Dolmar Spare Parts for Petrol Hedge Trimmer HT2256D
€1.35
Tax included
Dolmar Spare Parts for Petrol Hedge Trimmer HT2256D
Buy at best price, all the original Dolmar spare parts and accessories that will allow you to repair or maintain your Dolmar Petrol Hedge Trimmer HT2256D in complete safety. Open the PDF of the technical drawing on the page to accurately choose all the spare parts you need to give new life to your Hedge Trimmer.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Dolmar Spare Parts for Petrol Hedge Trimmer HT2256D
Buy at best price, all the original Dolmar spare parts and accessories that will allow you to repair or maintain your Dolmar Petrol Hedge Trimmer HT2256D in complete safety. Open the PDF of the technical drawing on the page to accurately choose all the spare parts you need to give new life to your Hedge Trimmer. The Engine hedge trimmer HT2256 is a valuable garden tool, which will allow you to work more comfortably once repaired.
In the following table, look for the model of the Engine Hedge Trimmer and the respective parts of the code.
| Dolmar Petrol Hedge Trimmer HT2256D | ||
| A Pag.1 |
||
| # | Part Num. | Description |
| 1 | 1181550000 | FRONT HANDLE |
| 2 | 0301080000 | REINFORCING PLATE |
| 3 | 1361410000 | DRUM COMPLETE |
| 4 | 1181410000 | CASE (UPPER) |
| 5 | 162050000K | FLANGE NUT M5 |
| 6 | 054060150K | HEX. BOLT M6X15 |
| 7 | 055001000R | GREASING NIPPLE M6 |
| 8 | 354060010K | BALL BEARING HT2256D |
| 9 | 351006080K | BALL BEARING 608Z HT2256 |
| 10 | 150060000K | HEX. NUT M6 |
| 11 | 1361420000 | PINION GEAR |
| 12 | 1360030000 | GEAR CRANK ASS Y |
| 13 | XOC0000018 | CONNECTING ROD |
| 14 | 283026000K | RETAINING RING STW-26 |
| 15 | 055060350K | HEX. BOLT M6X35 |
| 16 | 351006080K | BALL BEARING 608Z HT2256 |
| 17 | 010030050K | PAN HEAD SCREW M3X5 |
| 18 | 0301100000 | ROD SLIDING PLATE |
| 19 | 1181010000 | FELT |
| 20 | 1181040000 | CASE (LOWER) |
| 21 | 054050160K | HEX. BOLT M5X16 |
| 22 | 054050200K | HEX. BOLT M5X20 |
| 23 | 164060000K | HEX. U-NUT M6 |
| 24 | 164060000K | HEX. U-NUT M6 |
| 25 | 1181520000 | BLADE GUARD (W) |
| 26 | 031050200K | COUNTERSUNK HEAD SCREW M5 X20 |
| 27 | 0082500000 | BLADE SLIDING WASHER |
| 28 | 0082470000 | BLADE SLIDING SCREW(L=19) |
| 29 | 1181260000 | BLADE SUPPORT BAR |
| 32 | 150060000K | HEX. NUT M6 |
| 33 | 055060400K | HEX. BOLT M6X40 |
| 34 | 055060500K | HEX. BOLT M6X50 |
| 35 | 0082480000 | BLADE SLIDING SCREW(L=22) |
| 36 | 028002039A | BLADE COVER |
| 37 | 1181540000 | LEAF SPRING |
| 38 | XOC0000033 | SPRING |
| 39 | 112040100K | TAPPING SCREW M4X10 |
| 40 | 1181210000 | CABLE HOLDER |
| 41 | 1181110000 | WIRE END |
| 42 | 005044004A | SLIDE SWITCH |
| 43 | 1181150000 | LEVER |
| 44 | 280002500K | RETAINING RING ETW 2.5 |
| 48 | 1181500000 | REAR HANDLE (L) |
| 49 | 017040160K | PAN HEAD SCREW M4X16 |
| 50 | 017040300K | PAN HEAD SCREW M4X30 |
| 51 | 1181490000 | REAR HANDLE (R) |
| 52 | 150040000K | HEX. NUT M4 |
| 53 | 126493-4 | REAR HANDLE |
| 54 | 229060000K | WAVE WASHER |
| 55 | 0566079970 | CLAMP |
| 100 | 6018505400/KIT | BLADE ASSY |
| B Pag.2 |
||
| 56 | 5251003000 | CRANKCASE COMPLETE |
| 57 | 424447-8 | CRANKCASE GASKET |
| 58 | 0140059500 | SCREW M5X25 |
| 59 | 5252002002 | ECCENTRIC SHAFT |
| 60 | 5212500700 | PISTON |
| 61 | 5982500000 | PISTON RING |
| 62 | 5212500801 | PISTON PIN |
| 63 | 233976-8-4 | CIRLIP |
