Dolmar Lawn Mower PM5120SR Parts
search
  • Dolmar Lawn Mower PM5120SR Parts
  • Dolmar Lawn Mower PM5120SR Parts Diagram
  • Dolmar Lawn Mower PM5120SR Parts Diagram - 1

Dolmar Lawnmower PM5120SR Parts

€2.84
Tax included

Dolmar Spare Parts for Lawn Mower PM5120SR

We are DOLMAR original spare parts Worldwide Dealers at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Lawn Mower PM5120SR.
ITEM CODE: 671687001
Quantity
Usually Ships in: 7/10 Business Days Approx.

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Dolmar Spare Parts for Lawn Mower PM5120SR

We are DOLMAR original spare parts Worldwide Dealers

 at low at unbeatable prices and a service center with professional repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Lawn Mower PM5120SR.

In the following table, look for the model of the Lawn Mower and the respective parts of the code.
Dolmar PM5120SR

PM5120SR - PETROL LAWN MOWER
Pag.1
# Part Num. Description
1 671687001 HANDLE PM5120-5120S
2 671103001 HANDLE COVER
3 DA00001087
4 DA00001060
5 671687001 HANDLE PM5120-5120S
6 671001814 UPPER HANDLE PM5120-5120S
7 DA00000575 M6 NUT
8 DA00000574 WASHER
9 DA00000573 PLATE
10 DA00001164
11 DA00000952 TRACTION CABLE PM5120-5120S
12 DA00001165
13 DA00000572 SCREW
14 DA00000577 SCREW
15 DA00000579 HOOK
16 DA00000574 WASHER
17 DA00000576 SPRING WASHER
18 DA00000563 HEX NUT
19 DA00000564 KNOB
20 DA00000924 SEAL
21 DA00000569 SCREW
22 DA00000924 SEAL
23 DA00000564 KNOB
24 DA00000563 HEX NUT
25 DA00000951 PM5120-5120S LOWER HANDLE
26 DA00000566
27 DA00000924 SEAL
28 DA00000564 KNOB
29 DA00000563 HEX NUT
30 DA00001170
31 DA00000566
32 DA00000537 FLANGE NUT
33 DA00000582 SQUARE WASHER
34 DA00000617 SCREW
35 DA00000583 HEX WRENCH
36 DA00000584 ROD FOR WRENCH
Pag.2
37 671689001 TRACTION GROUP COVER
38 671314001 COMPASS PM5120-5120S
39 DA00000614 SCREW 4.8X19
40 DA00000562 FLANGE NUT
41 671001710 GRADUATED SCALE PM5120-5120S
42 DA00000537 FLANGE NUT
43 DA00000590
44 DA00000562 FLANGE NUT
45 DA00000589
46 DA00000537 FLANGE NUT
47 DA00000560
48 DA00000559
49 DA00000556
50 DA00000558
51 DA00000543 NUT
52 DA00000555
53 DA00000552 SCREW M6X16
54 671001602 RED FRAME PM5120-5120S
55 DA00000546
56 671001813 CONNECTING BAR PM5120S
57 DA00000549 NUT
58 DA00000549 NUT
59 671001322 HUB CAP PM5100S3
60 DA00000537 FLANGE NUT
61 DA00000538 BEARING
62 671002021 REAR WHEEL PM5100S3
63 DA00000538 BEARING
64 671200010 GEAR PM5120-5120S
65 DA00000603 SCREW
66 671007065 WASHER 20 PM5120-5120S
67 671251800 INNER HUB COVER FOR PLM5600
68 DA00000604 RETAINING RING
69 DA00001091 RIGHT PINION PLM4611
70 671007059 WASHER 12.8 PM5120-5120S
71 DA00001029 BEARING FOR ELM4611
72 DA00000610 BEARING BOX
73 DA00000612 STOP RING
74 671001812 REAR AXLE PM5120-5120S
75 DA00000549 NUT
76 671001707 HEIGHT ADJUSTMENT LEVER PM5120S
77 DA00001058 KNOB
78 671002030 SCREW PM5100S3
79 671002019 SCREW M6X12 ELM4110
80 DA00000542 SUPPORT
81 DA00000543 NUT
82 DA00000543 NUT
83 DA00000542 SUPPORT
84 671002019 SCREW M6X12 ELM4110
85 DA00000612 STOP RING
86 DA00000610 BEARING BOX
87 671251800 INTERNAL HUB COVER FOR PLM5600
88 671007065 WASHER 20 PM5120-5120S
89 DA00001029 BEARING FOR ELM4611
90 671007059 WASHER 12.8 PM5120-5120S
91 DA00001090 LEFT PINION PLM4110-4610-4611
92 DA00000604 RETAINING RING
93 DA00000603 SCREW
94 671200010 GEAR PM5120-5120S
95 DA00000538 BEARING
96 671002021 REAR WHEEL PM5100S3
97 DA00000538 BEARING
98 DA00000537 FLANGE NUT
99 671001322 HUB CAP PM5100S3
100 DA00000536 REAR HUB CAP
101 DA00000537 FLANGE NUT
102 DA00000538 BEARING
103 671020160 WHEEL 200 PLM4110-4610-4611
104 DA00000538 BEARING
105 671002019 M6X12 SCREW ELM4110
106 DA00000542 SUPPORT
107 DA00000543 NUT
108 DA00000545
109 671001811 FRONT AXLE PM5120S
110 DA00000543 NUT
111 DA00000542 SUPPORT
112 671002019 M6X12 SCREW ELM4110
113 DA00000538 BEARING
114 671020160 WHEEL 200 PLM4110-4610-4611
115 DA00000538 BEARING
116 DA00000537 FLANGE NUT
117 DA00000536 HUB CAP REAR
118 671011173 DRIVE RECALL SPRING PM5120-S
119 671502015 DRIVE GROUP PM5120-5120S
120 DA00000597 PIN
121 671020380 BELT 813MM PM5120-5120S
122 DA00000599
123 DA00000598 SCREW
124 DA00000594
125 DA00000537 FLANGE NUT
126 671319001 WASHER 12 PM5120-5120S
127 DA00000535 KEY
128 671002049 BLADE BOSS PM5120-5120S
129 DA00000533
130 DA00000944 BLADE 510MM PM5120S
131 DA00000531 LOWER WASHER PM5120S
132 DA00000530
133 DA00000529 WASHER
134 671006141 SCREW 3/8X55 PM5120-5120S
