Compa-OMS Spare Parts for Portable Saws FC 300-350 RAP
€2.52
Tax included
Compa-OMS Spare Parts for Portable Mitre Saws FC 300-350 RAP
We supply original COMPA-OMS spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Professional Mitre Saws FC 300 RAP - FC 350 RAP.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Compa-OMS Spare Parts for Portable Mitre Saws FC 300-350 RAP
We supply original COMPA-OMS spare parts on offer at unbeatable prices, we are an authorized service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Professional Mitre Saws FC 300 RAP - FC 350 RAP.In the following table, look for the model of the Professional Mitre Saws and their spare part.
| Professional Miter Saws FC 300 RAP - FC 350 RAP | |||
| # | Description | FC 300 RAP | FC 350 RAP |
| 1 | Complete motor TF | 801504-00 | 801504-00 |
| 1A | Complete motor MF | 801503-00 | 801503-00 |
| 2 | Group movement shelter | KIT007001 | KIT007002 |
| 2 | outer ring | 801097-02 | 801097-02 |
| 2 | Pin limit | 801344-01 | 801344-01 |
| 2 | Ball joint DIN 81 702-M6 | 801176-00 | 801176-00 |
| 2 | M6 threaded bolt | 800300-00 | 800300-00 |
| 2 | Plastic tube diam. int. 6 L = 10 | 401561-03 | 401561-03 |
| 2 | Tie rod | 801520-01 | 801520-02 |
| 2 | spring | 800965-00 | 800965-00 |
| 2 | Pin Menato M6 | 800195-00 | 800195-00 |
| 2 | Shaped bracket | 801090-00 | 801090-00 |
| 3 | Collarbush | 801094-00 | 801094-00 |
| 4 | sump | 801072-00LAV | 801069-00 |
| 5 | Prisoners locking motor | ||
| 6 | Guard release Kit | KIT008002 | KIT008002 |
| 6 | button release | 801519-00 | 801519-00 |
| 6 | Return spring lever | 401308-01 | 401308-01 |
| 6 | Pivot lever | 801095-00 | 801095-00 |
| 6 | Collarbush | 801094-00 | 801094-00 |
| 6 | lever | 801089-00 | 801089-00 |
| 7 | switch 3 F | 401318-04 | 401318-04 |
| 7 | MF switch | 401318-03 | 401318-03 |
| 8 | Terminal covers TF | 800077-00 | 800077-00 |
| 9 | handle assembly | KIT013001 | KIT013001 |
| 9 | Semimpugnatura lower | 801070-00 | 801070-00 |
| 9 | Semimpugrratura top | 801071-00 | 801071-00 |
| 10 | cable cover | 801088-00 | 801088-00 |
| 11 | Pair of faceplates cable cover | 801087-00 | 801087-00 |
| 12 | cable clamp | ||
| 13 | motor pulley | 800510-00 | 800510-00 |
| 14 | Grain UNI 5927 CE PC M6x8 | ||
| 15 | V-belt Polij-J6 SV.711 | 800416-00 | 800416-00 |
| 16 | Casing belt | 800375-00 | 800376-00 |
| 17 | Box + cover + screws | ||
| 18 | Blade shaft assembly | KIT005007 | KIT005007 |
| 18 | tree blade | 800500-02 | 800500-02 |
| 18 | internal spacer | 800534-00 | 800534-00 |
| 18 | external spacer | 800535-00 | 800535-00 |
| 18 | key | 800331-02 | 800331-02 |
| 18 | bearing 6204-2Z | 36020450 | 36020450 |
| 18 | pulley shaft | 800511-00 | 800511-00 |
| 19 | Fan cover | 801459-00 | 801459-00 |
| 20 | fan | 801659-01 | 801659-01 |
| 21 | inner flange | 800505-01 | 800505-01 |
| 22 | Outer flange | 800506-00 | 800506-00 |
| 23 | Fixing screw blade | 0228 | 0228 |
| 24 | Blade Guard | 800083-00 | 800083-00 |
| 25 | Blade Guard Cpl. | KIT007003 | KIT007004 |
| 25 | shelter blade | 800353-00LAV | 801082-03LAV |
| 25 | Threaded bushing | 801281-01 | 801281-01 |
| 26 | overall cylinder | KIT006001 | KIT006002 |
| 26 | cylinder connection | 800203-00 | 800203-02 |
