Compa-OMS Spare Parts for Portable Saws 2301 XL MAXIMA
€2.52
Tax included
Compa-OMS Spare Parts for Portable Saws 2301 XL MAXIMA
COMPA-OMS Authorized Technical Assistance and original spare parts Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Professional Portable Mitre Saws 2301 XL MAXIMA.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Compa-OMS Spare Parts for Portable Saws 2301 XL MAXIMA
COMPA-OMS Authorized Technical Assistance and original spare parts Worldwide Distributors and wholesalers. We offer low prices and a professional repair service able to advise you for to buy the most suitable spare part to quickly solve any maintenance and repair issues for Professional Portable Mitre Saws 2301 XL MAXIMA.In the following table, look for the model of the Mitre Saws and their spare part.
| MITRE SAW 2301XL MAXIMA | |
| Part Num. | Description |
| 0115 | Cockerel (Key of serr.CSP M6x25) |
| 0118 | Washer Brass d.24x10,5x2 |
| 0134 | Ades.cuffie / occh. / Gloves unific.PVC |
| 0139 | terminals couple p.ta rods arr. |
| 0163 | Knob d.20 M6x10 (01TBP20C10) |
| 0184 | THP knob d.20 M6x15 nylon tip |
| 0207 | Bearing 6201 2Z (CTK) (HCH) mm.12x32x10 |
| 0214 | rubber grommet |
| PULSANTE | 82L5 button 2 MORS.VERDE + PR. |
| 0216 | VVF cable 3x1 + mt.2 sp.SHUKO FR. |
| 0222 | thrust 51100 |
| 0228 | Brug.f.sega HEX SOCKET HEAD M10x25 SX Zn |
| 0283 | disc brake pads |
| 0284 | Spring 'CO.MEC 720 P.32'x brake |
| 0292 | Cond. 20mF V.450 2 cav.mm.250 |
| 0293 | d.30 knob M10x60 conical tip |
| 0522 | Presser universal vise |
| 0623 | rod mil.335 all.ades.x3000 3500 2300X |
| 0636 | adhesive aluminum arrow |
| 0642 | rod traf.d.10x330 x BIG / 350 |
| 0805 | Lot asp.C216 / G d.60 int + Hinge |
| 0806 | Clamp HOP9 d.40-70 |
| 0851 | Suction bag support |
| 0911LAV | motor cover 250 WORKED |
| 0912 | Copriv.mot.picc.Policarb. 250/300/2300 |
| 0913 | Vent.mot.picc. 250/300/2300 |
| 23010012LAV | base x mod.2300 (vers.reggispinta) |
| 23010020LAV | ruot.LAVORATA table |
| 23010070 | P.ta roll cage mounted |
| 23010080 | fifth wheel |
| 23010090 | Saucer stops brackets |
| 23010110 | Washer dished x bas.to 2300 |
| 23010120 | rubber foot univ.x 2300 / 1-3000 / 1-3500 |
| 23010140 | lever positioning ring |
| 23010160 | lever return spring |
| 23010170 | Lever positioning table |
| 23010180 | Galletto NPT d.40 M8x210 |
| 23010220 | Snap handle KP79 M10 (0179E) |
| 23010320 | Index graduated sector 2300/3000/3500 |
| 23010330 | Spacer for rod blocc.tavola 2300 |
| 23010390 | A leaf spring X 2300/1 |
| 23010400 | Bush to get up lever cover 2300 |
| 23010420 | Bezel mounting brackets |
| 23010450 | x lateral support base 2300 XL |
| 23010490 | Right bracket x mod.2300XL / 3000/5300 |
| 23020012 | Arm worked vers. "MAXIMA" |
| 23020020 | Arm Cover x 2300 |
| 23020050 | Grip x line 2300 |
| 23020060 | Trigger Grip line x 2300 |
| 23020070 | Tear-proof cable clamp x impugn.tipo 2300 |
| 23020100 | Jack x wheel guard |
| 23020180 | Guy M5x180 Zn |
| 23020200 | Jack fulcrum arm |
| 23020232 | short release lever 2300 |
| 23020250 | Arm spring rod tube |
| 23020300 | Cover version x 2301 |
| 23020320 | fulcrum bolt release lever TC M6 d.12x16,5 |
| 23020490 | Long release lever |
| 23020610 | plast protection. motor 90x120 |
| 23020620 | Rosetta spingimolla |
| 23020630 | Jack spring adjustment |
| 23020640 | Spring holder rod |
| 23020651 | Arm spring 2300 L.130 |
| 23020660 | Arm spring spacer 2300 |
| 23020691 | Flat reinforces spring 2300 NEW |
| 23020695 | Spacer reinforcement spring 2300 |
| 23020740 | Laser support bracket |
| 23020750 | laser terminal |
| 23020760 | Cover laser terminal |
| 23020770 | focus laser pin clamp |
| 23020780 | assembled Laser + Box p.ta batteries |
| 23020801 Lav | Carter engine support 2300 MAX.LAVORATO |
| 23020843 | drive pulley x MAXIMA (new ver.) |
| 23020854 | driven pulley x MAXIMA (new ver.) |
| 23020861 | Driven shaft MAXIMA |
| 23020870 | Washer stops pulley MAXIMA |
| 23020880 | Locking Washer Saw WORKED |
| 23020890 | Washer stops Saw |
| 23020900 LAV | Sliding Blade Guard |
| 23020901 | extension spring nr.9 |
| 23020910 | for internal protection ring |
| 23020920 | conveyor maxima |
| 23020930 | Get up lever guard maxima |
| 23021030 | spacer |
| 23021071 | Sheet interposed maxima |
| 23021081 | Belt x MAXIMA line - HP255 5MHP15 |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Compa-OMS websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Compa-OMS brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
2301 XL MAXIMA
12 Items
