Spare Parts for Mitre Saw Femi 911 - 8436028
€3.05
Tax included
Spare Parts for Mitre Saw Femi 911 - 8436028
FEMI Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Professional Wood Mitre Saw 911 - 8436028.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Spare Parts for Mitre Saw Femi 911 - 8436028
FEMI Original spare parts at the most competitive prices on the web, we are a service center with repair service able to advise you to purchase the most suitable spare part to quickly resolve any maintenance or repair issues for Professional Wood Mitre Saw 911 - 8436028.
In the following table, look for the model of the Mitre Saw and the respective parts of the code.
| Mitre Saw FEMI 911-8436028 | ||
| # | Part Num. | Description |
| 1 | 0320826 | Socket Head Screw |
| 2 | 0120308 | Washer |
| 3 | 0120714 | Plain Washer |
| 4 | 5190299 | Wheel Flange |
| 5 | 5061037 | Blade Bushing |
| 7 | 5182862 | Arm Protection |
| 10 | 5100146 | Nut |
| 11 | 5170001 | Protection Locking Pin |
| 12 | 7130585 | Lever And Protection Group |
| 13 | 5000742 | Blade Shaft |
| 17 | 5182551 | Electric Box Cover |
| 19 | 5182872 | Cable Protection |
| 20 | 5080129 | Spring |
| 22 | 5100147 | Nut |
| 23 | 5120655 | Spacer |
| 24 | 0536203 | Ball Bearing |
| 25 | 0215111 | Belt |
| 26 | 5133008 | Riving Knife Plate |
| 28 | 0120206 | Washer |
| 29 | 5100078 | Screw |
| 32 | 5183067 | Riving Knife |
| 35 | 0151116 | Snap Ring |
| 36 | 7013152 | Rotor |
| 37 | 5050146 | Left Handle |
| 38 | 5143014 | Safety Button |
| 39 | 5143016 | Safety Button |
| 40 | 5081022 | Spring |
| 41 | 5143015 | Release Button |
| 42 | 5142071 | Lever |
| 43 | 0802611 | Switch |
| 44 | 7130606 | Head Release Lever Group |
| 45 | 5080130 | Spring |
| 46 | 5214400 | Wheel |
| 47 | 0107011 | Nut |
| 48 | 5137945 | Motor Holder |
| 49 | 7801092 | Motor Body |
| 50 | 5050126 | HANDLE GRIP ASS'Y (5050145+5050146+5143018 ) |
| 52 | 0536202 | Ball Bearing |
| 53 | 5137946 | Belt Holder |
| 54 | 5100143 | Spacer |
| 57 | 5182853 | CAPACITOR Cover |
| 58 | 0536201 | Ball Bearing |
| 59 | 5112027 | Motor Fan |
| 60 | 5182871 | Switch Cover |
| 61 | 5154501 | Cable Locking Device |
| 62 | 5080172 | Brake Spring |
| 64 | 7820118 | Electronic Card |
| 66 | 0840028 | Capacitor |
| 68 | 5141012 | Adjusting Handwheel |
| 69 | 5182850 | Motor Cover |
| 71 | 5042827 | Mitre Saw Arm |
| * | 7130620 | Blade Transmission Unit Ass'y |
| ** | 7801094 | Motor Body assy |
| 72 | 5181670 | Mobile Protection |
| 76 | 5181665 | Upper Protection |
| 78 | 5141009 | Adjusting Handwheel |
| 79 | 5081016 | Spring |
| 82 | 5181682 | Upper Protection |
| 84 | 5130838 | Upper Table Front Guide |
| 85 | 0170004 | Steel Ball |
| 89 | 5871040 | Cable |
| 93 | 5130767 | Upper Table Rear Guide |
| 96 | 5130858 | Rear Guide |
| 98 | 5130441 | Upper Table |
| 99 | 5130798 | Rear Guide |
| 100 | 5130480 | Fence Guide |
| 101 | 4130474 | Upper Fence |
| 103 | 5138019 | Friction Plate |
| 104 | 0140103 | Wing Nut |
| 182 | 7130657 | Complete Upper Guide |
| 140 | 5182569 | Holder Cover |
| 142 | 0063035 | Bushing |
| 145 | 0151116 | Snap Ring |
| 146 | 5181821 | Fix Protection |
| 148 | 0152319 | Elastic Pin |
| 149 | 5170530 | Joint Pin |
| 150 | 5137872 | Joint |
| 151 | 5155156 | Rubber Damper |
| 152 | 5001560 | Joint Shaft |
| 153 | 0120708 | Plain Washer |
| 156 | 5159506 | Joint Index |
| 157 | 7130624 | Joint Group |
| 107 | 0080256 | Spring Washer |
| 108 | 5063031 | Bushing |
| 109 | 5124051 | Ring |
| 110 | 5080168 | Spring |
| 111 | 5181822 | Fix Protection |
| 113 | 0147006 | Hand Lever |
| 114 | 5120646 | Spacer |
| 115 | 0450880 | Tie Rod |
| 117 | 5181819 | Lower Protection |
| 118 | 5133733 | Mitre Saw Base |
| 120 | 0080257 | Spring Washer |
| 122 | 5401417 | Graduate Plate |
| 123 | 5137902 | Angular Bracket |
| 124 | 5155159 | Brake Device |
| 125 | 0140078 | Wing Nut |
| 126 | 5081012 | Spring |
| 129 | 5171077 | Swivel Support Pin |
| 130 | 5142096 | Release Lever |
| 131 | 5133003 | Sliding Bracket |
| 132 | 5137793 | Rest Foot |
| 134 | 5182900 | Plastic Cover |
| 135 | 5159514 | Blade Tension Index |
| 137 | 5121552 | Spacer |
| 138 | 5130901 | Base Extension |
| 139 | 5137848 | Swivel Holder |
| *** | 5130966 | Parallel Fence |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Femi websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Femi brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Femi 911 - 8436028
12 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
- CHECK ITEM CODE OR S/N FEMI:
- FEMI ITEM CODE START WITH (8....) AND HAVE 7 DIGITS
