DeWalt Belt Sander DW433 Spare Parts
€1.78
Tax included
DeWalt Belt Sander DW433 Type 1 Spare Parts
DEWALT, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for DeWalt DW433 Type 1 Belt Sander.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
DeWalt Belt Sander DW433 Type 1 Spare Parts
DEWALT, original Accessories and spare parts, Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for DeWalt DW433 Type 1 Belt Sander.
In the following table, look for the model of the hammer and the respective parts of the code.
| DeWalt DW433 Type 1 Belt Sander Spare Parts | ||
| # | Part Num. | Description |
| 1 | 398028-00SV | GEAR CASE INCL. 120, 121 |
| 2 | 330045-06 | SCREW |
| 3 | 398097-00SV | SHAFT ASSEMBLY |
| 4 | 398050-00 | LEVER |
| 5 | 398074-00 | SPRING |
| 6 | 398064-00 | BUSHING |
| 7 | 098023-25 | SCREW |
| 8 | 330021-07 | NUT |
| 9 | 330016-02 | WASHER |
| 10 | 393745-00 | PLATE |
| 11 | 393758-00 | O-RING |
| 12 | 398094-00 | NUT |
| 13 | 398080-00SV | BASE & CORK PLATE DW432 & DW433 |
| 14 | 398049-00 | CLAMP |
| 15 | 153637-04 | SCREW |
| 16 | 398065-00 | COVER |
| 17 | 398076-01SV | 240v ARMATURE & FAN |
| 19 | 402051-04SV | FIELD |
| 20 | 393742-00 | FIELD CASE |
| 21 | 398045-01 | BRUSH SET 230V |
| 22 | 393747-00 | BAFFLE |
| 23 | 949638-02 | DAMPER |
| 24 | 398105-00 | COLLAR |
| 25 | 398108-00 | BRUSH HOLDER |
| 26 | 176951-00 | SCREW |
| 27 | 072412-00 | PLUG |
| 28 | 398036-00 | HANDLE |
| 29 | 615509-00 | ROLLER |
| 30 | 330019-14 | SCREW |
| 31 | 398098-00 | LOCKING SCREW |
| 32 | 398117-00 | HANDLE & COVER |
| 33 | N918736 | CORD PROTECTOR |
| 34 | N409399 | CORDSET (EURO) |
| 35 | 380414-00 | CORD CLAMP |
| 36 | N033987 | CONTROL MODULE SA |
| 37 | 330045-07 | SCREW |
| 38 | 619242-00 | SWITCH |
| 40 | 609468-00 | PAD |
| 41 | 619714-00 | WIRE LATE 2004 DATE CODES AND LATER |
| 41 | 612653-00 | WIRE |
| 42 | 398078-00 | LEAD WHITE |
| 43 | 398078-01 | LEAD WHITE |
| 44 | 398100-00 | TERMINAL BLOCK |
| 45 | 330015-01 | NUT |
| 47 | 393741-00 | DRIVE PULLEY |
| 48 | 330015-04 | NUT |
| 49 | 398029-00 | DRIVE BELT |
| 50 | 398030-00 | PULLEY |
| 51 | 330015-09 | NUT |
| 52 | 398096-00SV | SHAFT ASSEMBLY |
| 53 | 393753-00 | GEAR |
| 54 | 393755-00 | GEAR |
| 55 | N174784 | REPAIR KIT Includes 55, 57 |
| 56 | 393759-00 | PLATE |
| 57 | N174784 | REPAIR KIT Includes 55, 57 |
| 58 | 605040-17 | BEARING,BALL |
| 59 | 385244-00 | LOCKING RING |
| 60 | 640257-00 | YOKE SA INCL. (2) 125 |
| 61 | 398068-00 | SPACER |
| 62 | 614545-00 | ROLLER INCL. 125 |
| 63 | 398039-00 | SHAFT ASSEMBLY |
| 64 | 393752-01 | SHROUD |
| 65 | 606899-00 | NUT |
| 66 | 393746-00 | BAFFLE |
| 67 | 393743-00SV | FAN |
| 69 | 330045-13 | SCREW |
| 70 | 393749-01 | O-RING |
| 71 | 398027-01 | FRAME |
| 72 | 613099-00 | SCREW |
| 73 | 398083-00 | BAFFLE |
| 74 | 398079-00 | CLIP |
| 75 | 330015-02 | NUT |
| 76 | 398070-00 | KNOB |
| 77 | 398071-01SV | BELT COVER INC. 23, 127, 128 |
| 80 | N055169 | RATING PLATE |
| 81 | 398107-00 | POTENTIOMETER SA |
| 82 | 398111-00 | CAPACITOR |
| 83 | 617084-00 | PIN |
| 84 | 606902-00 | CAP |
| 85 | 636658-00 | BAFFLE |
| 104 | 398082-00 | HOLDER |
| 105 | 398072-00 | DUSTBAG & FRAME |
| 106 | 617085-00 | CLIP |
| 120 | N110359 | BEARING |
| 125 | N110359 | BEARING |
| 127 | 398115-00 | LABEL |
| 128 | 616067-00 | RATING PLATE |
| 800 | 761995-01 | GREASE 180 Grams |
| 800 | 283484-01 | GREASE 32oz, EXXON CVJ |
| 821 | N055167 | RATING PLATE |
| 836 | 559648-99 | S.T.ROLLER REMOVER |
| 837 | 559649-99 | S.T.ROLLER REMOVER |
| 856 | 340608-01 | BELT 80 GRIT |
