Dewalt D27113 Type 1 Mitre Saw Parts
€1.93
Tax included
Dewalt D27113 Type 1 Table Top Mitre Saw Spare Parts
DEWALT, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Dewalt D27113 Type 1 Table Top Mitre Saw Spare Parts.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Dewalt D27113 Type 1 Table Top Mitre Saw Spare Parts
DEWALT, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Dewalt D27113 Type 1 Table Top Mitre Saw Spare Parts.
In the following table, look for the model of the hammer and the respective parts of the code.
| DEWALT TABLE TOP MITRE SAW D27113 Type 1 GB Parts List | ||
| # | Part Num. | Description |
| 101 | 860085-19 | SCREW |
| 102 | N140117 | BASE SA |
| 103 | 153612-00 | FOOT |
| 104 | 330045-05 | SCREW |
| 105 | N140118 | GUARD SA |
| 108 | 330045-23 | SCREW |
| 110 | N053752 | SPRING TORSION |
| 111 | 153639-00 | SCREW |
| 120 | N140119 | TRUNNION |
| 121 | 391346-00 | SCREW |
| 122 | N056425 | DUST PORT |
| 124 | 330045-14 | SCREW |
| 125 | 397080-00 | HANDLE |
| 126 | 397089-00 | NUT |
| 128 | 612008-00 | SCREW |
| 140 | N083191 | BUSH |
| 141 | N170479 | LOCKING PIN |
| 142 | 943030-00 | O RING |
| 144 | 860092-00 | NUT |
| 147 | 098105-03 | SCREW |
| 148 | N140120 | BACK FENCE |
| 149 | N140121 | FENCE |
| 161 | 653947-00 | KNOB |
| 162 | N065550 | SCALE |
| 163 | 638875-00 | BOLT |
| 164 | N065549 | POINTER |
| 165 | 249233-00 | WASHER |
| 166 | 330045-05 | SCREW |
| 167 | 860092-05 | NUT |
| 168 | 613270-00 | WASHER |
| 169 | 153781-00 | WASHER |
| 170 | N140122 | CLAMP SA |
| 180 | 330045-06 | SCREW |
| 181 | N045946 | INSERT |
| 183 | 398693-00 | POINTER |
| 184 | 145439-10 | KNOB |
| 185 | 146733-00 | CLAMP |
| 186 | 391357-00 | CLAMP |
| 187 | 330045-55 | SCREW |
| 188 | 148611-00 | COVER |
| 189 | 146745-00 | SPRING |
| 190 | 330045-23 | SCREW |
| 191 | 604987-00 | SCREW |
| 192 | 391292-01 | DETENT |
| 193 | N140123 | TABLE ROTARY |
| 194 | 640146-00 | PAD |
| 195 | 860093-07 | SCREW |
| 196 | 147107-02 | KNOB LOWER |
| 197 | 630068-00 | SUPPORT |
| 198 | 330045-55 | SCREW |
| 199 | 630085-00 | GRIP |
| 210 | N095523 | GUARD UPPER |
| 211 | 612282-00 | SCREW |
| 212 | 330045-23 | SCREW |
| 213 | 860083-15 | NUT |
| 214 | N095520 | RIVING KNIFE |
| 220 | 860084-24 | SCREW |
| 221 | 860074-02 | WASHER |
| 222 | 330045-32 | SCREW |
| 223 | N114229 | TABLE |
| 224 | 637807-00 | SCALE |
| 225 | N142445 | LED LIGHT |
| 226 | 330045-55 | SCREW |
| 227 | N052767 | GUARD REAR |
| 228 | N142446 | GUARD SA |
| 229 | 330045-05 | SCREW |
| 230 | 330013-02 | SCREW |
| 231 | 330045-55 | SCREW |
| 235 | 391358-01 | HOLDER |
| 236 | 860094-02 | SCREW |
| 237 | 860610-01 | PUSHROD |
| 238 | N054742 | COLUMN |
| 239 | 153781-00 | WASHER |
| 240 | 606362-01 | BUSHING |
| 241 | N082707 | WEDGE |
| 242 | N124653 | SCREW |
| 245 | 860092-05 | NUT |
| 246 | 941756-00 | KNOB |
| 248 | 639383-00 | SPACER |
| 249 | 633290-04 | SPRING TORSION |
| 250 | 642980-00 | SPACER |
| 251 | N144184 | FOLLOWER |
| 255 | 153655-00 | WASHER |
| 256 | 397128-00 | PIVOT SHAFT |
| 257 | 153639-00 | SCREW |
| 258 | 637193-00 | LEVER |
| 259 | 637289-00 | SPRING |
