Bosch Compound Mitre Saw GCM 18V-216 Parts
€231.93
Tax included
Bosch Compound Mitre Saw GCM 18V-216 Spare Parts
We are BOSCH original spare parts Dealers at low at unbeatable prices and a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Professional Compound Mitre Saw GCM 18V-216 - 3601M41000.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Compound Mitre Saw GCM 18V-216 Spare Parts
We are BOSCH original spare parts Dealers at low at unbeatable prices and a service center with repair service able to advise you on the purchase of the most suitable spare part to quickly resolve any maintenance or repair issues for Professional Compound Mitre Saw GCM 18V-216 - 3601M41000.
In the following table, look for the model of the Miter Saw and the respective parts of the code.
| BOSCH Compound Mitre Saw GCM 18V-216 3601M41000 - 18 V Spare Parts | ||
| # | Part Num. | Description |
| 2 | 160702266T | DC motor |
| 4 | 2607202382 | Switch |
| 21 | 1609B06265 | Ribbon cable |
| 22 | 1609BP7087 | Tapping Screw |
| 25 | 1609B06252 | Box |
| 26 | 1609B06253 | Cover |
| 28 | 1619P01642 | Compression Spring |
| 29 | 1609B04070 | Cap |
| 31 | 1609B06269 | Compression Spring |
| 32 | 1609B04073 | Guide Bracket |
| 38 | 1609BP7084 | Screw |
| 39 | 1609B06570 | Cover |
| 41 | 1609B04154 | Rod |
| 42 | 1609B06259 | Mitre Fence |
| 44 | 1609B06261 | Mitre Fence |
| 45 | 1609B02206 | Screw |
| 46 | 1609B05238 | Table |
| 51 | 1609B03746 | End cap |
| 52 | 1609B06251 | Handle |
| 56 | 1609B00780 | Screw |
| 57 | 1609BP7326 | Knob |
| 58 | 1609B03708 | Scale |
| 59 | 1609B05382 | Knurled Screw |
| 60 | 1609B05298 | Cover |
| 61 | 1609B00863 | Plain Washer |
| 62 | 1609B00717 | Pointer |
| 63 | 1609B03714 | Wear Plate |
| 64 | 1609B04236 | Bolt |
| 65 | 1609B04227 | Adjusting Nut |
| 66 | 1609B01949 | Nut |
| 67 | 1609B06571 | Washer |
| 70 | 1609B00682 | Screw |
| 72 | 1609B05203 | Bolt |
| 74 | 1609B00704 | Lock Nut |
| 75 | 1609B00670 | Washer |
| 77 | 1609B00705 | Rubber Bushing |
| 80 | 1609BP7098 | Rubber Ring |
| 81 | 1609BP7026 | Hexagon Socket Screw Key |
| 84 | 1609B05242 | Support Plate |
| 86 | 1609B05240 | Rod |
| 87 | 1609B04079 | Knob |
| 88 | 1609B05241 | Lever |
| 89 | 1609B02211 | Spring |
| 90 | 1609B01664 | Screw |
| 92 | 1609B05115 | Cable |
| 93 | 1609BP7341 | Contact strap |
| 94 | 1609B03727 | Supporting foot |
| 95 | 1609B03729 | Wear Plate |
| 96 | 1609B04108 | Pivot Shaft |
| 97 | 1609B04086 | Screw |
| 98 | 1609B03723 | Screw |
| 99 | 1609B01324 | Plain Washer |
| 101 | 1609B01462 | Shoulder Screw |
| 105 | 1609BP7143 | Set screw |
| 111 | 1609B01668 | Washer |
| 114 | 1609B03739 | Stop Plate |
| 118 | 1609B04134 | Wear Plate |
| 119 | 1609B03758 | Pointer |
| 120 | 1609BP7053 | Compression Spring |
| 121 | 1609BP7045 | Plain Washer |
| 122 | 1609B03749 | Hex Socket Head Cap Screw |
| 123 | 1609BP7343 | Contact strap |
| 124 | 1609B03755 | Knob |
| 125 | 1609B03762 | Rotor |
| 126 | 1609B03763 | Felt Washer |
| 127 | 1609B03769 | Bolt |
| 128 | 1609B02215 | Lever |
| 129 | 1609BP7081 | Screw |
| 130 | 1609B03773 | Friction Plate |
| 131 | 1609B01041 | Hex Nut |
| 132 | 1609B03776 | Stop bolt |
| 133 | 1609B03771 | Pivot Pin |
| 134 | 1609B06272 | Screw |
| 136 | 1609B03767 | Detent Pin |
| 137 | 1609B03757 | Clip |
| 138 | 1609B00601 | O-Ring |
| 140 | 1609B03745 | Handle Plate |
| 141 | 1609B03747 | Carrying Handle |
| 142 | 1609B03768 | Tapping Screw |
| 143 | 1609B03753 | Slide Stop |
| 144 | 1609B03752 | Special Nut |
| 145 | 1609B06667 | O-Ring 12,2 X 3,6 |
| 146 | 1609B00660 | Spring Washer |
| 147 | 1609B03795 | Shoulder Screw |
