Bosch Spare Parts for Wall Chaser GNF 20 CA
€1.57
Tax included
Bosch Spare Parts for Wall Chaser GNF 20 CA
Bosch genuine replacement parts for to replace broken parts for to fix Wall Chaser GNF 20 CA - 0601612503.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Wall Chaser GNF 20 CA
Bosch genuine replacement parts for to replace broken parts for to fix Wall Chaser GNF 20 CA - 0601612503.
In the following table, look for the model of the Groover and the respective parts of the code.
| Wall Chaser GNF 20 CA/0 601 612 503 | ||
| # | Part Num. | Description |
| 3 | 3605500081 | Protective Cover |
| 6 | 3603105005 | Bearing Shaft |
| 7 | 3600309003 | Roller |
| 9 | 3601902012 | Locking Lever |
| 10 | 3601923001 | Rejection Slide |
| 11 | 3600390023 | Clamping-Flange |
| 12 | 3603345005 | Round Nut M14 |
| 13 | 3609202041 | Plain Washer Ø 42X22,2X4 MM |
| 14 | 3602305011 | Push-Button |
| 15 | 3604651004 | Torsion Spring |
| 16 | 3604651006 | Coiled Spring |
| 17 | 3604651005 | Coiled Spring |
| 20 | 3601023003 | Safety Catch |
| 21 | 3604680002 | Shaped Spring |
| 22 | 3600300029 | Spacer Tube |
| 25 | 3600300028 | Spacer Sleeve |
| 26 | 3601990002 | Handle |
| 27 | 3605500078 | Protective Cap |
| 28 | 3603490015 | Pan head screw M 10x12 MM |
| 29 | 3601119425 | Manufacturer's nameplate |
| 31 | 2603490023 | Torx Oval-Head Screw 4x20 |
| 32 | 2603490027 | Torx Oval-Head Screw 4x40 |
| 33 | 2603490017 | Torx Oval-Head Screw 3x10 |
| 35 | 2916089079 | Locking Washer |
| 37 | 2917511104 | Straight Pin DIN 7-4MM6x28-C35K-RIKO |
| 41 | 3601119076 | Reference Plate |
| 49 | 1613490017 | Thread-forming tap. Screw M4x30 DIN7500-1 T-20 |
| 201 | 1605108151 | Motor Housing BLUE |
| 202 | 1604220220 | Field 220-230V |
| 204 | 1607200086 | Switch |
| 204/10 | 2910110048 | Pan head screw DIN 85-AM3x6-CUZN |
| 206 | 2600703013 | Grommet Ø7,6-Ø8,2x95 MM |
| 207 | 1601302017 | Fastening Clamp |
| 209 | 1601110665 | Manufacturer's nameplate |
| 212 | 1607328029 | Suppression Filter |
| 213 | 2600905032 | groove ball bearing 7x19x6 |
| 214 | 1600905011 | groove ball bearing 8x22x7 |
| 215 | 1606610121 | Fan |
| 216 | 1600A003G4 | Brush Holder |
| 217 | 3601110396 | Reference Plate |
| 218 | 1604611026 | Compression Spring |
| 222 | 1602319002 | Adjusting Slide |
| 223 | 1602026057 | Switch Handle BLACK |
| 225 | 1600508010 | Housing Cover BLUE |
| 226 | 1600502020 | Rubber Bushing |
| 227 | 1600206025 | Rubber Ring |
| 229 | 1601328005 | Air-Deflector Ring |
| 231 | 2916660013 | Spring retaining ring DIN 472-32x1,2 MM |
| 233 | 3600210124 | O-Ring 46,0x1,1 MM RED |
| 235 | 1600136012 | Shim 0,1 MM THICK |
| 235a | 1600136010 | Shim 0,2 MM THICK |
| 235b | 1600136011 | Shim 0,3 MM THICK |
| 236 | 1600150011 | Spring Washer |
| 237 | 1600290016 | Rotary shaft lip seal |
| 238 | 1606333235 | Crown Gear Z=35 |
| 239 | 1604652013 | Spiral Spring |
| 240 | 2916660009 | Spring retaining ring DIN 472-25x1,2MM |
| 241 | 1600910018 | Needle bearing Ø8xØ12x8 MM |
| 242 | 1600905006 | groove ball bearing 12x32x10 |
| 243 | 1606333234 | Bevel Gear Z=9 |
| 245 | 1603300016 | Hex Nut M7, SW10 |
| 247 | 2910211018 | Tapping Screw DIN 7971-ST3,9x13-F |
| 248 | 1613435034 | Lens Head Screw 3x10 ST |
| 249 | 1603435026 | Thread-forming tap. Screw |
| 250 | 2914201508 | Torx Oval-Head Screw |
| 251 | 1607233008 | Speed governor 220-230V |
| 253 | 1604448005 | Connecting Cable L=95 MM WHITE |
| 254 | 1604448006 | Connecting Cable L=40 MM WHITE |
| 255 | 2914201508 | Torx Oval-Head Screw |
| 304 | 1601008003 | Insulating Plate |
| 651 | 3607959005 | Splitting Tool |
| 700 | 3607000060 | Parallel-Guide |
| 700/20 | 3603101002 | Stop Pin |
| 700/30 | 3600210024 | O-Ring 5,94x3,53 MM |
| 700/40 | 2603480003 | Wing Screw M 6x16 MM |
| 739 | 3608640001 | Wall Chaser Ø 115x22,2x2,2 MM |
| 752 | 1607950043 | Pin-Type Face-Wrench |
| 802 | 3607031206 | Parts Set |
| 804 | 3607031656 | Parts Set |
| 810 | 1607014116 | Carbon-Brush Set |
| 813 | 1607000253 | Push-Button BLACK |
| 818 | 3607031207 | Parts Set |
| 821 | 1605806480 | Gear Housing |
| 823 | 3607031547 | Rotary Knob |
| 828 | 1607000936 | Bearing Flange |
| 830 | 1604010248 | Armature With Fan 220-230V |
| 831 | 2914201508 | Torx Oval-Head Screw |
| 832 | 2910211093 | Tapping Screw DIN 7971-BZ3,9x38 |
| 833 | 3607031208 | Parts Set |
| 835 | 1607000386 | Power supply cord EU 230V 4,15m 2 x 1,0mm H05 RN-F |
| 888 | 1601106032 | Nameplate 26x52 MM |
