Dolmar Spare Parts for Cordless Pruning Scissor AR-3733XE3

€770.61
Tax included

Dolmar Spare Parts for Cordless Pruning Scissor AR-3733XE3

We have the original Spares DOLMAR for Cordless Pruning Scissor AR-3733XE3 the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Cordless Pruning Scissor AR-3733XE3. All Spares are original and can be supplied at discounted prices.
ITEM CODE: 123458-7
Quantity
on 7/10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Dolmar Spare Parts for Cordless Pruning Scissor AR-3733XE3

We have the original Spares DOLMAR for Cordless Pruning Scissor AR-3733XE3 the Repair information, Exploded Diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix Your Cordless Pruning Scissor AR-3733XE3. All Spares are original and can be supplied at discounted prices. Our Spares are Genuine Parts Guaranteed.

In the following table, look for the model of the Scissor and the respective parts of the code.


Cordless Pruning Scissor AR-3733XE3
1 251490-2 SCREW M5X14
3 456210-1 UPPER HOUSING X AR-3733
5 251474-0 SCREW M8
6 197558-9 UPPER BLADE X AR-3733
7 197367-6 LOWER BLADE X DUP361Z
8 213034-6 RING 3 X DA3010F
9 346940-1 BLOCK PLATE X DUP361Z
10 266557-3 SCREW HS M3X8 X DUP361Z
11 264118-3 NUT M8
12 266786-8 SCREW 2X10 BHP459
13 456218-5 COVER B X DUP361Z
14 961011-9 RETAINER RING E4
15 347165-0 CON-ROD
16 256568-6 PIN 5
17 251484-7 SCREW M3X4
18 456215-1 LEVER X DUP361Z
19 216031-1 BALL 2.3 AT450H
20 233491-2 SPRING COMPRESSION 2 X AT450H
21 688189-0 MAGNET X DUP361Z
22 266999-1 SCREW M3X4
23 231397-8 COMPRESSION SPRING 4 2414B
24 123536-3 SWITCH LEVER X DUP361Z
25 456217-7 COVER X DUP361Z
26 123458-7 JOINT X DUP361Z
27 912012-0 SCREW M3X10
28 227390-8 GEAR 48 X DUB361Z
29 227389-3 GEAR 18
30 253810-6 WASHER 12 X HR4000C
31 911006-2 CYLINDER HEAD SCREW M3X8
32 319349-0 HOLDER HOLDER DUP361Z
33 629160-5 MOTOR DC X DUP361Z
34 620459-1 CABLE CONNECTION X DUP361Z
35 456212-7 LOWER HOUSING X AR-3733
36 911028-2 SCREW 3 X 16 X 4604D
37 143936-1 FRONT HOUSING X AR-3733
38 266980-2 SCREW M3X16 X DUP361Z
58 266786-8 SCREW 2X10 BHP459
41 183B70-7 CONTROL HOUSING X AR-3733
42 232267-4 SPRING PLATE X DUP361Z
43 687053-2 CABLE CLAMP
44 265995-6 SCREW M4X18 X 6408 / 6221DW
45 643523-1 BATTERY TERMINAL
46 620461-4 UNIT X DUP361Z
47 620458-3 REGULATOR X DUP361Z
49 265995-6 SCREW M4X18 X 6408 / 6221DW
50 183B75-7 HOUSING SWITCH AR-3733
51 699086-5 POWER CABLE DUP361Z
52 687053-2 CABLE CLAMP
53 265995-6 SCREW M4X18 X 6408 / 6221DW
54 651536-8 SWITCH 1941.1451 X DUP361Z
55 620460-6 CIRCUIT DUB361Z
57 266429-2 SCREW 3X16 FOR TD0101F
59 661445-3 CONNECTING CABLE
60 630A13-9 BATTERY HOLDER

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Dolmar websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Dolmar brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
