Bosch Spare Parts for Hammer GBH 7/45 DE

€2.23
Tax included

Bosch Spare Parts for Hammer GBH 7/45 DE

Bosch original spare parts for to replace broken parts for to fix Rotary Hammer GBH 7 45 DE - 0611214703.

Bosch GBH 7 45 DE - 0611214703
ITEM CODE: 1600210004
Quantity
on 10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Bosch Spare Parts for Hammer GBH 7/45 DE

Bosch original spare parts for to replace broken parts for to fix Rotary Hammer GBH 7 45 DE - 0611214703.

In the following table, look for the model of the Hammer and the respective parts of the code.
Bosch GBH 7 45 DE - 0611214703

Rotary Hammer GBH 7/45 DE/0611214703
# Part Num. Description
2 1614220090 Field 220-240V
4 1617200040 On-Off Switch
6 1610703053 Grommet Ø9,7-Ø12x89 MM
3600703011 Grommet Ø9,2-Ø12x120 MM
7 1611034020 Fastening Clamp
9 1611110480 Manufacturer's nameplate
13 1610905009 groove ball bearing 9x26x8
14 1610905008 groove ball bearing 12x32x10
15 1616610067 Fan
17 1610500013 Friction Washer
18 1610210040 O-Ring 16,0x5,0 MM
20 1618597054 Toolholder
21 1613124014 Locking Bolt
22 1610506006 Guide Bushing
23 1614616002 Compression Spring
24 1610320002 Guide Bushing
26 1618598150 Bit holder Ø 19 MM
27 1610103018 Stop Disc Ø 26 MM
28 1610113011 Supporting Disc
30 1610523001 Damping Bushing
31 1610309002 Damping Bushing
32 1610101616 Supporting Disc 1,5 MM THICK
33 1616317031 Cylindrical Gear Z=57/8
34 1615806073 Hammer Pipe
35 1618710048 Striker
36 1614616005 Compression Spring
37 1618700053 Hammer Piston
38 1615190010 Covering hood
39 1611015030 Sealing Frame
40 1615808059 Bearing cover
41 1613219001 Piston Pin
42 1614336005 Brush Holder
43 1615808068 Bearing cover BLUE
44 1611015032 Frame
45 1615133027 Handle BLACK
46 1615500269 Handle Cover BLACK
48 1616333018 Bevel Gear Z=35
49 1615819011 Drive bearing
52 1615820086 Bearing Flange
53 1611015031 Sealing Frame
56 1613060012 Toothed Shaft Z=10
59 1610591010 Plug
60 1612026022 Clamp Handle
61 2917550138 Straight Pin 5M6x70 RIKO DIN 6325
62 1614680003 Holding Spring
63 1611329008 Control Fork
64 1610102620 Supporting Disc 1,0 MM THICK
65 1610101617 Supporting Disc 2,5 MM THICK
66 1610101615 Supporting Disc 0,5 MM THICK
68 1610101618 Shim 0,3 MM THICK
1610101621 Shim 0,1 MM THICK
72 1615500284 Sealing cap BLUE
73 1610210082 Clamping Ring
74 1614652000 Spiral Spring
75 1615190011 Socket Housing
76 1617328016 Suppression Filter BLUE
77 1617328017 Suppression Filter GRAY
78 1614431022 Connecting Cable L=35 MM WHITE
80 1617233006 Control device 220-240V
81 1614616007 Compression Spring
82 1614616006 Compression Spring
84 1612025060 Auxiliary Handle M8 BLACK
1612025019 Auxiliary Handle M8
85 1618040076 index turning toolholder
86 1613521003 Stud bolt M8
87 1611316003 Clamping Band Ø43 MM
88 1613100012 Straight Pin
89 1613480009 Wing Screw M6x25 MM
90 1613300006 Hex Nut M6
91 1611030009 Clamping Plate
92 2917550118 Straight Pin 5M6x12 RIKO DIN 6325
98 1610900023 groove ball bearing
99 1610910068 Needle bearing
100 2600910001 Needle bearing Ø14 MM
101 2600910000 Needle bearing
103 2916690007 Spring Lock Washer DIN 128-A8-FST
105 1614601004 Retaining ring
107 2916601012 Retaining ring DIN 9045-24
108 1900210104 O-Ring 8x2 MM
110 1600210004 O-Ring 54,0x3,0 MM
111 1610210078 O-Ring 26,0x3,0 MM
112 1610210079 O-Ring 22,0x4,0 MM
113 1610210080 O-Ring 27,5x10,5 MM
114 1610210077 O-Ring 41,0x3,0 MM
115 1610210081 O-Ring 10,0x1,0 MM
117 2910141262 Hex Socket Head Cap Screw DIN 912-M8x80-8.8
118 2910141244 Hex Socket Head Cap Screw DIN 912-M8x25-8.8
120 2910211038 Tapping Screw DIN 7971-ST4,8x38-F
122 1603435008 Tapping Screw BZ4,8x63 MM
123 2910211236 Tapping Screw DIN 7971-ST4,8x25-C
125 2910601118 Tapping Screw DIN 7972-B3,9x13
126 2910211011 Tapping Screw DIN 7971-BZ3,5x13
128 2910021118 Socket head cap screw DIN 84-AM4x8-8.8
129 2603410001 Socket head cap screw M3x6,5-4.8
131 1611110481 Manufacturer's nameplate
135 1611110387 Reference Plate
149 1610108014 Felt Disc
650 1615438148 Carrying Case
655/10 1610508014 Protective Cap
1610508001 Sealing cap Ø15xØ27,5x36 MM
655/20 1610508013 Protective Cap
1610508009 Protective Cap
801 1617000938 Assembly Of Service Parts
810 1617014110 Carbon-Brush Set
812 1617328015 Suppression Filter
819 1617000123 Hex Socket Head Cap Screw DIN 912-M6x25-10.9
820 1617000912 Tool Holder Set
821 1617000014 Locking Bolt Set
830 1614011038 Armature 220-240V
835 1607000228 Power supply cord EU 4,15m 2 x 1,5mm H07 RN-F
850 1617000927 Parts Set
879 1613001008 Depth-Gauge SW 6x330 MM
880 1617000159 Modification Set 220-240V
884 1612025039 Auxiliary Handle
888 1601106032 Nameplate 26x52 MM
894 1617000169 Needle-Roller Assembly
895 1610101008 Thrust Bearing Disc 1,0 MM THICK
897 1617000181 Wear and Tear Part Set
898 1617000182 Wear and Tear Part Set
899 1610910068 Needle bearing

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Bosch websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Bosch brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch GBH 7 45 DE - 0611214703
9 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS APPROX.
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:
BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
New

Download

Diagram Bosch GBH 7/45 DE

Diagram Bosch GBH 7/45 DE

Download (165.14KB)
