Compa-OMS Spare Parts for Portable Mitre Saws Orange 305/0
€3.78
Tax included
Compa-OMS Spare Parts for Portable Mitre Saw Orange 305/0
We are COMPA-OMS authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem forr Portable Mitre Saw Orange 305/0.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Compa-OMS Spare Parts for Portable Mitre Saw Orange 305/0
We are COMPA-OMS authorized service center and original spare parts Distributors. We offer low prices and a professional repair service able to advise you for to purchase the most suitable spare part to quickly solve any maintenance and repair problem forr Portable Mitre Saw Orange 305/0.
In the following table, look for the model of the Portable Saws and their spare part.
| MITRE SAW ORANGE 305/0 | ||
| # | Part Num. | Description |
| 1 | ORANG3050/001 | Blade attachment bolt |
| 2 | ORANG3050/002 | external flange |
| 4 | ORANG3050/004 | internal flange |
| 5 | ORANG3050/005 | M5 x 20 mm |
| 6 | ORANG3050/006 | M5 x 20 mm |
| 7 | ORANG3050/007 | Semi-left arm |
| 9 | ORANG3050/009 | Rivet d.4 x 8 mm |
| 10 | ORANG3050/010 | Bushing d.16 x d.10 x 12 mm |
| 11 | ORANG3050/011 | nut M5 |
| 12 | ORANG3050/012 | Connecting rod |
| 13 | ORANG3050/013 | Mobile Security |
| 14 | ORANG3050/014 | Sealing ring d.36 mm |
| 15 | ORANG3050/015 | Bushing d.14 x d.7.8 x 7.5 mm |
| 16 | ORANG3050/016 | M5 x 12 mm |
| 17 | ORANG3050/017 | Plastic cover |
| 18 | ORANG3050/018 | Screw M4 x 10 mm |
| 19 | ORANG3050/019 | Ball Bearing (6202) |
| 20 | ORANG3050/020 | Spring d.10.6 x 22 x 1.2 mm |
| 21 | ORANG3050/021 | stator |
| 22 | ORANG3050/022 | Bolt d.6 x M5 x 26 mm |
| 23 | ORANG3050/023 | Bushing d.23 x 25 mm |
| 24 | ORANG3050/024 | Ball Bearing (6203) |
| 25 | ORANG3050/025 | bearing cover |
| 26 | ORANG3050/026 | Riving knife locking plate |
| 27 | ORANG3050/027 | Screw M6 x 15 mm |
| 28 | ORANG3050/028 | Spring washer M6 |
| 29 | ORANG3050/029 | motor cover |
| 30 | ORANG3050/030 | Aluminum casing of the engine |
| 31 | ORANG3050/031 | Semi-right arm |
| 32 | ORANG3050/032 | riving knife |
| 33 | ORANG3050/033 | Screw M4 x 30 mm |
| 34 | ORANG3050/034 | Flat washer d.16 mm |
| 35 | ORANG3050/035 | Sealing ring d.16 mm |
| 36 | ORANG3050/036 | rotor |
| 37 | ORANG3050/037 | Semi-left handle |
| 38 | ORANG3050/038 | Start button |
| 39 | ORANG3050/039 | The tripping device start button |
| 40 | ORANG3050/040 | spring |
| 41 | ORANG3050/041 | Release button arm |
| 42 | ORANG3050/042 | Kit levers release arm |
| 43 | ORANG3050/043 | switch |
| 44 | ORANG3050/044 | Kit release levers blade |
| 45 | ORANG3050/045 | Spring d.7 x 45 mm x d.1 |
| 46 | ORANG3050/046 | Block release blade |
| 47 | ORANG3050/047 | Sealing ring d.10 mm |
| 48 | ORANG3050/048 | Pin release blade d.10 x 54 mm |
| 49 | ORANG3050/049 | fan |
| 50 | ORANG3050/050 | Semi-right handle |
| 51 | ORANG3050/051 | Screw M4 x 20 mm |
| 52 | ORANG3050/052 | Fan cover |
| 53 | ORANG3050/053 | M5 x 10 mm |
| 54 | ORANG3050/054 | M5 x 180 mm |
