Dolmar Spare Parts for Lawn Mower PM5150S
Fix Your Lawn Mower PM5150S. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Lawn Mower and the respective parts of the code.
| Lawn Mower PM5150S | ||
| # | Part Num. | Description |
| 1 | 22601001/0 | GUARD X PM5150S |
| 2 | 112691800/0 | SCREW X PM4850S |
| 3 | 112521350/0 | WASHER X PM4850S |
| 4 | 381002732/0 | ORANGE CHASSIS FOR PM5150S |
| 5 | 12155000/0 | NUT X PM4850S |
| 6 | 22226050/0 | MASK X PM4850S |
| 7 | 112523040/0 | WASHER X PM4850S |
| 8 | 112735402/0 | SCREW X PM4850S |
| 9 | 664038400 | BUSH X PM4850S |
| 10 | 22545156/0 | PLATE X PM4850S |
| 11 | 12731350/0 | SCREW X PM4850S |
| 12 | 12729600/0 | SCREW X PM4850S |
| 13 | 122034000/0 | PM4850S WASH WATER CONNECTION |
| 14 | 19035000/0 | RING OR X PM4850S |
| 15 | 322545152/0 | PLATE X PM4850S |
| 16 | 664595352 | INSPECTION DOOR X PM4850S |
| 17 | 22060200/0 | BELT CARTER PM4850S |
| 18 | 112728522/0 | SCREW X PM4850S |
| 19 | 664789000 | SCREW X PM 43 |
| 20 | 322108205/0 | PM4850S X CONVEYOR |
| 21 | 12523020/0 | WASHER X PM4850S |
| 22 | 112154330/0 | NUT X PM4850S |
| 23 | 22517856/0 | PIN X PM5150S |
| 24 | 381008044/0 | STONE GUARD X PM4850S |
| 25 | 122450270/0 | SPRING FOR PM4850S |
| 26 | 112293200/0 | NUT X PM4850S |
| 27 | 22399803/0 | KNOB X PM4850S |
| 28 | 22680006/1 | WASHER X PM4850S |
| 29 | 81000634/0 | MOTOR BRAKE CABLE X PM5150S |
| 30 | 664007160 | THROTTLE CABLE PM 48S |
| 31 | 112735105/0 | SCREW X PM4850S |
| 32 | 12728460/0 | SCREW X PM4850S |
| 33 | 112523040/0 | WASHER X PM4850S |
| 34 | 112154510/0 | NUT X PM4850S |
| 35 | 181003288/1 | TRACTION LEVER X PM4850S |
| 36 | 322041965/1 | BUSHING FOR PLM4601 |
| 37 | 122041966/1 | BUSHING X PM4850S |
| 38 | 81003291/2 | MOTOR BRAKE LEVER X PM4850S |
| 39 | 22291050/0 | PM4850S BLACK HANDLE |
| 40 | 381007280/2 | PM4850S THROTTLE LEVER |
| 42 | 664120158 | BLACK PM4850S DASHBOARD |
| 43 | 22430309/0 | SPRING GUIDE X PM5150S |
| 44 | 22943006/0 | PM4850S SCREW |
| 45 | 81006861/0 | HANDLE, UPPER SIDE X PM5150S |
| 46 | 12791500/0 | SCREW X PM4850S |
| 47 | 112530060/0 | PM4850S ELASTIC WASHER |
| 48 | 322981467/0 | PLATE X PM4850S |
| 49 | 112154330/0 | NUT X PM4850S |
| 50 | 112819120/0 | SCREW X PM5150S |
| 51 | 322778397/1 | LEFT BRACKET FOR PLM4811 |
| 52 | 112793301/0 | SCREW X PM5150S |
| 53 | 12155000/0 | NUT X PM4850S |
| 54 | 322778396/1 | RIGHT BRACKET FOR PLM4811 |
| 55 | 381008609/0 | SCREW KIT |
| 56 | 81008610/0 | SCREW KIT X PM5150S |
| 101 | 22430309/0 | SPRING GUIDE X PM5150S |
| 103 | 664120164 | BLACK DASHBOARD X PM5150S |
| 104 | 81003291/2 | MOTOR BRAKE LEVER X PM4850S |
| 105 | 12726388/0 | SCREW X PM5150S |
| 106 | 22291050/0 | PM4850S BLACK HANDLE |
| 107 | 112290800/0 | NUT X PM5150S |
| 109 | 122399801/0 | KNOB X PM5150S |
| 110 | 322778397/1 | LEFT BRACKET FOR PLM4811 |
| 111 | 112819120/0 | SCREW X PM5150S |
| 112 | 122041966/1 | BUSHING X PM4850S |
| 113 | 12788910/0 | SCREW X PM5150S |
| 114 | 12728460/0 | SCREW X PM4850S |
| 115 | 81007091/0 | THROTTLE CABLE X PM5150S |