| 260 | 949894-02 | SCREW |
| 265 | 637338-00 | LEVER LOCK |
| 266 | 605794-00 | LEVER LOCK |
| 268 | 605795-00 | CLEVIS PIN |
| 269 | 605798-00 | POINTER |
| 270 | 605796-00 | BRACKET |
| 275 | 392948-00 | WASHER CLAMP |
| 276 | 612008-00 | SCREW |
| 277 | 862427-00 | KNOB |
| 278 | 637805-00 | PLATE |
| 279 | 634738-00 | BRACKET |
| 280 | 637806-00 | FENCE |
| 285 | 869231-04 | FENCE SA |
| 286 | 385567-03 | KEY |
| 287 | 385567-04 | KEY |
| 288 | 330045-33 | SCREW |
| 289 | 385756-01 | BUSH |
| 290 | 624195-01 | BRACKET |
| 291 | N142447 | ARM |
| 292 | N144183 | STUD |
| 293 | 150075-00 | SCREW |
| 295 | 330045-13 | SCREW |
| 296 | 625857-00 | SCREW.SPECIAL |
| 297 | 330045-15 | SCREW |
| 298 | N052443 | COVER |
| 310 | 641845-00 | BRAND LABEL |
| 312 | 647776-00 | BLADE BOLT |
| 313 | 604765-00 | CLAMP OUTER |
| 314 | 616319-00 | WASHER INNER CLAMP |
| 314 | N186624 | INNER FLANGE SA |
| 315 | N186624 | INNER FLANGE SA |
| 315 | N186624 | INNER FLANGE SA |
| 316 | 330045-14 | SCREW |
| 317 | N052765 | GEARCASE COVER |
| 318 | 616979-01 | O RING |
| 319 | 330003-69 | BEARING |
| 320 | 939625-00 | WASHER |
| 325 | 330045-49 | SCREW |
| 326 | 949702-19 | SCREW |
| 328 | N142448 | GEAR & SPINDLE SA |
| 329 | 386780-00 | BEARING |
| 330 | 930098-00 | RETAINER |
| 335 | 696519-00 | RING |
| 336 | 391375-00 | BAFFLE |
| 337 | 330003-13 | BEARING BALL |
| 338 | N600857 | HANDLE SA |
| 339 | 330045-05 | SCREW |
| 340 | 326057-00 | TERMINAL BLOCK |
| 341 | 650889-00 | BUSHING |
| 342 | N142449 | SA POWER SUPPLY |
| 343 | N600857 | HANDLE SA |
| 345 | N600857 | HANDLE SA |
| 346 | 330019-13 | SCREW |
| 347 | 330060-85 | CORDSET |
| 348 | 615851-00 | BUSHING |
| 349 | 330045-08 | SCREW |
| 350 | 868320-00 | COVER |
| 350 | 653767-00 | FELT |
| 351 | N060327 | SWITCH |
| 352 | 650855-00 | FELT |
| 353 | 393071-00 | PLATE |
| 355 | 98094-55 | SCREW |
| 356 | 860073-07 | WASHER M6 |
| 357 | N052769 | BRACKET |
| 358 | 868082-00 | SPRING |
| 359 | 650846-00 | LOCK PIN |
| 360 | 653767-00 | FELT |
| 361 | 860322-00 | CIRCLIP |
| 367 | N102137 | SET OF LEAD WIRES |
| 368 | N141826 | CAPACITOR SA |
| 370 | 391933-00 | END CAP |
| 371 | N625165 | BRAND LABEL |
| 372 | 650828-00 | BRACKET |
| 373 | 391317-00 | FIELDCASE |
| 374 | 659512-00 | BRUSH PAIR |
| 375 | N463392 | BRUSH HOLDER SA |
| 376 | 330019-19 | SCREW |
| 377 | N142441 | FIELD 230V |
| 378 | 145312-00 | PLUG |
| 379 | N110359 | BEARING |
| 379 | N110359 | BEARING |
| 380 | N142443 | ARMATURE 230V |
| 381 | N136387 | LABEL |
| 385 | N154416 | WASHER |
| 386 | N052766 | LINK |
| 387 | N045949 | GUARD |
| 388 | N045948 | GUARD |
| 389 | 146774-00 | ROLLER - DISCONTINUED |
| 390 | 604728-00 | LOCKING RING |
| 391 | 629745-00 | CIRCLIP |
| 392 | N110617 | SPRING |
| 394 | 860093-10 | SCREW |
| 396 | 146740-02 | SLEEVE |
| 397 | 860073-01 | WASHER |
| 398 | 949719-04 | BEARING |
| 801 | 5140061-28 | GREASE |
| 821 | N102178 | RATING PLATE |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s DEWALT websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to DEWALT brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
