Dolmar Spare Parts for Shredder FH-2500
€29.17
Tax included
Dolmar Spare Parts for Shredder FH-2500
We have the original Spares Dolmar for Shredder FH-2500, the diagram, parts list and tool repair that help you need to get your tools running like new again.Fix Your Shredder FH-2500. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Dolmar Spare Parts for Shredder FH-2500
Fix Your Shredder FH-2500. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Pressure Washer and the respective parts of the code.
| FH-2500 - SHREDDER 2,5KW DOLMAR | ||
| # | Part Num. | Description |
| 1 | 652023652 | SWITCH BOX ASS'Y |
| 2 | 652024820 | UPPER HANDLE |
| 3 | 652023666 | PLUG COVER ASS'Y |
| 4 | 652023676 | CONTROL PCB CIRCUIT |
| 5 | 652023762 | UPPER HOUSING |
| 6 | 652023679 | HOPPER |
| 7 | 652023680 | SELF-TAPPING SCREW 5 X 20 |
| 8 | 652024821 | CAPACITOR |
| 9 | 652023682 | MOTOR WITH KNIFE CYLINDER ASS'Y |
| 10 | 652024824 | SWITCH |
| 11 | 652023717 | SWITCH PRESSBOARD |
| 12 | 652024828 | SCREW 4 X 12 |
| 13 | 652023719 | SWITCH |
| 14 | 652023726 | NYLON BAND |
| 15 | 652024829 | HEAT SHRINKABLE TUBE diam. 6 |
| 16 | 652023728 | LOCK WASHER 5 |
| 17 | 652023729 | SCREW M5 X 16 |
| 18 | 652023730 | LOWER HOUSING |
| 19 | 652023731 | SCREW M6 X 16 |
| 20 | 652023747 | SELF-TAPPING SCREW M5 X 25 |
| 21 | 652023736 | FRAME ASSEMBLY |
| 22 | 652024834 | COLLECTION CONTAINERS |
| 1.1 | 652023653 | SELF-TAPPING SCREW 4 X 16 |
| 1.1O | 652023662 | LIGHT GUIDE COVER |
| 1.2 | 652023654 | SWITCH BOX UPPER COVER |
| 1.3 | 652023655 | WATER PROOF COVER |
| 1.4 | 652023656 | SWITCH ON BUTTON |
| 1.5 | 652023657 | STOP BUTTON RED |
| 1.6 | 652023658 | PRESS BUTTON YELLOW |
| 1.7 | 652024819 | SPRING |
| 1.8 | 652023660 | PRESSBOARD |
| 1.9 | 652023661 | SELF-TAPPING SCREW 3 X 8 |
| 9.1 | 652023732 | MOTOR CPL. |
| 9.1O | 652024823 | SOCKET HEAD SCREW M6X30 |
| 9.2 | 652023702 | ADJUSTING KNOP |
| 9.3 | 652023700 | LOCK KNOB |
| 9.4 | 652023699 | SELF-LOCKING NUT |
| 9.5 | YA00000706 | LOCK NUT |
| 9.6 | 652023697 | FEATHER KEY |
| 9.7 | 652023709 | FEEDING BAFFLE PLATE |
| 9.8 | 652023710 | KNIFE CYLINDER 86X70 |
| 9.9 | 652024822 | FRONT COVER ASSY. |
| 1.11 | 652023663 | OPERATION PCB |
| 1.12 | 652023664 | SWITCH BOX LOWER COVER |
| 10.1 | 652024825 | MICRO SWITCH |
| 10.2 | 652024826 | 2 CORE CONNECTION CABLE |
| 10.3 | 652024827 | SINGLE WIRING CABLE |
| 21.1 | 652023847 | CONNECTION CABLE |
| 21.10 | 652024832 | 3 IN 1 SELF-TAPPING SCREW M5X16 |
| 21.11 | 652023748 | SUPPORTING FOOT |
| 21.12 | 652023749 | FRAME FIX PLATE |
| 21.13 | 652024833 | BOLT M6X16 |
| 21.14 | 652023751 | SUPPORTING AXLE |
| 21.15 | 652024828 | SCREW 4 X 12 |
| 21.16 | 652023752 | CABLE PRESSBOARD |
| 21.17 | 652023753 | COLLECTOR COVER |
| 21.18 | 652023747 | SELF-TAPPING SCREW M5 X 25 |
| 21.2 | 652023739 | LEFT FRAME TUBE |
| 21.3 | 652023740 | WHEEL AXLE |
| 21.4 | 652023741 | RIGHT FRAME TUBE |
| 21.5 | 652023742 | COTTER PIN 2,5X25 |
| 21.6 | 652023905 | FRONT WHEEL COVER |
| 21.7 | 652023744 | SELF-LOCKING NUT M5 |
| 21.8 | 652023745 | BASE PLATE |
| 21.9 | 652024831 | 3 IN 1 SELF-TAPPING SCREW M5X12 |
| 22.1 | 652023765 | COLLECTION BOX |
| 22.2 | 652023757 | PUSH BUTTON BASE |
| 22.3 | 652024828 | SCREW 4 X 12 |
| 22.4 | 652024835 | SELF-TAPPING SCREW M5X35 |
| 22.5 | 652023759 | MECHANICAL SWITCH PUSH ROD |
| 22.6 | 652023760 | PUSHBUTTON |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Dolmar websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Dolmar brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
