Bosch Spare Parts for Wall Chaser GNF 35 CA
€2.31
Tax included
Bosch Spare Parts for Wall Chaser GNF 35 CA
Bosch genuine replacement parts for to replace broken parts for to fix Wall Chaser GNF 35 CA - 0601621703.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Wall Chaser GNF 35 CA
Bosch genuine replacement parts for to replace broken parts for to fix Wall Chaser GNF 35 CA - 0601621703.
In the following table, look for the model of the Groover and the respective parts of the code
| Wall Chaser GNF 35 CA/0 601 621 703 | ||
| # | Part Num. | Description |
| 1 | 1605108208 | Motor Housing BLUE |
| 2 | 1604220284 | Field 220-230V |
| 4 | 1607200150 | Switch |
| 6 | 2600703013 | Grommet Ø7,6-Ø8,2x95 MM |
| 7 | 1601302017 | Fastening Clamp |
| 9 | 3601119179 | Manufacturer's nameplate |
| 12 | 1607328042 | Suppression Filter |
| 13 | 2600905032 | groove ball bearing 7x19x6 |
| 14 | 1600905032 | groove ball bearing 8x22x7 |
| 16 | 1601323025 | Brush Holder |
| 17 | 1604652013 | Spiral Spring |
| 18 | 3602025023 | Switch Handle |
| 19 | 1604611026 | Compression Spring |
| 20 | 1602319011 | Adjusting Slide |
| 25 | 1600508016 | Housing Cover BLUE |
| 26 | 1600206036 | Rubber Ring |
| 27 | 1600206025 | Rubber Ring |
| 29 | 1600591025 | Air-Deflector Ring |
| 30 | 1600591014 | Air-Deflector Ring |
| 32 | 3603523041 | Grinding Spindle M14 |
| 33 | 3600210124 | O-Ring 46,0x1,1 MM RED |
| 35 | 1600136013 | Shim 0,1 MM THICK |
| 1600136014 | Shim 0,2 MM THICK | |
| 1600136015 | Shim 0,3 MM THICK | |
| 1600136020 | Shim 0,15 MM THICK | |
| 37 | 1600290016 | Rotary shaft lip seal |
| 40 | 1600119011 | Spring retaining ring |
| 41 | 1600200029 | Plain bearing |
| 45 | 1603300016 | Hex Nut M7, SW10 |
| 47 | 2603490021 | Torx Oval-Head Screw 4x12 |
| 48 | 1613435034 | Lens Head Screw 3x10 ST |
| 49 | 1603435026 | Thread-forming tap. Screw |
| 50 | 2603490023 | Torx Oval-Head Screw 4x20 |
| 51 | 1607233148 | Speed governor 220-240V |
| 52 | 3604460117 | Light Conductor |
| 53 | 3604438020 | Connecting Cable L=50 MM WHITE |
| 55 | 2603490024 | Torx Oval-Head Screw 4x25 |
| 70 | 3600150023 | Cover Disc |
| 81 | 2600101022 | Shim 0,2 MM |
| 104 | 1600210044 | O-Ring 4,5x1,0 MM BLUE |
| 105 | 1601008005 | Insulating Plate |
| 154 | 3600913010 | Distance Pipe |
| 155 | 2916660013 | Spring retaining ring DIN 472-32x1,2 MM |
| 156 | 3600905130 | groove ball bearing 12x32x10 |
| 157 | 3600105009 | Seal ring |
| 203 | 3605108193 | Protective Cover |
| 204 | 3605108194 | Housing Section |
| 205 | 3600150029 | Sliding Plate |
| 206 | 3603105010 | Bearing Shaft |
| 207 | 3600309003 | Roller |
| 209 | 3601902012 | Locking Lever |
| 210 | 3601923001 | Rejection Slide |
| 211 | 3609202043 | Tensioner Parts Set |
| 214 | 3602305011 | Push-Button |
| 215 | 3604651016 | Torsion Spring |
| 216 | 3604651006 | Coiled Spring |
| 217 | 3604651005 | Coiled Spring |
| 220 | 3601023003 | Safety Catch |
| 221 | 3604680002 | Shaped Spring |
| 222 | 3600300060 | Spacer Tube |
| 225 | 3600300061 | Spacer Sleeve |
| 227 | 3605500164 | Protective Cap |
| 228 | 3603490015 | Pan head screw M 10x12 MM |
| 231 | 2603490023 | Torx Oval-Head Screw 4x20 |
| 232 | 2918370504 | Countersunk-Head Screw |
| 233 | 1613435034 | Lens Head Screw 3x10 ST |
| 235 | 2916089079 | Locking Washer |
| 237 | 2917511104 | Straight Pin DIN 7-4MM6x28-C35K-RIKO |
| 241 | 3601119180 | Reference Plate |
| 249 | 1613490017 | Thread-forming tap. Screw M4x30 DIN7500-1 T-20 |
| 305 | 3601119236 | Reference Plate |
| 318 | 3609202039 | Clamping-Flange Ø 42 MM, SW17 |
| 319 | 3609202040 | Round Nut Ø 45 MM, M14 |
| 320 | 3609202041 | Plain Washer Ø 42X22,2X4 MM |
| 321 | 3609202042 | Plain Washer Ø 42X22,2X6 MM |
| 651 | 3607959005 | Splitting Tool |
| 652 | 1607950061 | Pin-Type Face-Wrench |
| 802 | 3607031545 | Parts Set |
| 803 | 1604010654 | Armature With Fan 220-240V |
| 805 | 1607000392 | Power supply cord EU 4,15m 2 x 1,0mm H07 RN-F |
| 806 | 1900452012 | End Splice DIN 46 228-A1-6 |
| 808 | 1601106032 | Nameplate 26x52 MM |
| 810 | 3607014010 | Carbon-Brush Set |
| 1607000500 | Carbon-Brush Set 10 x 3 607 014 010 | |
| 818 | 3607031207 | Parts Set |
| 821 | 1605806451 | Gear Housing |
| 823 | 3607031547 | Rotary Knob |
| 828 | 3605700158 | Bearing Flange |
| 835 | 1606610132 | Fan |
| 838 | 1607000A4P | Set Of Gearwheels |
| 840 | 1607000253 | Push-Button BLACK |
| 899 | 3605430011 | Silicone Sealing SILASTIC 7091 |
