Femi Spare Parts for Band Saw for Metal 782XL/8484622
€3.47
Tax included
Femi Spare Parts for Band Saw for Metal 782XL/8484622
Femi genuine spare parts or replacements parts for to repair Electric Band Saw for Metal 782XL/8484622.Two speed with electronic switchover, sturdy professional vice
Large 105 mm cutting capacity with adjustable angle from 0 ° to 45 ° left
Cutting without lubrication of all metals
Reliable, robust and easily transportable
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Femi Spare Parts for Band Saw for Metal 782XL/8484622
Femi genuine spare parts or replacements parts for to repair Electric Band Saw for Metal 782XL/8484622.
In the following tables, look for the spare part and its respective code.
| Band Saw 782XL/8484622 | ||
| # | Part Num. | Description |
| 2 | 5182837 | MOTOR COVER |
| 3 | 5112021 | MOTOR FAN |
| 4 | 5182838 | MOTOR COVER |
| 6 | 7820104 | ELECTRONIC SPEED REGULATOR |
| 7 | 5182005 | BAFFLE |
| 8 | 5850111 | FAN WITH MAGNETIC RING |
| 9 | 5850005 | BRUSHES SUPPORT |
| 10 | 5061038 | RUBBER BUSHING |
| 11 | 0816005 | RADIO INTERFERENCE SUPPRESSOR |
| 12 | 5850109 | CARBON BRUSHE SET WHITH INSERT |
| 13 | 7013130 | ARMATURE |
| 14 | 0130502 | THERMOSTAT SUPPORT |
| 14 | 0130502 | THERMOSTAT |
| 16 | 5024111 | STATOR |
| 18 | 5061039 | RUBBER BUSHING |
| 20 | 5182522 | GEAR COVER |
| 21 | 0155013 | ELASTIC RING |
| 22 | 0570627 | BALL BEARING |
| 23 | 7213003 | GEAR GROUP |
| 24 | 0606202 | BALL BEARING |
| 25 | 0155136 | THICKNESS WASHER |
| 26 | 0730810 | CAGE BEARING |
| 27 | 5100090 | LOCKING SCREW |
| 28 | 0129004 | INOX STEEL WASHER |
| 29 | 0590624 | BALL BEARING |
| 30 | 0174022 | NEEDLE |
| 31 | 5120638 | SPACER |
| 32 | 0600607 | BALL BEARING |
| 33 | 0155142 | THICKNESS WASHER |
| 34 | 5214016 | INCLUDED IN CODE 5214019 |
| 34 | 5214019 | DRIVING WHEEL |
| 35 | 5181623 | PROTECTION |
| 38 | 5100065 | SCREW |
| 39 | 5100064 | SCREW |
| 40 | 5130939 | BRACKET |
| 41 | 5181016 | BLADE CLEANER FELT |
| 42 | 5154103 | CABLE LOCKING DEVICE |
| 43 | 0120206 | WASHER |
| 44 | 0102106 | CAP NUT |
| 45 | 0155140 | THICKNESS WASHER |
| 46 | 0730609 | CAGE BEARING |
| 47 | 7213001 | GEAR GROUP |
| 48 | 7213007 | GEAR GROUP |
| 49 | 0147000 | HAND LEVER |
| 50 | 0120706 | FLAT WASHER |
| 51 | 5130932 | BLADE GUIDE |
| 52 | 5181844 | SLIDING PROTECTION |
| 55 | 0400604 | SCREW |
| 56 | 0179901 | NEEDLE |
| 57 | 5001564 | (included into code 5001572) |
| 58 | 5137869 | (included into code 5137914) |
| 59 | 0155152 | THICKNESS WASHER |
| 60 | 0596002 | BALL BEARING |
| 61 | 5120663 | SPACER |
| 63 | 5124062 | WASHER |
| 64 | 5214225 | FREE WHEEL |
| 66 | 5130734 | WHEEL GUIDE |
| 67 | 5081005 | SPRING |
| 69 | 5100506 | (included into code 5100507) |
| 70 | 5081021 | (included into code 0080256x12) |
| 71 | 0140074 | HANDWHEEL |
| 72 | 5042844 | BAND SAW BODY |
| 73 | 5142070 | LEVER |
| 74 | 5870847 | CABLE |
| 78 | 0802317 | SWITCH |
| 79 | 5050121 | HANDLE BASE |
| 80 | 5182521 | SWITCH COVER |
| 82 | 0802319 | SWITCH |
| 83 | 5182520 | SWITCH COVER |
| 84 | 0802314 | SWITCH |
| 85 | 7890101 | CLAMP GROUP |
| 87 | 5870843 | CABLE |
| 88 | 5154501 | CABLE LOCKING DEVICE |
| 89 | 5182840 | SWITCH BOX |
| 90 | 0102106 | RADIO INTERFERENCE SUPPRESSOR |
| 91 | 0147002 | HAND LEVER |
| 92 | 0120710 | PLAIN WASHER |
| 93 | 0151409 | SNAP RING |
| 94 | 7133603 | SWIVEL SUPPORT GROUP |
| 96 | 0102110 | CAP NUT |
| 97 | 5171043 | LOCKING PIN |
| 98 | 0222021 | O-RING SEAL |
| 99 | 0140076 | HANDWHEEL |
| 101 | 0063042 | SLEEVE |
| 103 | 5124029 | ECCENTRIC |
| 104 | 0402905 | RIVET |
| 105 | 5401319 | GRADUATE PLATE |
| 106 | 7130535 | ROD STOP GROUP |
| 107 | 0401001 | SCREW |
| 108 | 5137842 | BASE FOOT |
| 109 | 5133763 | BAND SAW BASE |
| 111 | 0080261 | SPRING WASHER |
| 114 | 0155143 | THICKNESS WASHER |
| 115 | 5080116 | SPRING |
| 116 | 0063027 | BUSHING |
| 117 | 0802606 | SWITCH |
| 118 | 0063027 | SELF-LOCKING NUT |
| 119 | 0155150 | THICKNESS WASHER |
| 120 | 5130416 | PLATE |
| 121 | 5130428 | SLIDING VICE PLATE |
| 123 | 5152613 | VICE JAW |
| 126 | 0150701 | CYLINDRIC PIN WITH SLOT |
| 127 | 5042849 | VICE BASE |
| 128 | 5150005 | VICE PIN STOPPER |
| 130 | 5142014 | LEVER |
| 131 | 5130426 | PLATE |
| 132 | 5130427 | PLATE |
| 133 | 5063034 | BUSH |
| 134 | 5100320 | SCREW |
| 136 | 5042850 | MOBILE VICE |
| 138 | 0063041 | BUSH |
| 139 | 7130670 | VICE ASSEMBLY |
| 500 | 7801612 | 230V MOTOR ASSEMBLY |