| 148 | 1609B00382 | Knob |
| 149 | 1609B00417 | Compression Spring |
| 150 | 1609B02203 | Retaining Plate |
| 151 | 1609B03766 | Retaining Plate |
| 152 | 2610027044 | Dust Extraction |
| 153 | 1609B03777 | Set screw |
| 158 | 2610027045 | Dust Extraction |
| 159 | 2610027046 | Bracket |
| 160 | 1609B01561 | Screw |
| 161 | 1609B05201 | Shoulder Screw |
| 162 | 1609B00623 | Screw |
| 164 | 1609B01690 | Screw |
| 167 | 1609B01602 | Wear Plate |
| 168 | 1609B04188 | Lower guard |
| 169 | 1609B04001 | Linkage |
| 170 | 1609B04002 | Cover |
| 171 | 1609B04004 | Spring |
| 172 | 1609BP7145 | Screw |
| 173 | 1609B05251 | Spring Clip |
| 174 | 1609B04235 | Ball Bearing |
| 176 | 1609B04163 | Screw |
| 178 | 1609B00974 | Lock Nut |
| 179 | 1609BP7134 | Tapping Screw |
| 182 | 1609B04205 | Set screw |
| 184 | 1609BT4033 | Nut |
| 185 | 1609BP7068 | Spring retaining ring |
| 186 | 1609BP7050 | Washer |
| 187 | 1609B03774 | Ball Bearing |
| 188 | 1609B03780 | Spacer |
| 189 | 1600200029 | Plain bearing |
| 190 | 1609B04017 | Deflector |
| 191 | 1609B06271 | Chip Deflector |
| 192 | 1609B04018 | Clamping Flange |
| 193 | 1609B06289 | Clamping Flange |
| 194 | 1609B05364 | Flange Bolt |
| 195 | 1609B04020 | Wheel |
| 197 | 1609B06264 | Housing Cover |
| 198 | 1609B06286 | Housing Cover |
| 199 | 2609110353 | Torx Oval-Head Screw |
| 200 | 1609B00637 | Tapping Screw |
| 201 | 1609B00973 | Screw |
| 202 | 1609B06270 | Screw |
| 203 | 1609B00458 | Quick-Lock |
| 212 | 1609B04208 | Screw |
| 215 | 1609B04664 | Chip Deflector |
| 225 | 1609B06301 | Cover |
| 231 | 1609B06266 | Ribbon cable |
| 232 | 1609B00691 | Nut |
| 234 | 1609B03791 | rubber lip |
| 235 | 1609B04225 | Plain Washer |
| 236 | 1609B04220 | Rubber Strip |
| 238 | 1609B04222 | Rubber Strip |
| 239 | 1609B00633 | Screw |
| 240 | 1609B06262 | Battery Holder |
| 241 | 16072335F8 | Electronics Module |
| 242 | 1609B06832 | Cable Set |
| 244 | 1609B03361 | Screw |
| 245 | 1609280477 | Compression Spring |
| 246 | 1609B06800 | Screw |
| 247 | 1609B06267 | Cover |
| 254 | 1609B06283 | Label |
| 255 | 1609B06285 | Label |
| 263 | 1609B06575 | Label |
| 284 | 1609B00703 | Plain Washer |
| 808 | 1609BN0373 | Nameplate |
| 822 | 1609B01726 | Laser |
| 825 | 1609B04127 | Dust-Protection Cover |
| 840 | 1609B06665 | Base |
| 843 | 1609B06578 | Mitre Fence |
| 844 | 1609B06666 | LED lamp |
| 847 | 1609B06579 | Pivot |
| 848 | 1609B06663 | Yoke |
| 849 | 1609B06664 | Arm |
| 850 | 1609B05349 | Gear cover |
| 851 | 1617S019K0 | Battery Pack |
| 852 | 1609B04224 | Clamp |
| 853 | 2607225921 | Charger EU GAL 1880 CV 230/14,4-18V |
| 854 | 1609B06278 | Dust Bag |
| 855 | 1609B06573 | Gear |
| 866 | 1609B04124 | Torsion Spring |
| 876 | 1609B05323 | Knob |
All product specifications in this catalog are based on information taken from official sources, including the official manufacturer’s Bosch websites, which we consider as reliable. Unfortunately, even the official documents may contain mistakes and printing errors – we are not able to confirm that all of these data are precise and represent the facts. Most of the manufacturers reserve the right to change the product characteristics or complement without notice. We strongly recommend using the published information as a basic information subject to Bosch brand review. Please refine the important parameters by the selling assistant when making a purchase. All content included in this catalog is the intellectual property of www.bricoutensili.com. Any publication or copying (full or partial) without a reference to the source page is prohibited.