| 64 | 442171-1 | CYLYNDER GASKET |
| 66 | 0119059730 | SOCKET HEAD BOLT M5X20 |
| 67 | 5253500200 | INSULATOR GASKET |
| 68 | 141056-5 | ISOLATOR |
| 69 | 0140059500 | SCREW M5X25 |
| 70 | 5253500102 | MUFFLER GASKET |
| 71 | 5253010001 | EXHAUST MUFFLER |
| 72 | 0031005000 | WASHER M5 |
| 73 | 0119059660 | SOCKET HEAD BOLT M5X50 |
| 74 | 5257001010 | MAGNETO FLYWHEEL |
| 75 | 5257001020 | IGNITION COIL |
| 76 | 0140049920 | SCREW ASS Y M4X20 |
| 77 | 5257500300 | GROMMET |
| 78 | 324891-8 | PLUG CAP SPRING, MEM427 |
| 79 | 5237503301 | PLUG CAP |
| 80 | 0650149721 | SPARK PLUG BMR7A |
| 81 | 5238500500 | CLUTCH SPRING |
| 82 | 6252500801 | CLUTCH SHOE |
| 83 | 267429-5 | WASHER 6 |
| 84 | 267817-6 | WASHER 8, MEM427 |
| 85 | 266457-7 | SHOULDER HEX. BOLT M6*25, MEM427 |
| 86 | 6202500000 | HOLDER |
| 87 | 5253500500 | MUFFLER COVER |
| 88 | 0043705160 | SCREW ASS Y |
| 89 | 5255001000 | REWIND STARTER ASS Y |
| 90 | 5255001020 | SET SCREW |
| 91 | 5505001030 | FRICTION PLATE |
| 92 | 5105015050 | CLUTCH SPRING |
| 93 | 5105015020 | PAWL |
| 94 | 5105015060 | RETURN SPRING |
| 95 | 5025001010 | STARTER REEL |
| 96 | 5235024022 | STARTER ROPE |
| 97 | 232257-7 | SPIRAL SPRING |
| 98 | 5225004020 | HANDLEBHX2500/PB-250.4 |
| 99 | 911218-7 | PAN HEAD SCREW M5X14, EBH252U |
| 100 | 0200070010 | WASHER |
| 101 | 5255501200 | CYLINDER COVER (DOLMAR COLOR) |
| 102 | 5503503001 | SPACER |
| 103 | 0140059490 | SCREW |
| 104 | 0031206000 | WASHER |
| 105 | 0011306160 | BOLT ASS Y |
| 106 | 5215500300 | BAFFLE PLATE |
| 107 | 5255500001 | BLOWER HOUSING |
| 108 | 0043505160 | SCREW ASS Y |
| 109 | 5256012001 | TUBE ASS Y |
| 110 | 5256002000 | TANK PLATE COMPLETE |
| 111 | 163447-0 | FILTER, EBH340U |
| 112 | 0043705160 | SCREW ASS Y |
| 113 | 5256025000 | FUEL TANK COMPLETE |
| 114 | 452920-8 | FUEL CAP |
| 115 | 1181240000 | SPACER |
| 116 | 0140059450 | SCREW M5X18 |
| 117 | 6202006000 | BOLT ASS Y |
| 118 | 5607005000 | WIRE COMPLETE (2) |
| 119 | 213628-7 | OIL SEAL |
| 120 | 0600129920 | BALL BEARING 6001 C3 |
| 121 | 140436-2 | STRAP COMPLETE |
| 153 | 0566059980 | CLAMP |
| C Pag.3 |
||
| 119 | 5256032000 | CARBURETOR |
| 120 | 5253020010 | AIR CLEANER COVER |
| 121 | 5203004010 | AIR FILTER |
| 122 | 0043305650 | SCREW ASS Y |
| 123 | 5253003020 | AIR CLEANER HOUSINGCOMPLETE |
| 124 | 5236061000 | O RING |
| 126 | 5256501900 | CABLE BRACKET |
| 127 | 5236018040 | SWIVELBHX2500/PB-250.4 |
| 128 | 266581-6 | PAN HEAD SCREW M3X8 |
| 129 | 5256032010 | THROTTLE VALVE ASS Y |
| 130 | 5316005120 | RINGBHX2500/PB-250.4 |
| 131 | 5246001010 | O RINGBHX2500/PB-250.4 |
| 132 | 5026004010 | NOZZLE |
| 133 | 5246001030 | PUMP GASKET |
| 134 | WJ00009599 | PUMP DIAPHRAGM, DCS230T |
| 135 | 5016004010 | INLET SCREENBHX2500/PB-250.4 |
| 136 | 5256007010 | PUMP BODY ASS Y |
| 137 | 442154-1 | METERING DIAPHRAGM GASKET |
| 138 | 168574-8 | METERING DIAPHARGM, EBH341U |
| 139 | 5236046060 | AIR PURGE BODY ASS Y |
| 140 | 424314-7 | PRIMER PUMP |
| 141 | 5236046050 | PRIMER PUMP COVERBHX2500/PB-250.4 |
| 142 | 266582-4 | PUMP COVER |
| 143 | 442177-9 | SCREW 3X24 |
| 144 | 5316020020 | SCREW CABLE ADJ |
| 145 | 5316005450 | CABLE ADJUST NUT |
| 146 | 0630029830 | CONTROL CABLE |
| 152 | 442177-9 | GASKET |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Dolmar websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Dolmar brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
