Femi Spare Parts for Band Saw DCS NG110
€5.22
Tax included
Femi Spare Parts for Band Saw DCS NG110
FEMI service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Portable Band Saw with DIGITAL CUTTING SYSTEM DCS NG110 - 8484820
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Femi Spare Parts for Band Saw DCS NG110
FEMI service center and original spare parts Worldwide Distributor. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair issues for Portable Band Saw with DIGITAL CUTTING SYSTEM DCS NG110 - 8484820In the following table, look for the model of the Band Saw and the respective parts of the code.
| Portable Band Saw with DIGITAL CUTTING SYSTEM DCS NG110 - 8484820 | ||
| # | Part NUm. | Description |
| NR 1 Pag.1 |
||
| 1 | 5100076 | SCREW |
| 2 | 5080116 | SPRING |
| 3 | UNI 5931 M5 x 45 | |
| 4 | 0155143 | THICKNESS WASHER |
| 5 | 0147002 | HAND LEVER |
| 6 | 0120710 | PLAIN WASHER |
| 7 | UNI 5931 M5 x 20 | |
| 8 | 5130428 | SLIDING VICE PLATE |
| 9 | DIN 7500 M5x15 | |
| 10 | 0100410 | |
| 11 | 0102110 | CAP NUT |
| 12 | 5130416 | PLATE |
| 13 | 5130427 | PLATE |
| 14 | 5130426 | PLATE |
| 15 | 5152613 | VICE JAW |
| 16 | 5181962 | GRADUATE PLATE |
| 17 | 0120710 | PLAIN WASHER |
| 18 | 5124029 | ECCENTRIC |
| 19 | DIN 7500 M6 x 10 | |
| 20 | 7130535 | ROD STOP GROUP |
| 21 | 5043574 | |
| 22 | UNI 5732 M10 x 60 | |
| 23 | 5137793 | REST FOOT |
| 24 | UNI 5588 M16 | |
| 25 | UNI 5588 M16 | |
| 26 | 5150005 | VICE PIN STOPPER |
| 27 | 5063034 | BUSHING |
| 28 | 5100321 | SCREW |
| 29 | 5142014 | LEVER |
| 30 | 5042754 | SLIDING VICE |
| 31 | 0063041 | BUSH |
| 32 | 0155150 | THICKNESS WASHER |
| 33 | UNI 7474 M8 | |
| 34 | 5152614 | VICE JAW |
| 35 | UNI 5933 M6 x 10 | |
| (•) | 7133661 | |
| NR 2 Pag.2 |
||
| 36 | 0596002 | BALL BEARING |
| 37 | 5100507 | BLADE TENSIONING SCREW |
| 38 | 0080256 | SPRING WASHER |
| 39 | DIN 7500 M4 x 8 | |
| 40 | 5050168 | LEFT HANDLE |
| 41 | UNI 6954 P8 x 25 | |
| 42 | 5130734 | WHEEL GUIDE |
| 43 | 5001572 | SHAFT |
| 44 | 5137914 | WHEEL SUPPORT |
| 45 | 0155152 | THICKNESS WASHER |
| 46 | 5050167 | RIGHT HANDLE |
| 47 | DIN 7500 M5 x 10 | |
| 48 | 0802324 | SWITCH |
| 49 | 5181966 | CABLE PROTECTION |
| 50 | 0123004 | NYLON WASHER |
| 51 | ||
| 52 | 5181623 | PROTECTION |
| 53 | 5214225 | FREE WHEEL |
| 54 | 5124062 | WASHER |
| 55 | 7130589 | COMPLETE BLADE TENSION DEVICE |
| 56 | DIN 7500 M5 x 20 | |
| 57 | 0124026 | THICKNESS WASHER |
| 58 | 5081005 | SPRING |
| 59 | 5120663 | SPACER |
| NR 3 Pag.3 |
||
| 60 | 0420682 | |
| 61 | 5873638 | LED WITH CABLE |
| 62-1 | 0802628 | SWITCH |
| 62-2 | 0802628 | SWITCH |
| 63 | 5181004 | RUBBER CABLE PROTECTION |
| 64 | 0400400 | |
| 65 | 7890105 | CABLE |
| 66 | 5154501 | CABLE LOCKING DEVICE |
| 67 | 5182840 | SWITCH BOX |
| 68 | 0802629 | SWITCH |
| 69 | 0400513 | SCREW |
| 70 | 5131021 | LASER SUPPORT |
| 71 | 5873637 | LASER+LED WITH CABLE |
| NR 4 Pag.4 |
||
| 72 | 0420672 | |
| 73 | 7183006 | |
| 74 | 7820161 | DISPLAY CARD |
| 75 | ||
| 76 | 5873633 | ENCODER WITH CABLE |
| 77 | 5112024 | MOTOR FAN |
| 78 | 5182015 | SPEED REARED |
| 79 | 0816005 | RADIO INTERFERENCE SUPPRESSOR |
| 80 | 5850005 | CARBON BRUSHES HOLDER |
| 81 | 5061038 | RUBBER BUSHING |
| 82 | 7013164 | ROTOR |
| 83 | 5850109 | CARBON BRUSHE SET |
| 84 | 5024111 | STATOR |
| 85 | 0130502 | THERMOSTAT SUPPORT |
| 86 | 7801659 | MOTOR |
| 87 | 0816003 | THERMOSTAT |
| 88 | 5061039 | RUBBER BUSHING |
| 89 | 0320515 | |
| 90 | 5182522 | GEAR COVER |
| 91 | 0155013 | ELASTIC RING |
| 92 | 0570627 | BALL BEARING |
| 93 | 7213023 | GEAR GROUP |
| 94 | 0606202 | BALL BEARING |
| 95 | 7213007 | GEAR GROUP |
| 96 | 0155136 | THICKNESS WASHER |
| 97 | 0730810 | CAGE BEARING |
| 98 | 0311080 | EXAGONAL HEAD SCREW |
| 99 | 0129004 | INOX STEEL WASHER |
| 100 | 0590624 | BALL BEARING |
| 101 | 0174022 | NEEDLE |
| 102 | 5120638 | SPACER |
| 103 | 0600607 | BALL BEARING |
| 104 | 0155142 | THICKNESS WASHER |
| 105 | 5214043 | DRIVING WHEEL |
| 106 | 5100065 | SCREW |
| 107 | 5100064 | SCREW |
| 108 | 5130957 | BEARING FIXING SUPPORT |
| 109 | 0120206 | WASHER |
| 110 | 0102106 | CAP NUT |
| 111 | 0400514 | |
| 112 | 5154103 | CABLE LOCKING DEVICE |
| 113 | 0400604 | SCREW |
| 114 | 0179901 | NEEDLE |
| 115 | 5042947 | SAW ARM |
| 116 | 0730609 | CAGE BEARING |
| 117 | 0155140 | THICKNESS WASHER |
| 118 | 7213001 | GEAR GROUP |
| 119 | 0147000 | HAND LEVER |
| 120 | 0120706 | FLAT WASHER |
| 121 | 5130932 | BLADE GUIDE |
| 122 | 5181843 | SLIDING PROTECTION |
| 123 | 0400601 | |
| 124 | 5181867 | ADDITIONAL GUIDE PROTECTION |
| 125 | 5181963 | LASER RIGHT PROTECTION |
| 126 | 5181964 | LASER LEFT PROTECTION |
