FEMI Spare Parts for Drill Press DP12-942 PRO DISPLAY
€90.56
Tax included
FEMI Spare Parts for Drill Press DP12-942 PRO DISPLAY
We are FEMI original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Floor and Bench Drill Press DP12-942 PRO DISPLAY 8086121.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
FEMI Spare Parts for Drill Press DP12-942 PRO DISPLAY
We are FEMI original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Floor and Bench Drill Press DP12-942 PRO DISPLAY 8086121.In the following table, look for the model of the Drill Presses and the respective parts of the code.
| FEMI JOB LINE DRILL RESS DP12-942 PRO DISPLAY 8086121 | ||
| Pos. | Code | Descrition |
| 1 | DP12942-001 | BASE |
| 2 | DP12942-002 | COLLAR FIXING RING |
| 4 | DP12942-004 | COLUMN |
| 5 | DP12942-005 | RACK |
| 6 | DP12942-006 | WORKTABLE LEVER |
| 8 | DP12942-008 | LOCKING LEVER |
| 9 | DP12942-009 | GEAR |
| 10 | DP12942-010 | WORKTABLE SUPPORT |
| 12 | DP12942-012 | SUPPORT |
| 13 | DP12942-013 | RACK RING |
| 15 | DP12942-015 | TABLE SUPPORT |
| 16 | DP12942-016 | WORKTABLE |
| 17 | DP12942-017 | TABLE EXTENSION |
| 18 | DP12942-018 | KNOB |
| 19 | DP12942-019 | EXTENSION SUPPORT |
| 20 | DP12942-020 | ROLLER |
| 23 | DP12942-023 | (see F12-904 accessories price list) |
| 24 | DP12942-024 | CHUCK SHAFT |
| 25 | DP12942-025 | CHUCK HUB |
| 26 | DP12942-026 | BALL BEARING |
| 27 | DP12942-027 | SPACER |
| 28 | DP12942-028 | BALL BEARING |
| 29 | DP12942-029 | KNOB |
| 30 | DP12942-030 | SPRING |
| 31 | DP12942-031 | SELF-LOCKING NUT |
| 32 | DP12942-032 | SPACER |
| 33 | DP12942-033 | SPACER |
| 34 | DP12942-034 | BRACKET |
| 36 | DP12942-036 | SUPPORT |
| 39 | DP12942-039 | LIGHT/LASER SWTCH |
| 40 | DP12942-040 | MAIN SWITCH |
| 41 | DP12942-041 | EMERGENCY BUTTON |
| 42 | DP12942-042 | SPEED INDICATOR |
| 43 | DP12942-043 | SWITCH BOX |
| 45 | DP12942-045 | ELECTRONIC CIRCUIT |
| 46 | DP12942-046 | KEY SUPPORT |
| 51 | DP12942-051 | VARIATOR SUPPORT |
| 52 | DP12942-052 | SCREW |
| 53 | DP12942-053 | LOCKING PLATE |
| 54 | DP12942-054 | FEATHER |
| 55 | DP12942-055 | VARIATOR SHAFT |
| 56 | DP12942-056 | VARIATOR LEVER |
| 60 | DP12942-060 | (included into code DP12942-200) |
| 62 | DP12942-062 | SCREW |
| 63 | DP12942-063 | WASHER |
| 64 | DP12942-064 | SPRING |
| 65 | DP12942-065 | VARIATOR SHAFT |
| 66 | DP12942-066 | WORK LIGHT |
| 67 | DP12942-067 | LASER POINTER |
| 69 | DP12942-069 | SHAFT |
| 70 | DP12942-070 | LEVER SUPPORT |
| 71 | DP12942-071 | CHUCK LEVER |
| 72 | DP12942-072 | LEVER HANDLE |
| 78 | DP12942-078 | MOTOR |
| 83 | DP12942-083 | MOTOR PULLEY |
| 85 | DP12942-085 | MOTOR FIX PULLEY |
| 87 | DP12942-087 | SENSOR |
| 90 | DP12942-090 | SPEED SENSOR |
| 92 | DP12942-092 | RING |
| 93 | DP12942-093 | BALL BEARING |
| 94 | DP12942-094 | RING |
| 95 | DP12942-095 | FREE PULLEY SHAFT |
| 96 | DP12942-096 | FEATHER |
| 97 | DP12942-097 | RING |
| 98 | DP12942-098 | PULLEYS PLATE |
| 99 | DP12942-099 | CHUCK FIX PULLEY |
| 100 | DP12942-100 | CHUCK MOBILE PULLEY |
| 101 | DP12942-101 | RING |
| 102 | DP12942-102 | RING |
| 103 | DP12942-103 | COLLAR WITH BEARING |
| 104 | DP12942-104 | SUPPORT |
| 106 | DP12942-106 | BELT |
| 109 | DP12942-109 | PROTECTION SUPPORT |
| 110 | DP12942-110 | KNOB |
| 111 | DP12942-111 | PROTECTION SUPPORT |
| 113 | DP12942-113 | PROTECTION |
| 200 | DP12942-200 | SPRING GROUP |
| 201 | DP12942-201 | MICROSWITCH GROUP |
| 202 | DP12942-202 | CHUCK SHAFT GROUP |
| 203 | DP12942-203 | CHUCK SENSOR GROUP |
| 204 | DP12942-204 | SPEED SENSOR GROUP |
| 205 | DP12942-205 | DISPLAY GROUP |
| 206 | DP12942-206 | MOTOR PULLEY GROUP |
| 207 | DP12942-207 | CHUCK PULLEY GROUP |
| 208 | DP12942-208 | CHUCK DOWN SHAFT GROUP |
| 209 | DP12942-209 | DEEPTH BRACKETS GROUP |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Fox websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Makita brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Femi DP12-942 PRO DISPLAY
6 Items
Data sheet
- SHIPPING IN:
- Usually Ships in: 10 BUSYNESS DAYS APPROX.
- MORE INFO:
- PLEASE PAY ATTENTION! FOR MACHINES FEMI SPA DISTRIBUTION ONLY
- CHECK ITEM CODE OR S/N:
- CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
