Femi Spare Parts for Band Saw for Metal 784XL/8485023
€18.10
Tax included
Femi Spare Parts for Band Saw for Metal 784XL/8485023
Femi genuine spare parts or replacement parts for to repair Electric Band Saws for Metal 784XL - 8485023.Electronic speed adjustment, performances, easy to carry
- Max cutting capacity D.120 mm - 120x115 mm
- Weight 17 Kg
- Bandsaw blade 1440x13x0.65
- Powerul 1200 Watt motor
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Femi Spare Parts for Band Saw for Metal 784XL/8485023
Femi genuine spare parts or replacement parts for to repair Electric Band Saws for Metal 784XL - 8485023.
In the following table, look for the model of the Band Saw and the respective parts of the code.
| Band Saw for Metal 784XL/8485023 | ||
| # | Part Num. | Description |
| 1 | 0147002 | HAND LEVER |
| 3 | 5130427 | PLATE |
| 4 | 7133603 | SWIVEL SUPPORT GROUP |
| 6 | 0102110 | CAP NUT |
| 7 | 5130426 | PLATE |
| 8 | 5063034 | BUSHING |
| 9 | 5100320 | VICE SCREW |
| 11 | 5042850 | MOBILE VICE |
| 13 | 5124029 | ADJUST WASHER |
| 14 | 0402905 | RIVET |
| 15 | 5401319 | GRADUATE PLATE |
| 16 | 7130535 | ROD STOP GROUP |
| 17 | 0401001 | SCREW |
| 18 | 5137842 | BASE FOOT |
| 19 | 5133635 | BAND SAW BASE |
| 22 | 0063041 | BUSH |
| 25 | 0155143 | THICKNESS WASHER |
| 26 | 5080116 | SPRING |
| 27 | 7130670 | VICE GROUP |
| 28 | 0311080 | EXAGONAL HEAD SCREW |
| 29 | 0101408 | SELF-LOCKING NUT |
| 30 | 0155150 | THICKNESS WASHER |
| 31 | 5130416 | PLATE |
| 32 | 5130428 | SLIDING VICE PLATE |
| 34 | 5152613 | VICE JAW |
| 37 | 0150701 | CYLINDRIC PIN WITH SLOT |
| 38 | 5042849 | VICE BASE |
| 39 | 5150005 | VICE PIN STOPPER |
| 41 | 5142014 | LEVER |
| 42 | 5120663 | SPACER |
| 43 | 0596002 | BALL BEARING |
| 44 | 0155152 | THICKNESS WASHER |
| 45 | 5137914 | WHEEL SUPPORT |
| 46 | 5001572 | SHAFT |
| 48 | 5100507 | BLADE TENSIONING SCREW |
| 49 | 0080256 | SPRING WASHER |
| 50 | 5130734 | WHEEL GUIDE |
| 51 | 5142070 | LEVER |
| 52 | 5870847 | CABLE |
| 55 | 5050122 | HANDLE COVER |
| 56 | 0802317 | SWITCH |
| 57 | 5050121 | HANDLE |
| 60 | 5154103 | CABLE LOCKING DEVICE |
| 61 | 5124064 | WASHER |
| 64 | 7214212 | DRIVING WHEEL GROUP |
| 65 | 5124065 | WASHER |
| 66 | 0606205 | BALL BEARING |
| 67 | 5124066 | WASHER |
| 70 | 5181728 | ARM PROTECTION |
| 71 | 0179901 | NEEDLE |
| 72 | 5214225 | FREE WHEEL |
| 73 | 5124062 | WASHER |
| 74 | 7130589 | COMPLETE BLADE TENSION DEVICE |
| 76 | 0124026 | THICKNESS WASHER |
| 77 | 5081005 | SPRING |
| 78 | 0590634 | BALL BEARING |
| 79 | 0129004 | INOX STEEL WASHER |
| 81 | 5100075 | SCREW |
| 82 | 5100074 | SCREW |
| 83 | 5100065 | SCREW |
| 84 | 5100064 | SCREW |
| 85 | 5181844 | SLIDING PROTECTION |
| 86 | 0600607 | BALL BEARING |
| 87 | 5181845 | SLIDING PROTECTION |
| 88 | 7132515 | COMPLETE REAR BLADE GUIDE |
| 89 | 7132514 | COMPLETE FRONT BLADE GUIDE |
| 91 | 5130932 | BLADE GUIDE |
| 92 | 0174022 | NEEDLE |
| 93 | 0590624 | BALL BEARING |
| 94 | 5120638 | SPACER |
| 95 | 0147000 | HAND LEVER |
| 96 | 0120706 | PLAIN WASHER |
| 99 | 5130774 | BLADE GUIDE |
| 100 | 0174016 | NEEDLE |
| 101 | 7213016 | GEAR GROUP |
| 102 | 5850111 | FAN WITH MAGNETIC RING |
| 103 | 7820112 | ELECTRONIC SPEED REGULATOR |
| 104 | 5182857 | CASE COVER |
| 107 | 0802316 | SWITCH |
| 108 | 5870853 | CABLE |
| 109 | 5154501 | CABLE LOCKING DEVICE |
| 110 | 0816008 | THERMOSTAT |
| 111 | 0816004 | RADIO INTERFERENCE SUPPRESSOR |
| 113 | 5182542 | GEAR COVER |
| 114 | 0600608 | BALL BEARING |
| 115 | 5850008 | BRUSHES SUPPORT |
| 116 | 5182856 | MOTOR COVER |
| 117 | 7013154 | ARMATURE |
| 119 | 5063040 | THREADED BUSH |
| 121 | 0606001 | BALL BEARING |
| 122 | 5182006 | GREASE BAFFLE PLATE |
| 123 | 5024121 | STATOR - FIELD |
| 124 | 5850112 | CARBON BRUSHE SET |
| 125 | 5061038 | RUBBER BUSHING |
| 126 | 7801847 | MOTOR |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Femi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Femi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Femi 784XL - 8485023
