Bosch Spare Parts for Rotary Hammer GBH 2-22 RE
search
  • Bosch Spare Parts for Rotary Hammer GBH 2-22 RE
  • Bosch Spare Parts for Rotary Hammer GBH 2-22 RE
  • Bosch Spare Parts for Rotary Hammer GBH 2-22 RE

Bosch Spare Parts for Rotary Hammer GBH 2-22 RE

€7.84
Tax included

Bosch Spare Parts for Rotary Hammer GBH 2-22 RE

We have the original Bosch Spare Parts for Rotary Hammer GBH 2-22 RE, the diagram, parts list and tool repair that help you need to get your tools running like new again

Fix Your Rotary Hammer GBH 2-22 RE - 0611250703. All Spares are original and can be supplied at Low and discounted prices. Our Spares are Genuine Parts and Come with a Full Guarantee


Bosch GBH 2-22 RE - 0611250703
ITEM CODE: 1600900037
Quantity
on 10 Business Days Approx

  Politiche per la sicurezza

(modificale nel modulo Rassicurazioni cliente)

  Politiche per le spedizioni

(modificale nel modulo Rassicurazioni cliente)

  Politiche per i resi

(modificale nel modulo Rassicurazioni cliente)

Bosch Spare Parts for Rotary Hammer GBH 2-22 RE

We have the original Bosch Spare Parts for Rotary Hammer GBH 2-22 RE, the diagram, parts list and tool repair that help you need to get your tools running like new again.

Fix YourRotary Hammer GBH 2-22 RE - 0611250703. All Spares are original and can be supplied at Low and discounted prices For Shipping. Our Spares are Genuine Parts and Come with a Full Guarantee.

In the following table, look for the model of the Hammer and the respective parts of the code.
Bosch GBH 2-22 RE - 0611250703

Rotary Hammer GBH 2-22 RE/0 611 250 703
# Part Num. Description
2 2604220683 Field 220-230V
4 1617200532 Switch
6 2600703018 Grommet Ø7,3-Ø8,6x76 MM
9 1611110A77 Manufacturer's nameplate
10 1611110A79 Reference Plate
17 1614465011 Suppression Filter
21 1616490070 Ratchet Sleeve
22 1616312003 Cylindrical Gear
26 1617000534 Hammer Piston
42395 1618700075 Hammer Piston
27 1618710080 Striker
28 1613124077 Striker Pin Ø7,5 MM
29 1613105012 Piston Pin
34 1610190049 Supporting Disc
36 1601329040 Tensioning Bracket
38 1610190045 Catch Disk
41 1615500334 Housing Cover BLUE
42 1610422017 Thrust Ring
44 1610508047 Protective Cap
45 1610522012 Air-Deflector Ring
46 1612026097 Clamp Handle BLACK
48 1601021005 Shift Plate
49 1615700044 End Shield
50 1604611037 Compression Spring
54 1610502012 Rubber Bushing
55 1610290226 Seal ring 53,0x7,0 MM
56 1610210187 O-Ring
57 1610210068 O-Ring 24,0x2,5 MM
59 1610210177 O-Ring 9,0x2,0 MM
64 1610202026 Plain bearing
65 1600900037 groove ball bearing
66 1610202020 Plain bearing
67 1610910098 Needle bearing
68 1610283017 Rotary shaft lip seal
70 1903230013 Ball DIN 5401-Ø7MM-III-ST
71 1610101011 Shim washer 1,2 MM THICK
72 1604601027 Retaining ring
73 1614601057 Retaining ring
74 1614601027 Retaining ring
75 1610101629 Retaining Washer
76 160343000A Thread-forming tap. Screw
77 2603490024 Torx Oval-Head Screw 4x25
78 2603490022 Torx Oval-Head Screw 4x16
79 1613435023 Thread-forming tap. Screw
87 2916540012 Retaining ring DIN 7993-A22
94 1610205010 Felt Seal
96 1612026035 Switch Button RED
97 1903201118 Needle Roller
98 1610210046 O-Ring 10,5x2,7 MM
99 1614611006 Compression Spring
101 1614449014 Connecting Cable
102 1614449015 Connecting Cable
103 2603490017 Torx Oval-Head Screw 3x10
190 1611110X79 Manufacturer's nameplate
651 1613001009 Depth-Gauge SW 6x210 MM
691/895 1615438409 Lock for 1 615 438 486+...358+...367
1615438431 Lock for 1 615 438 429 + 1 615 438 430
801 1617000523 Motor Housing BLUE
803 1617000524 Armature With Fan 220-230V
805 1607000392 Power supply cord EU 4,15m 2 x 1,0mm H07 RN-F
806 1900452012 End Splice DIN 46 228-A1-6
808 1601106035 Nameplate 26x42 MM
811 1617000525 Carbon-Brush Set
1607000485 Carbon-Brush Set 10 x 1 617 000 525
813 1610905025 groove ball bearing 7x19x6
814 1610905048 groove ball bearing 9x24x7
816 1614336061 Brush Plate
820 1617000526 Intermediate Flange
821 1617000V81 Ratchet Sleeve
822 2602025118 Auxiliary Handle Ø43 MM
822/120 1612025019 Auxiliary Handle M8
822/124 1611316006 Clamping Band Ø43 MM
822/125 1613490002 T-Head Bolt M8x40 MM
822/802 2608040176 index turning toolholder Ø43 MM
824 1617000892 Toothed Shaft
832 1617000529 Guide Sleeve
835 1616610093 Fan
840 1617000530 Gear Housing BLACK
843 1617000531 Protection Sleeve BLACK
870 1617000154 Drill Chuck Shank 1/2" SDS-PLUS
870/2 2603421207 Countersunk-Head Screw M6x27-KØ11 LEFTHAND THREADS
871 1608571088 Chuck
872 2607950007 Chuck Wrench SG2
880 2603435015 Recessed-Head Screw DIN 7981-ST3,5x9,5-F

All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Bosch websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Bosch brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
Bosch GBH 2-22 RE - 0611250703
6 Items

Data sheet

SHIPPING IN:
Usually Ships in: 10 BUSYNESS DAYS APPROX.
CHECK ITEM CODE OR S/N:
CHECK YOUR TOOL CODE OR S/N BEFORE CHECKOUT
CHECK S/N BOSCH:
BOSCH S/N START WITH (0) or (3) AND HAVE 10 DIGITS
New

Download

Diagram Bosch GBH 2-22 RE

Diagram Bosch GBH 2-22 RE

Download (153.14KB)
