AEG Rotary Hammer KH7E Spare Parts
Fix Your Combi Rotary Hammer KH7E. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee.
In the following table, look for the model of the Drill Driver and their spare part.
| AEG KH7E COMBI HAMMER IN2 Spare Parts 4935459609 - KH7E - 4000463251 |
||
| # | Part Num. | Description |
| 4 | 4931624585 | CONNECTION CABLE |
| 6 | 4931432200 | ADHESIVE LABEL |
| 8 | 4931463254 | RATING PLATE |
| 9 | 4931412349 | RATING PLATE |
| 10 | 4931412344 | WORK STAND |
| 11 | 4931398263 | BAND |
| 12 | 4931398267 | NUT |
| 14 | 4931412346 | HANDLE |
| 16 | 4931622765 | SCREW N874101-1 SHR C-K5X45/20 KOMBITORX |
| 100 | 4931412340 | MOTOR HOUSING |
| 105 | 4931442747 | ELECTRIC FIELD |
| 106 | 4931442685 | ARMATURE |
| 111 | 4931426441 | BEARING END PLATE |
| 112 | 4931624541 | SCREW |
| 114 | 4931890311 | LOCKING RING |
| 115 | 4931398198 | SEAL RING |
| 116 | 4931398205 | AIR DEFLECTOR RING |
| 118 | 4931398006 | MOTOR CAP |
| 119 | 4931624565 | SCREW D7500-1CE M6X38 T30 Tapt.2000 SW B |
| 120 | 4931412338 | PAIR HANDLE SHELLS |
| 121 | 4931339996 | SCREW |
| 122 | 4931432207 | GEAR BOX INSULATION |
| 123 | 4931624263 | WIRE |
| 124 | 4931624538 | SCREW |
| 125 | 4931256500 | CABLE COLLAR |
| 126 | 4931624538 | SCREW |
| 128 | 4931398531 | PUSH-BUTTON |
| 129 | 4931624517 | SCREW N874101-1 SHR H-K4X22 T15 |
| 130 | 4931381694 | BRUSH HOLDER |
| 131 | 4931624504 | SCREW |
| 132 | 4931398673 | ELECTRIC ELEMENT |
| 133 | 4931398114 | LIGHT PIPE |
| 134 | 4931624681 | CABLE |
| 135 | 4931375458 | SWITCH |
| 156 | 4931398095 | BEARING |
| 158 | 4931398746 | BEARING BOLT |
| 200 | 4931463355 | GEAR BOX ASSY |
| 212 | 4931426455 | GEAR BOX COVER |
| 214 | 4931624555 | SCREW |
| 225 | 4931432431 | COUPLING |
| 236 | 4931409601 | CRANK WHEEL |
| 237 | 4931455235 | SPINDLE KIT |
| 238 | 4931455234 | SPINDLE SLEEVE |
| 239 | 4931398031 | BACK-PRESSURE RING |
| 241 | 4931398032 | DISC |
| 246 | 4931455749 | PERC. BODY W SEAL |
| 258 | 4931398792 | PISTON COMPL. |
| 268 | 4931398078 | SET COLLAR |
| 270 | 4931621847 | NEEDLE BEARING |
| 272 | 4931432188 | SPINDLE BEVEL GEAR |
| 273 | 4931398154 | ADJUSTING PIECE |
| 274 | 4931398075 | LOCKING PLATE |
| 275 | 4931398626 | SWITCH |
| 282 | 4931624479 | RING |
| 288 | 4931398749 | THRUST COLLAR |
| 290 | 4931624499 | DISC |
| 291 | 4931398658 | LATCH PLATE |
| 292 | 4931624236 | SCREW |
| 293 | 4931398097 | THRUST PIECE |
| 294 | 4931455748 | WASHER |
| 295 | 4931398099 | PRESSURE SPRING |
| 297 | 4931624535 | DISC |
| 305 | 4931398744 | SLEEVE |
| 306 | 4931426248 | INTERLOCK SLEAVE |
| 309 | 4931398856 | PRESSURE SPRING |
| 310 | 4931426013 | INTERLOCK ELEMENT |
| 406 | 4931449971 | ARMATURE ASSEMBLY |
| 605 | 4931398266 | DEPTH GAUGE |
| 700 | 4931412328 | CARRYING CASE |
| 705 | 4931412331 | HANDLE |
| 1200 | 4931463257 | MAINTENANCE SET |
| 1201 | 4931398132 | CARBON BRUSH SET |
| 1204 | 4931622166 | O-RING N874701 26X3 |
| 1205 | 4931393422 | PROTECTING COVER |
| 1207 | 4931398748 | DAMPING ELEMENT |
| 1208 | 4931398101 | SEALING SLEEVE |
| 1209 | 4931398085 | RUBBER SLEEVE |
| 1210 | 4931624440 | SEAL RING |
| 1212 | 4931398639 | SNAP DIE |
| 1213 | 4931398297 | O-RING (FKM) |
| 1216 | 4931398539 | SEAL |
| 1219 | 4931398105 | DAMPING ELEMENT |
| 1220 | 4931398033 | CORE LIFTER RING |
| 1221 | 4931398073 | RING |
| 1222 | 9170319040 | SPRING RING |
| 1223 | 4931487601 | INTERLOCK ELEMENT |
| 1224 | 4931398034 | SEAL RETAINER |
| 1225 | 4931398080 | INTERLOCK DISC |
| 1226 | 4931624495 | SEAL RING |
| 1227 | 4931398064 | RUBBER CAP |
| 1228 | 4931409768 | HOLDING-DOWN DEVICE |
| 1230 | 4931426013 | REPAIR KIT |
| 1231 | 4931398298 | WASHER |
| 1232 | 4931624586 | WASHER |
| 1234 | 4931398189 | GROOVED BALL BEAR. |
| 1235 | 4931341741 | BALL BEARING |
| 1236 | 4931426570 | MAGNETIC DISC |
| 1238 | 4931409781 | STOP WASHER |
