Femi Spare Parts for Wood Mitre Saw 742 - 8420021
€133.82
Tax included
Femi Spare Parts for Wood Mitre Saw 742 - 8420021
Femi genuine spare parts or replacement parts for to repair Wood Mitre Saw 742 - 8420021.Fix Your Wood Mitre Saw 742. All Spares are Ready at discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Femi Spare Parts for Wood Mitre Saw 742 - 8420021
Fix Your Wood Mitre Saw 742 - 8420021. All Spares are Ready at discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Mitre Saw and the respective parts of the code.
| Wood Mitre Saw 742-8420021 | ||
| # | Part Num. | Description |
| 1 | 4130420 | UPPER TABLE |
| 3 | 5401416 | GRADUATE PLATE |
| 4 | 5044026 | SIDE CAP |
| 5 | 5044027 | SIDE CAP |
| 6 | 5130421 | SQUARE |
| 8 | 5871040 | CABLE |
| 10 | 5130417 | SQUARE |
| 12 | 5130433 | GUIDE |
| 13 | 5130432 | BRACKET |
| 14 | 0107004 | WING NUT |
| 16 | 5100143 | SPACER |
| 18 | 7130587 | LINKAGE ASS'Y |
| 19 | 5080130 | SPRING |
| 24 | 5182543 | SWITCH COVER |
| 25 | 7820118 | ELECTRONIC CARD |
| 26 | 5182858 | SWITCH BOX |
| 27 | 5182850 | MOTOR COVER |
| 29 | 5042769 | MITRE-SAW BODY |
| 31 | 0140084 | KNOB |
| 32 | 5154103 | CABLE LOCKING DEVICE |
| 33 | 5137847 | RIVING KNIFE SUPPORT |
| 34 | 5183068 | RIVING KNIFE |
| 35 | 5130767 | UPPER TABLE REAR GUIDE |
| 37 | 5181645 | PROTECTION |
| 38 | 5133008 | RIVING KNIFE PLATE |
| 39 | 0120206 | WASHER |
| 40 | 0140070 | KNOB |
| 41 | 5100147 | NUT |
| 42 | 5120655 | SPACER |
| 43 | 0151136 | SNAP RING |
| 44 | 0155148 | THICKNESS WASHER |
| 45 | 7130586 | LEVER AND PROTECTION GROUP |
| 47 | 5182827 | CAPACITOR COVER |
| 48 | 5063026 | BUSHING |
| 49 | 0526203 | BALL BEARING |
| 50 | 0151040 | SNAP RING |
| 51 | 0840029 | CAPACITOR |
| 53 | 0151512 | SPRING RING |
| 54 | 5112027 | MOTOR FAN |
| 55 | 5081024 | SPRING |
| 56 | 5152066 | BRAKE PIN |
| 57 | 0526201 | BALL BEARING |
| 60 | 5050126 | HANDLE GRIP ASS'Y (5050145+5050146+5143018) |
| 61 | 7801074 | MOTOR BODY |
| 62 | 0802611 | SWITCH |
| 63 | 5142071 | LEVER |
| 64 | 5143007 | RELEASE BUTTON |
| 65 | 5081022 | SPRING |
| 66 | 5143009 | SAFETY BUTTON |
| 67 | 5143006 | SAFETY BUTTON |
| 69 | 7013141 | ARMATURE |
| 70 | 5061037 | BLADE BUSH |
| 71 | 5190291 | WHEEL FLANGE |
| 72 | 0120714 | PLAIN WASHER |
| 73 | 0120308 | WASHER |
| 74 | 0320826 | SOCKET HEAD SCREW |
| 75 | 5120649 | SPACER |
| 76 | 5080129 | SPRING |
| 77 | 5080122 | SPRING |
| 78 | 5130766 | UPPER TABLE FRONT GUIDE |
| 79 | 5401404 | GRADUATE PLATE |
| 80 | 7130586 | LEVER AND PROTECTION GROUP |
| 81 | 5170001 | PROTECTION LOCKING PIN |
| 82 | 5100146 | NUT |
| 85 | 0151405 | SNAP RING |
| 86 | 5081016 | SPRING |
| 87 | 5141009 | ADJUSTING HANDWHEEL |
| 89 | 5181665 | UPPER PROTECTION |
| 91 | 5181670 | MOBILE PROTECTION |
| 92 | 5001561 | SHAFT |
| 93 | 5137846 | JOINT |
| 94 | 5124042 | WASHER |
| 97 | 0080256 | SPRING WASHER |
| 98 | 5063031 | BUSHING |
| 99 | 5080121 | SPRING |
| 100 | 0150616 | CYLINDRIC PIN |
| 101 | 5181644 | PROTECTION |
| 103 | 0147006 | HAND LEVER |
| 104 | 5120646 | SPACER |
| 105 | 0450880 | TIE ROD |
| 107 | 5181673 | PROTECTION |
| 110 | 5170530 | JOINT PIN |
| 111 | 0152319 | ELASTIC PIN |
| 113 | 0151116 | SNAP RING |
| 114 | 5181643 | PROTECTION |
| 117 | 0063035 | BUSHING |
| 119 | 5182544 | COVER |
| 120 | 5137848 | SWIVEL SUPPORT |
| 121 | 0147007 | HAND LEVER |
| 123 | 5121552 | SPACER |
| 124 | 5137793 | REST FOOT |
| 126 | 5133003 | SLIDING BRACKET |
| 127 | 5142072 | LEVER |
| 128 | 5171023 | SWIVEL SUPPORT PIN |
| 129 | 0152319 | ELASTIC PIN |
| 130 | 5081012 | SPRING |
| 131 | 5401349 | GRADUATE PLATE |
| 133 | 5401417 | GRADUATE PLATE |
| 134 | 5133680 | MITRE SAW BASE |
| 138 | 5121551 | SPACER |
| 139 | 7130623 | JOINT ASS'Y |
| 140 | 7130661 | UPPER BENCH GUIDE ASSY |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Femi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Femi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
