Femi Spare Parts for Stationary Band Saw N266 XL-8488027
€17.28
Tax included
Femi Spare Parts for Stationary Band Saw N266 XL
We have the original FEMI parts and tool repair help you need to get your tools running like new again.Fix Your Stationary Band Saw N266 X L- 8488027. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Femi Spare Parts for Stationary Band Saw N266 XL
Fix Your Stationary Band Saw N266 XL - 8488027. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of Band Saw and the respective parts of the code.
| Segatrice a Nastro N266 XL-8488027 | ||
| # | Part Num. | Description |
| 1 | 0106140 | SELF-LOCKING NUT |
| 2 | 5124078 | WASHER |
| 3 | 0551202 | CONIC BEARING |
| 4 | 5137967 | SWIVEL SUPPORT |
| 5 | 5120666 | SPACER |
| 7 | 5171067 | JOINT SHAFT |
| 8 | 5171065 | VICE PIN |
| 9 | 5182560 | VICE COVER |
| 10 | 5171069 | QUICK LOCKING BUSHING |
| 12 | 0451250 | TIE ROD |
| 13 | 0606205 | BALL BEARING |
| 14 | 0606004 | BALL BEARING |
| 17 | 5401935 NEW 7075064 |
(incluso nel cod./eingeschlossen in Kode/compris dans le NEW code: 7075064) REPLACEMENT KIT FOR GRADUATED VICE PLATE replaces/replaces 5401483, 5401935 and 5401661 |
| 18 | 5182538 | TANK FILTER |
| 20 | 0120706 | PLAIN WASHER |
| 21 | 7113524 | ELECTRIC PUMP |
| 22 | 0240303 | SPHERE VALVE |
| 23 | 5870852 | CABLE |
| 25 | 0120710 | PLAIN WASHER |
| 28 | 5152608 | VICE JAW |
| 30 | 5181762 | TANK BASE PROTECTION |
| 32 | 5181777 | FRONT COLUMN PANEL |
| 36 | 0120708 | PLAIN WASHER |
| 37 | 5124033 | WASHER |
| 38 | 5142086 | QUICK LOCKING LEVER |
| 39 | 5133718 | RIGHT SIDE PANEL |
| 40 | 0140082 | KNOB |
| 41 | 0152630 | ELASTIC PIN |
| 42 | 5050138 | HEAD LEVER |
| 43 | 5191023 | VICE FLANGE |
| 44 | 0551405 | BALL BEARING |
| 45 | 5171070 | SCREW PIN |
| 46 | 5152609 | VICE JAW |
| 47 | 5133715 | TANK BASE |
| 49 | 5130869 | ANGLE STOPPER |
| 51 | 5142091 | ANGULAR VICE LOCKING |
| 53 | 5100333 | SCREW |
| 54 | 5080153 | SPRING |
| 56 | 5159517 | INDEX |
| 58 | 5130868 | SLIDING VICE |
| 59 | 5152607 | VICE JAW |
| 61 | 5137966 | VICE BASE |
| 62 | 0140073 | HANDGRIP |
| 63 | 5151507 | LOCKING PIN |
| 64 | 5182561 | PUMP SUPPORT |
| 65 | 5133716 | BASE |
| 66 | 7130628 | LOCK ROD ASS'Y |
| 67 | 4130452 | ROD STOP BRACKET |
| 68 | 7130628 | ROD STOP BRACKET |
| 69 | 5151558 | SLIDING PIN |
| 70 | 5171064 | PIN |
| 72 | 5401858 | GRADUATE PLATE |
| 73 | 0596405 | BALL BEARING |
| 74 | 5001574 | SHAFT |
| 75 | 0150152 | FEATHER |
| 76 | 0150151 | FEATHER |
| 78 | 5120668 | SPACER |
| 80 | 5192023 | MOTOR REDUCTOR FLANGE |
| 81 | 0120121 | WASHER |
| 82 | 7211003 | REDUCTOR |
| 83 | 5124079 | WASHER |
| 86 | 7820107 | ELECTRONIC SPEED REGULATOR |
| 87 | 5142059 | LEVER |
| 88 | 5143005 | MICROSWITCH BUTTON |
| 89 | 5124060 | WASHER |
| 90 | 5182842 | SWITCH BOX |
| 91 | 0801101 | MICROSWITCH |
| 92 | 0140058 | HANDWHEEL |
| 93 | 0080260 | SPRING WASHER |
| 95 | 5222009 | SPRING DUST PROTECTION |
| 96 | 5066016 | BUSHING |
| 97 | 0711528 | CAGE BEARING |
