Bosch Spare Parts for Angle Grinder GWS 9-125 CS - 0601343003
€15.04
Tax included
Bosch Spare Parts for Angle Grinder GWS 9-125 CS - 0601343003
Distribution and Sale at attractive prices of BOSCH Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Angle Grinder GWS 9-125 CS /230 V/EU - 0601343003.
Politiche per la sicurezza
(modificale nel modulo Rassicurazioni cliente)
Politiche per le spedizioni
(modificale nel modulo Rassicurazioni cliente)
Politiche per i resi
(modificale nel modulo Rassicurazioni cliente)
Bosch Spare Parts for Angle Grinder GWS 9-125 CS - 0601343003
Distribution and Sale at attractive prices of BOSCH Original Spare Parts. We guarantee low prices and a professional Assistance and repair service able to advise you on the purchase of the most suitable spare part to quickly solve any maintenance issue for Angle Grinder GWS 9-125 CS /230 V/EU - 0601343003.
In the following table, look for the model of the Angle Grinder and the respective parts of the code.
| Angle Grinder - GWS 9-125 CS /230 V/EU - 0601343003 | ||
| # | Part Num. | Description |
| 1 | 16051082CC | Motor Housing |
| 2 | 1604220220 | Field 220-230V |
| 3/50 | 1606610121 | Fan |
| 4 | 1607200086 | On-Off Switch |
| 4/10 | 2910110048 | Pan head screw DIN 85-AM3x6-CUZN |
| 6 | 2600703012 | Grommet Ø6,5-Ø6,9x95 MM |
| 7 | 1601302017 | Fastening Clamp |
| 9 | 1601110607 | Manufacturer's nameplate |
| 12 | 1607328029 | Suppression Filter |
| 13 | 2600905032 | Ball Bearing 7x19x6 |
| 14 | 1900905018 | Ball Bearing 7x22x7 |
| 16 | 1600A003G4 | Brush Holder |
| 17 | 1601110608 | Manufacturer's nameplate |
| 18 | 1604611026 | Compression Spring |
| 22 | 1602319002 | Adjusting Slide |
| 23 | 1602026057 | Switch Handle BLACK |
| 25 | 1600508006 | Housing Cover BLACK |
| 26 | 1600502020 | Rubber Bushing |
| 27 | 1600206025 | Rubber Ring |
| 29 | 1601328005 | Air-Deflector Ring |
| 31 | 2916660013 | Retaining clip DIN 472-32x1,2 MM |
| 33 | 3600210124 | O-Ring 46,0x1,1 MM RED |
| 35 | 1600136010 | Shim 0,2 MM THICK |
| 1600136011 | Shim 0,3 MM THICK | |
| 1600136012 | Shim 0,1 MM THICK | |
| 36 | 1600150011 | Spring Washer |
| 37 | 1600290016 | Rotary shaft lip seal |
| 38 | 1606333601 | Crown Gear Z=36 |
| 39 | 1604652013 | Spiral Spring |
| 40 | 2916660009 | Spring retaining ring DIN 472-25x1,2MM |
| 41 | 1600910018 | Needle bearing Ø8xØ12x8 MM |
| 42 | 1600905006 | groove ball bearing 12x32x10 |
| 43 | 1606333242 | Bevel Gear Z=11 |
| 45 | 1603300016 | Hex Nut M7, SW10 |
| 47 | 2910211018 | Tapping Screw DIN 7971-ST3,9x13-F |
| 48 | 2910211005 | Tapping Screw DIN 7971-ST2,9x9,5-F |
| 49 | 1603435026 | Thread-forming tap. Screw |
| 50 | 2910211021 | Tapping Screw DIN 7971-ST3,9x22-F |
| 51 | 1607233013 | Speed governor 230V |
| 53 | 1604448005 | Connecting Cable L=95 MM WHITE |
| 54 | 1604448006 | Connecting Cable L=40 MM WHITE |
| 55 | 2912401021 | Tapping Screw DIN7981-ST3,9x22-C-Z |
| 100 | 1601110378 | Sticker |
| 105 | 1601110470 | Reference Plate |
| 107 | 1600210044 | O-Ring 4,5x1,0 MM BLUE |
| 650/20 | 1603345043 | Round Nut M14 |
| 650/30 | 1607950052 | Pin-Type Face-Wrench |
| 650/50 | 2605703014 | Clamping Flange Ø22,3xØ42 MM |
| 650/50/20 | 1600210039 | O-Ring 20,35x1,78 MM |
| 651/10 | 2602025067 | Auxiliary Handle M10, Ø32,5x105 MM |
| 1602025027 | Auxiliary Handle M10 | |
| 652 | 1600A0136N | Protective Cover |
| 652/20 | 2910022197 | Socket head cap screw DIN 84-M 6x16-8.8 |
| 2910141197 | Hex Socket Head Cap Screw DIN 912-M6x16-8.8 | |
| 803 | 1604010248 | Armature With Fan 220-230V |
| 805 | 1607000227 | Power supply cord EU 4,15m 2 x 1,0mm H07 RN-F |
| 808 | 160111A3H3 | Nameplate |
| 810 | 1607014116 | Carbon-Brush Set |
| 813 | 1607000253 | Push-Button BLACK |
| 821 | 1605806480 | Gear Housing |
| 828 | 1607000936 | Bearing Flange |
| 832 | 1607000D6A | Grinding Spindle |