| 116 | 81000634/0 | MOTOR BRAKE CABLE X PM5150S |
| 117 | 112154330/0 | NUT X PM4850S |
| 118 | 22943006/0 | PM4850S SCREW |
| 119 | 112291000/0 | NUT X PM5150S |
| 121 | 112581500/0 | GROWER X PM5150S |
| 122 | 12523020/0 | WASHER X PM4850S |
| 123 | 381007028/1 | HANDLE, UPPER SIDE X PM5150S |
| 124 | 381008499/1 | DASH PANEL EQUIPMENT |
| 251 | 81001134/0 | PM5150S X COMMAND ROD |
| 252 | 12000930/0 | ELASTIC RING X PM4850S |
| 253 | 381002801/1 | FRONT AXLE FOR PM4850S |
| 254 | 112530150/0 | ELASTIC WASHER X PM4850S |
| 255 | 664122200 | BEARING X PM 48S |
| 256 | 664007317 | WHEEL D = 170 X PM4850S |
| 257 | 112521350/0 | WASHER X PM4850S |
| 258 | 12155000/0 | NUT X PM4850S |
| 259 | 22110290/0 | ORANGE TAPE PM43 |
| 260 | 664007318 | WHEEL D = 210 X PM4850S |
| 261 | 22110289/0 | RED HUBCAP X PM5150S |
| 262 | 122446187/0 | SPRING X PM4850S |
| 263 | 12604899/0 | WASHER X PM5150S |
| 264 | 112728519/0 | SCREW X PM5150S |
| 265 | 122529662/0 | PIN X PM5150S |
| 266 | 22672151/0 | WASHER X PM4850S |
| 267 | 381001269/0 | REAR ROD AXLE X PM5150S |
| 268 | 81000479/0 | SECTOR OF ADJUST X PM5150S |
| 269 | 12728520/0 | SCREW X PM4850S |
| 270 | 322060144/3 | CASING REGULATION X PM4850S |
| 271 | 112793301/0 | SCREW X PM5150S |
| 272 | 125038002/1 | BUSHING X PM5150S |
| 273 | 322785109/0 | SUPPORT X PM5150S |
| 274 | 112622640/0 | PIN X PM5150S |
| 275 | 322393611/2 | HANDLE X PM5150S |
| 276 | 12729600/0 | SCREW X PM4850S |
| 277 | 112293201/0 | NUT X PM4850S |
| 278 | 322785113/0 | HANDLE SUPPORT X PM5150S |
| 279 | 22446175/0 | SPRING X PM5150S |
| 280 | 122570200/0 | PLATE X PM5150S |
| 281 | 322672152/0 | WASHER X PM4850S |
| 401 | 112608600/0 | STOP RING FOR PM4850S |
| 402 | 122570120/1 | PINION SX X PM4850S |
| 403 | 664120105 | RING GEAR X PM 48S |
| 404 | 664600091 | GUARD WHEELS PM4850S |
| 405 | 381002811/0 | REAR AXLE WHEEL X PM4850S |
| 406 | 119216035/0 | PM4850S X BEARING |
| 407 | 122753000/0 | PM4850S PLUG |
| 408 | 22680009/0 | WASHER X PM4850S |
| 409 | 664110230 | PLUG X PM48S-4850S |
| 410 | 112154510/0 | NUT X PM4850S |
| 411 | 122450063/0 | SPRING X PM4850S |
| 412 | 664041957 | BUSHING X PM 48S |
| 413 | 122033281/0 | ADJUSTING ROD X PM4850S |
| 414 | 381000673/0 | PM4850S TRACTION CONTROL CABLE |
| 414A | 381000669/0 | TRACTION CABLE C / SPRING PM4850S |
| 415 | 664601909 | PULLEY X PM4850S |
| 416 | 664645705 | PIN X PM 48S |
| 417 | 664064195 | BELT Z 33 X PM5150S |
| 418 | 122570110/1 | PINION DX X PM4850S |
| 419 | 181003082/1 | TRACTION ASSY' FOR PM4850S |
| 501 | 664139100 | WOODRUFF PM 43 |
| 502 | 122465611/0 | HUB X PM4850S |
| 503 | 664160400 | ELASTIC WASHER X PM43 |
| 504 | 181004381/1 | BLADES FOR PM5360S3 |
| 505 | 112508120/0 | CUP SPRING X PM4850S |
| 506 | 322672105/0 | WASHER X PM4850S |
| 507 | 122041940/0 | METAL BUSH X PM4850S |
| 508 | 664735698 | SCREW X PM 43 |
| 552 | 81002124/1 | BAG X PM4850S |
| 553 | 181006430/0 | FRAME BAG X PM4850S |
| 555 | 22486065/0 | BAG, UPPER SIDE X PM4850S |
| 556 | 22486064/0 | BAG, LOWER SIDE X PM4850S |
