Bosch Spare Parts for Lawnmower ARM 32
€5.84
Tax included
Bosch Spare Parts for Lawnmower ARM 32
Bosch Genuine spare parts or replacement parts for to repair Lawnmower ARM 32 - 0600897003.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Lawnmower ARM 32
Bosch Genuine spare parts or replacement parts for to repair Lawnmower ARM 32 - 0600897003.
In the following table, look for the model of the Lawnmower and the respective parts of the code.
| Lawnmower ARM 32/0 600 897 003 | ||
| # | Part Num. | Description |
| 30 | F016T46305 | Cable Cleat |
| 32 | F016L11301 | Stud bolt M8x20 |
| 35 | F016L35411 | Plain Washer 8,5 MM |
| 37 | F016L35307 | Spring Washer 5/16 SW SE |
| 38 | F016L61530 | Sealing cap |
| 39/11 | F016L35411 | Plain Washer 8,5 MM |
| 39/16 | F016L59236 | Cable Clip |
| 39/17 | F016L62095 | Pivot Pin |
| 39/20 | F016L59277 | Bolt M6x50 |
| 40 | F016L59301 | Housing Base |
| 43/01 | F016L62162 | Cover GREEN |
| 43/04 | F016L59186 | Sealing cap |
| 43/07 | F016L59334 | Clamping Lever |
| 43/08 | F016L59311 | Guard Plate |
| 43/09 | F016L59353 | Hinge Bolt |
| 43/10 | F016L59352 | Coiled Spring |
| 52/01 | F016L59315 | Axle |
| 52/02 | F016L59324 | Adjusting lever |
| 52/03 | F016L59373 | Spacer |
| 55 | F016L59314 | Cutter Blade |
| 61/01 | F016L59315 | Axle |
| 61/03 | F016L59325 | Spacer |
| 75/01 | F016L59351 | Pipe Frame |
| 75/04 | F016L36449 | Switch Cover |
| 75/05 | F016T49637 | Switch Housing |
| 75/06 | F016T49630 | Cable Cleat |
| 75/07 | F016103606 | On-Off Switch |
| 75/09 | F016T49633 | Spiral Spring |
| 75/10 | F016T49223 | Knob |
| 75/11 | F016T49226 | Compression Spring |
| 75/12 | F016T49636 | Cable Cleat |
| 75/14 | F016T49429 | Self-Cutting Screw 4x19 MM |
| 75/15 | F016L59243 | Reference Plate |
| 75/16 | F016L65387 | Strain-Relief Clamp |
| 75/18/02 | F016T49627 | Limit Switch |
| 75/18/03 | F016T49634 | Holder |
| 75/18/04 | F016T56145 | Straight Pin |
| 75/21 | F016T49629 | Holder |
| 75/22 | F016T49628 | Holder |
| 80/01 | F016L62806 | Catcher Container |
| 83 | F016L61774 | Sealing cap |
| 86 | F016L59159 | Cover |
| 87 | F016L59360 | Cover |
| 91 | F016L61882 | Linkage part |
| 92 | F016L59346 | Display |
| 94 | F016L59372 | Plug |
| 95 | F016L59318 | Cover GREEN |
| 98 | F016L61602 | Protective Shield |
| 99 | F016L59327 | Spring |
| 100 | F016L61597 | Coiled Spring |
| 111 | F016L61609 | Leaf Spring |
| 120 | F016L61752 | Flap |
| 121 | F016L61751 | Clip |
| 450 | F016L59346 | Display |
| 451 | F016L59364 | Reference Plate |
| 453 | F016L61441 | Warning Plate |
| 454 | F016L61268 | Reference Plate |
| 500 | F016L61747 | Pickup Clip |
| 501 | F016T46941 | Spring retaining ring |
| 502 | F016T48428 | Plain Washer M5 |
| 503 | F016T49429 | Self-Cutting Screw 4x19 MM |
| 505 | F016L61750 | Blade |
| 510 | F016L57338 | Plain Washer |
| 801 | F016L59335 | Motor |
| 839/18 | F016L66136 | Wing Nut |
| 857 | F016102328 | Fan |
| 859 | F016102096 | Nut |
| 861/02 | F016102101 | Vertical Adjustment |
| 875/02 | F016102164 | Connecting Cable |
| 875/18 | F016102166 | Bow |
| 875/30 | F016102163 | Bow |
| 878 | F016102211 | Pipe Frame |
| 883/01 | F016L59370 | Cover |
| 883/02 | F016L59150 | Indicator Holder |
| 885 | F016102106 | Axle |
| 888 | F016102145 | Wheel |
| 889 | F016102146 | Wheel |
| 8150 | F016102207 | Balance Weights |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Bosch websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Bosch brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