| 55 | ORANG3050/055 | Wing Knob M6 x 30 mm |
| 56 | ORANG3050/056 | Screw M4 x 10 mm |
| 57 | ORANG3050/057 | Flat washer d.4 mm |
| 58 | ORANG3050/058 | Spring D.11 x 140 mm x d.2 |
| 59 | ORANG3050/059 | clamp bracket |
| 60 | ORANG3050/060 | Colonetta driving raising plan |
| 61 | ORANG3050/061 | Colonnetta driving raising plan |
| 62 | ORANG3050/062 | Screw M6 x 25 mm |
| 63 | ORANG3050/063 | Upper clamp bracket top |
| 64 | ORANG3050/064 | nut M6 |
| 65 | ORANG3050/065 | Support bracket top |
| 66 | ORANG3050/066 | Caps upper bracket |
| 67 | ORANG3050/067 | Superior protection iron |
| 68 | ORANG3050/068 | nut M8 |
| 69 | ORANG3050/069 | Headphone blade guard |
| 70 | ORANG3050/070 | Lower guard upstairs |
| 71 | ORANG3050/071 | Locking knob headset |
| 72 | ORANG3050/072 | Spring d.7 x 7.5 mm x d.0.6 |
| 73 | ORANG3050/073 | Sealing ring d.6 mm |
| 74 | ORANG3050/074 | Roll Pin D.3 x 30 mm |
| 75 | ORANG3050/075 | Locking pin d.10 x 43 mm |
| 76 | ORANG3050/076 | Locking lever carousel |
| 77 | ORANG3050/077 | Spring d.8 x 21 x 0.7 mm |
| 78 | ORANG3050/078 | Nut M12 closed |
| 79 | ORANG3050/079 | Flat washer M12 |
| 80 | ORANG3050/080 | Locking pawl carousel M6 x |
| 81 | ORANG3050/081 | Rubber foot and slip |
| 82 | ORANG3050/082 | base |
| 83 | ORANG3050/083 | Wing Bolt M6 x 20 mm |
| 84 | ORANG3050/084 | M8 x 40 mm |
| 85 | ORANG3050/085 | carousel |
| 86 | ORANG3050/086 | bracket |
| 87 | ORANG3050/087 | fifth wheel |
| 88 | ORANG3050/088 | Cage portarullini complete |
| 89 | ORANG3050/089 | roll |
| 90 | ORANG3050/090 | lower protection |
| 91 | ORANG3050/091 | nut M6 |
| 92 | ORANG3050/092 | Threaded bolt M6 x 30 mm |
| 93 | ORANG3050/093 | Screw M12 x 85 mm |
| 94 | ORANG3050/094 | M5 x 10 mm |
| 95 | ORANG3050/095 | ORANGE conveyor 305-0 |
| 96 | ORANG3050/096 | spring |
| 97 | ORANG3050/097 | M8 x 15 mm |
| 98 | ORANG3050/098 | Flat washer d.8 mm |
| 99 | ORANG3050/099 | Guide plastic blade |
| 100 | ORANG3050/100 | M4 screw |
| 101 | ORANG3050/101 | Handle unlocks arm |
| 102 | ORANG3050/102 | Threaded bolt M6 x 45 mm |
| 103 | ORANG3050/103 | tree arm |
| 104 | ORANG3050/104 | Sealing ring d.16 mm |
| 105 | ORANG3050/105 | Support arm |
| 106 | ORANG3050/106 | Ball Bearing 6002 |
| 107 | ORANG3050/107 | Upper Work Table |
| 108 | ORANG3050/108 | upper bracket |
| 109 | ORANG3050/109 | Push stick |
| 110 | ORANG3050/110 | nut M6 |
| 112 | ORANG3050/112 | Sachetto chip deflector |
| 113 | ORANG3050/113 | Retaining bar piece |
| 114 | ORANG3050/114 | hex wrench |
| 115 | ORANG3050/115 | Allen key |
| 116 | ORANG3050/116 | vertical vice |
| 117 | ORANG3050/117 | USE BRAKE ORANGE |
| 118 | ORANG3050/118 | condenser |
| 119 | ORANG3050/119 | Plastic cover |
| 120 | ORANG3050/120 | D.25 knob M12 x 50 mm at the tip |
| 121 | ORANG3050/122 | electrical cable |
| 123 | ORANG3050/123 | Complete engine 305/0 (24-25-36-19-21-30- |
| 124 | ORANG3050/124 | Group upper bracket OR.305-0 |
| 125 | ORANG3050/125 | Fulcrum lever bushing housing |