| 98 | 5124030 | WASHER |
| 99 | 5122017 | SPRING CONTEINER |
| 101 | 5100505 | BLADE TENSIONING SCREW |
| 102 | 5142058 | LEVER |
| 103 | 5081007 | SPRING |
| 104 | 5001575 | SHAFT |
| 105 | 5130871 | WHEEL GUIDE |
| 107 | 5214229 | FREE WHEEL |
| 108 | 0106120 | SELF-LOCKING RING NUT |
| 109 | 5120667 | SPACER |
| 110 | 5214030 | DRIVING WHEEL |
| 111 | 0606209 | BALL BEARING |
| 112 | 5152072 | PIN |
| 114 | 0894008 | LIGHT PILOT PANEL |
| 115 | 5182885 | FAN COVER |
| 116 | 5112030 | MOTOR FAN |
| 117 | 5182531 | PLASTIC COVER |
| 118 | 0606204 | BALL BEARING |
| 119 | 5042811 | BAND SAW BODY |
| 121 | 5130870 | WHEEL GUIDE |
| 122 | 5130872 | WHEEL SUPPORT |
| 124 | 7801826 | MOTOR |
| 125 | 5080156 | SPRING |
| 126 | 5080157 | SPRING |
| 127 | 5124080 | WASHER |
| 129 | 0802324 | SWITCH, SINGLE PHASE |
| 130 | 5050136 | HANDLE |
| 134 | 5151509 | DAMPER FULCRUM |
| 135 | 5050137 | HANDLE |
| 137 | 5130459 | END RUN BRACKET |
| 138 | 0240305 | COOLING LIQUID TAP |
| 139 | 1855807 | COOLING LIQUID PIPE |
| 140 | 0241448 | CONNECTOR |
| 142 | 0123315 | RUBBER WASHER |
| 143 | 5181770 | BLADE PROTECTION |
| 144 | 0140077 | WING NUT |
| 145 | 1855808 | COOLING LIQUID PIPE |
| 146 | 0241447 | CONNECTOR |
| 147 | 0880009 | CABLE LOCKING DEVICE |
| 148 | 5181779 | CABLE PROTECTION |
| 149 | 7240302 | LUBRICATION GROUP |
| 150 | 7130627 | COMPLETE DAMPER GROUP |
| 151 | 5171066 | DAMPER FLANGE |
| 156 | 5173033 | TIE ROD |
| 157 | 5040011 | DAMPER BODY |
| 158 | 5130865 | GUIDE SUPPORT |
| 159 | 0606000 | BALL BEARING |
| 160 | 5130867 | GUIDE SUPPORT |
| 162 | 5120669 | SPACER |
| 163 | 0600608 | BALL BEARING |
| 165 | 3249802 | BLADE GUIDE BIT |
| 168 | 5120670 | SPACER |
| 169 | 7130713 | REAR FIX BLADE GUDE |
| 171 | 5130866 | SLIDING BLADE GUIDE |
| 172 | 0894009 | LIGHT PILOT |
| 173 | 5181776 | SLIDING PROTECTION |
| 174 | 0147018 | HAND LEVER |
| 175 | 5171068 | BLADE GUIDE BRACKET |
| 176 | 0892102 | FUSE SUPPORT |
| 177 | 0810011 | CONTACTOR |
| 178 | 0810003 | MAGNETOTHERMIC SWITCH |
| 181 | 0801206 | SAFETY MICROSWITCH |
| 183 | 5070002 | CONTROL PANEL SUPPORT |
| 185 | 0880007 | CABLE LOCKING DEVICE |
| 186 | 0880008 | NUT FOR CABLE |
| 188 | 5137977 | CONTROL PANEL REST |
| 189 | 7132506 | FRONT SLIDING GUIDE GROUP |
| 190 | 5402336 | ELECTRIC BOX PANEL |
| 191 | 0803617 | SWITCH |
| 192 | 0820002 | SPEED COMMUTATOR |
| 193 | 5137970 | CONTROL PANEL SUPPORT |
| 195 | 7130712 | REAR FIX BLADE GUDE |
| 197 | 0806022 | EMERGENCY STOP BUTTON |
| 198 | 0806023 | KEY EMERGENCY STOP |
| 199 | 0893016 | FUSE |
| 200 | 0806024 | VOLTAGE COIL |
| 201 | 0810017 | THERMIC SWITCH |
| 202 | 0892105 | FUSE SUPPORT |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Femi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Femi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Femi N266 XL - 8488027
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK ITEM CODE OR S/N FEMI:
- FEMI ITEM CODE START WITH (8....) AND HAVE 7 DIGITS