| 26 | fork | 800126-00 | 800126-00 |
| 26 | Damper bush | 800059-01 | 800059-01 |
| 26 | tie rod cylinder | 800069-01 | 800069-00 |
| 26 | centering spring Bush | 800061-00 | 800061-00 |
| 26 | cylinder | 800063-01 | 800063-00 |
| 26 | Return spring arm | 800674-01 | 800674-02 |
| 26 | Fixed pivot lower cylinder | 801022-00 | |
| 26 | Pin + fork + split pin | 800129-00 | 800129-00 |
| 27 | couple gibs | KIT003001 | KIT003002 |
| 27A | Left Fence | 800669-00LAV | 800663-01LAV |
| 27B | Right Fence | 800668-00LAV | 800662-00LAV |
| 27C | knob M6x15 | 800963-00 | 800963-00 |
| 28 | rubber | 801388-00 | 801388-00 |
| 29 | ferrule | 800169-01 | 800169-01 |
| 30 | O-ring | 800467-00 | 800467-01 |
| 31 | Tapered roller bearings 30204 | 800291-00 | 800291-00 |
| 32 | Axial bearing 51106 | 800289-03 | 800289-03 |
| 33 | Knuckle pin head | 800514-00 | 800514-00 |
| 34 | drain pipe | 800548-00 | 800548-00 |
| 35 | conveyor | 801386-03 | 801386-03 |
| 36 | full log | KIT004001 | KIT004001 |
| 36 | rod 012x400 | 800507-00 | 800507-00 |
| 36 | Plastic catch | 800057-01 | 800057-01 |
| 36 | rod 01Ox300 | 800057-02 | 800057-02 |
| 36 | binoculars | 800058-00 | 800058-00 |
| 36 | knob M6x15 | 0188 | 0188 |
| 40 | full basement | KIT001007 | KIT001008 |
| 40 | base | 800043-00LAV | 800344-00LAV |
| 40 | turntable | 800355-00LAV | 800345-00 |
| 38 | Axial bearing 51114/51117 | 800289-02 | 800289-04 |
| 41 | Foot log | 801333-00 | 801333-00 |
| 42 | sector grooved | 800055-00LAV | 800654-00LAV |
| 43 | thrust bearing | ||
| 43 | Cage AXK axial 3552 | 800293-02 | 800293-02 |
| 43 | Turntable AS 3552 | 800293-01 | 800293-01 |
| 44 | Arm displacement degrees | 800053-00LAV | 800361-00LAV |
| 45 | Complete handle displacement degrees | KIT002001 | KIT002001 |
| 45 | Tube handle | 800052-00 | 800052-00 |
| 45 | lever | 800078-00 | 800078-00 |
| 45 | fork | 800127-00 | 800127-00 |
| 45 | tie rod M6 | 800214-00 | 800214-00 |
| 45 | spring | 800099-01 | 800099-01 |
| 45 | fattener | 800139-00 | 800139-00 |
| 45 | selector | 800213-01 | 800213-01 |
| 45 | Cap for tube | 800086-00 | 800086-00 |
| 46 | Graduated plate | 800257-00 | 800257-01 |
| 47 | Grain UNI 5923 M8x16 | ||
| 48 | nameplate index | 800245-00 | 800245-00 |
| 49 | Locking pawl | 800686-00 | 800686-00 |
| 50 | Terminal block | ||
| 51 | rectifier | 801462-00 | 801462-00 |
| 53 | blade | vedi acces. | vedi acces. |
| 54 | Group door unlock blade | KIT008003 | KIT008003 |
| 54 | lever pivot | 800197-00 | 800197-00 |
| 54 | tie rod | 801091-00 | 801091-00 |
| 54 | hammer | 801092-00 | 801092-00 |
| 55 | Bearing 6005 ZZ (25x47x12) | 800290-09 | 800290-09 |
| 56 | Ring shelter blade | 801096-00 | 801096-00 |
| 57 | hexagonal pin | 801345-01 | 801345-01 |
| 58 | Couple extra protection | ||
| 58 | Additional protection Sx | 801706-00 | 801706-00 |
| 58 | additional protection | 801707-00 | 801707-00 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Compa-OMS websites, which we consider as reliable.Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice.We strongly recommend using the published information as a basic information subject to Compa-OMS brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
