FEMI service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Wood Mitre Saw 745 - 8400722.In the following table, look for the model of the Mitre Saw and the respective parts of the code.
| Wood Mitre Saw 745-8400722 | |
| Part Num. | Description |
| 0063035 | BUSHING |
| 0080256 | SPRING WASHER |
| 0080258 | SPRING WASHER |
| 0106115 | SELF-LOCKING RING NUT |
| 0107004 | WING NUT |
| 0107005 | WING NUT |
| 0120206 | WASHER |
| 0120308 | WASHER |
| 0120708 | PLAIN WASHER |
| 0120714 | PLAIN WASHER |
| 0140070 | KNOB |
| 0147006 | HAND LEVER |
| 0147007 | HAND LEVER |
| 0151040 | SNAP RING |
| 0151116 | SNAP RING |
| 0151136 | SNAP RING |
| 0151405 | SNAP RING |
| 0152319 | ELASTIC PIN |
| 0154514 | FAIRLEAD |
| 0155148 | THICKNESS WASHER |
| 0320826 | SOCKET HEAD SCREW |
| 0450880 | TIE ROD |
| 0526201 | BALL BEARING |
| 0526203 | BALL BEARING |
| 0801400 | SWITCH |
| 0802602 | SWITCH |
| 0811200 | RELAY |
| 0840028 | CAPACITOR |
| 5001560 | JOINT SHAFT |
| 5042697 | ARM PROTECTION ( NEW CODE 7075019 ) |
| 5044026 | SIDE CAP |
| 5044027 | SIDE CAP |
| 5050118 | LOWER HALF-HANDLE |
| 5050119 | UPPER HALF-HANDLE |
| 5061037 | BLADE BUSH |
| 5063031 | BUSHING |
| 5080122 | SPRING |
| 5080129 | SPRING |
| 5080130 | SPRING |
| 5080135 | SPRING |
| 5081012 | SPRING |
| 5081016 | SPRING |
| 5081017 | MOTOR BRAKE SPRING |
| 5100146 | NUT |
| 5100147 | NUT |
| 5112015 | MOTOR FAN |
| 5120646 | SPACER |
| 5120655 | SPACER |
| 5121551 | SPACER |
| 5121552 | SPACER |
| 5124051 | RING |
| 5130417 | SQUARE |
| 5130418 | BRACKET |
| 5130419 | GUIDE |
| 5130420 | UPPER WORKING TABLE |
| 5130421 | SQUARE |
| 5130766 | UPPER TABLE FRONT GUIDE |
| 5130767 | UPPER TABLE REAR GUIDE |
| 5133003 | SLIDING BRACKET |
| 5133008 | RIVING KNIFE PLATE |
| 5137791 | SWIVEL SUPPORT |
| 5137793 | REST FOOT |
| 5137843 | JOINT |
| 5141009 | ADJUSTING HANDWHEEL |
| 5142028 | LEVER |
| 5142052 | LEVER |
| 5143004 | RELEASE BUTTON |
| 5152068 | BRAKE RING |
| 5154103 | CABLE LOCKING DEVICE |
| 5155151 | BRAKE BUSHING - DISCONTINUED |
| 5155152 | BRAKE DEVICE - BUY 7075075 MODIFICATION KIT |
| 5159506 | JOINT INDEX |
| 5170001 | PROTECTION LOCKING PIN |
| 5170002 | RELEASE PIN |
| 5170530 | JOINT PIN |
| 5171023 | SWIVEL SUPPORT PIN |
| 5181665 | UPPER PROTECTION |
| 5181666 | LOWER PROTECTION |
| 5181668 | LEFT PROTECTION |
| 5181669 | RIGHT PROTECTION |
| 5181670 | MOBILE PROTECTION |
| 5181673 | PROTECTION |
| 5182508 | SUPPORT COVER |
| 5182826 | MOTOR COVER |
| 5182827 | CONDENSATOR COVER |
| 5183067 | RIVING KNIFE |
| 5190295 | WHEEL FLANGE |
| 5401349 | GRADUATE PLATE |
| 5401404 | GRADUATE PLATE |
| 5401416 | GRADUATE PLATE |
| 5401417 | GRADUATE PLATE |
| 5871040 | CABLE |
| 7013135 | ARMATURE |
| 7801062 | MOTOR BODY |
| 5181667 | CARTER ASSEMBLY = 7130585 |
| 7075075 | BRAKE SYSTEM MODIFICATION KIT |
