Dolmar Lawn Mower PM5165S3 Parts
€25.80
Tax included
Dolmar Spare Parts for Lawn Mower PM5165S3
We are DOLMAR original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Lawn Mower PM5165S3.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Dolmar Spare Parts for Lawn Mower PM5165S3
We are DOLMAR original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Lawn Mower PM5165S3.In the following table, look for the model of the Lawn Mower and the respective parts of the code.
| PM-5165 S3 | ||
| # | Part Num | Description |
| A1 | 664003546 | DECK RED |
| A10 | 664035000 | O-RING |
| A11 | 664728519 | SCREW |
| A12 | 664060144 | DECK, ADJUSTMENT |
| A13 | 664570200 | PLATE, CUTTING POSITIONS |
| A14 | 664728520 | SCREW |
| A15 | 664521350 | WASHER |
| A17 | 664778397 | BRACKET, LEFT |
| A17.1 | 664140224 | MULCH PLUG |
| A18 | 664203854 | PROTECTION CAP |
| A2 | 664735420 | SCREW |
| A20 | 664778396 | BRACKET, RIGHT |
| A22 | 664155000 | NUT |
| A23 | 664793102 | SCREW |
| A24 | 664595352 | INSPECTION DOOR |
| A25 | 664729600 | SCREW |
| A26 | 664108205 | PLATE |
| A27 | 664789000 | SCREW |
| A28 | 664523020 | WASHER |
| A29 | 664154330 | NUT |
| A3 | 664226109 | MASK |
| A30 | 664731350 | SCREW |
| A31 | 664545147 | PLATE |
| A33 | 664038407 | BUSH |
| A34 | 664731350 | SCREW |
| A35 | 664545156 | PLATE |
| A36 | 664038400 | BUSH |
| A5 | 664728522 | SCREW |
| A51 | 664302847 | AXLE, FRONT WHEELS |
| A58 | 664002040 | ROD, HEIGHT ADJUSTMENT |
| A59 | 664000930 | SAFETY WASHER |
| A6 | 664060200 | PROTECTION |
| A61 | 664446187 | SPRING |
| A62 | 664604899 | SAFETY WASHER |
| A63 | 664529662 | PIN |
| A64 | 664672151 | WASHER |
| A65 | 664001269 | ROD, REAR WHEELS AXLE |
| A66 | 664000479 | SECTOR, HEIGHT ADJUSTMENT |
| A67 | 664672152 | WASHER |
| A68 | 664785109 | SUPPORT, HEIGHT |
| A69 | 664293201 | NUT |
| A7 | 664729600 | SCREW |
| A70 | 664793301 | SCREW |
| A71 | 664785113 | SUPPORT, HANDLE |
| A72 | 664293201 | NUT |
| A73 | 664729600 | SCREW |
| A74 | 664793301 | SCREW |
| A75 | 664038002 | BUSH |
| A76 | 664393611 | KNOB |
| A78 | 664293201 | NUT |
| A79 | 664622640 | PIN |
| A8 | 664523040 | WASHER |
| A80 | 664446175 | SPRING |
| A9 | 664034000 | WASHING CONNECTION |
| B1 | 664110653 | WHEEL COVER |
| B2 | 664007409 | WHEEL |
| B3 | 664216035 | BEARING |
| B4 | 664521350 | WASHER |
| B5 | 664155000 | NUT |
| C1 | 664006670 | HANDGRIP |
| C10 | 664728721 | SCREW |
| C11 | 664727786 | SCREW |
| C12 | 664030077 | CONTROL CABLE (MOTOR BRAKE) |
| C13 | 664030078 | CONTROL CABLE (WHEEL DRIVE) |
| C14 | 664007199 | THROTTLE LEVER WITH CONTROL CABLE |
| C15 | 664806644 | PROTECTION |
| C16 | 664727812 | SCREW |
| C17 | 664523000 | WASHER |
| C19 | 664488301 | SUPPORT, R |
| C2 | 664003349 | LEVER, DRIVING |
| C20 | 664488303 | SUPPORT, L |
| C21 | 664131750 | NUT |
| C22 | 664399835 | GRIP |
| C23 | 664003253 | HANDLE |
| C24 | 664680017 | SUPPORT |
| C3 | 664003344 | LEVER, MOTOR BRAKE |
| C30 | 664007195 | BOWDEN CABLE, SPEED DRIVE CONTROL |
| C31 | 664727786 | SCREW |
| C32 | 664154510 | NUT |
| C4 | 664430309 | GUIDE SPRING |
| C5 | 664154330 | NUT |
| C6 | 664007046 | HANDLE |
| C7 | 664735662 | SCREW |
| C8 | 664041967 | BUSH |
| C9 | 664154510 | NUT |
| D1 | 664608600 | SEEGER |
| D10 | 664003080 | GEAR BOX |
| D11 | 664601908 | PULLEY |
| D12 | 664645705 | PIN |
| D13 | 664033282 | ADJUSTMENT ROD |
| D14 | 664041957 | BUSH |
| D15 | 664450063 | SPRING |
| D16 | 664680009 | WASHER |
| D17 | 664154510 | NUT |
| D18 | 664110230 | HUB COVER |
| D19 | 664064197 | BELT |
| D2 | 664570120 | PINION LEFT |
| D3 | 664120105 | RING GEAR |
| D4 | 664600218 | PROTECTION |
| D5 | 664570110 | PINION RIGHT |
| D6 | 664608600 | SEEGER |
| D7 | 664216035 | BEARING |
| D8 | 664302845 | AXLE, REAR WHEELS |
| D9 | 664753000 | PIN |
| E1 | 664465608 | HUB WITH PULLEY |
| E2 | 664004381 | BLADE (COLLECT AND MULCH) |
| E3 | 664160400 | ELASTIC WASHER |
| E4 | 664523080 | WASHER |
| E5 | 664735698 | SCREW |
| E6 | 664139150 | FEATHER |
| E7 | 664155000 | NUT |
| E8 | 664521350 | WASHER |
| E9 | 664735108 | SCREW |
| F1 | 664008114 | STONE-GUARD |
| F11 | 664002124 | BOX, FABRIC |
| F12 | 664006430 | FRAME |
| F2 | 664450270 | SPRING |
| F3 | 664517907 | PIN |
| G1 | 664365734 | LABEL |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Dolmar websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Dolmar brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
